Page 1: Vik Software Setup
ASL 5000™ Breathing Simulator RespiSim® System VIK Ventilator Interface Kit Setup Guide USA Toll Free: 1-800-583-9910 | International: +1 (412) 441-8228 | support@ingmarmed.com... - Page 2 This page intentionally left blank...
- Page 3 Document History Revision History Date Authors Rev. 1 6/14/2018 Michael Bails...
-
Page 4: Egal Nformation
EGAL NFORMATION For factory repair service, call: Toll free: 1-800-583-9910 International: +1 (412) 441-8228 Facsimile: +1 (412) 441-8404 or contact us via e-mail at: service@ingmarmed.com Our shipping address: IngMar Medical, Ltd. 5940 Baum Blvd Pittsburgh, PA 15206 USA Please note that a valid return merchandise authorization (RMA) no. is always required before sending in any products for repair, calibrations, or updates. Limitation of Liability IngMar Medical Ltd.'s liability, whether arising out of or related to manufacture and sale of the goods, their installation, demonstration, sales representation, use, performance, or otherwise, including any liability based upon above defined product warranty, is subject to and limited to the exclusive terms and conditions as set forth, whether based upon breach of warranty or any other cause of action whatsoever, regardless of any fault attributable to IngMar Medical, and regardless of the form of action (including, without limitation, breach of warranty, negligence, strict liability, or otherwise). THE STATED EXPRESSED WARRANTIES ARE IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING, WITHOUT LIMITATION, WARRANTIES OF MERCHANTABILITY, FITNESS FOR ANY PARTICULAR PURPOSE, OR NONINFRINGEMENT. IngMar Medical, Ltd. shall not be liable for, nor shall buyer be entitled to recover, any special incidental or consequential damages or for any liability incurred by buyer to any third party in any way arising out of or relating to the goods. Patents The ASL™ 5000 Breathing Simulator is protected under US patent 5975748 which it uses under exclusive license. Copyright © 2018, IngMar Medical, Ltd. -
Page 5: Table Of Contents
Table of Contents .................... 4 EGAL NFORMATION .................. 6 BOUT THE UIDE 1.1 Conventions Used in This Manual ................6 ................. 6 AFETY ONSIDERATIONS 2.1 Operator Safety ......................6 2.2 Summary of General Precautions ................7 VIK ................ 8 NTRODUCTION TO THE 3.1 System Overview ...................... 8 .................... 9 ETUP 4.1 VIK Components ....................... 9 4.2 VIK Connection to the RespiSim System .............. 1 0 4.3 VIK Software Setup .................... 1 1... -
Page 6: About The Guide
BOUT THE UIDE This guide is for IngMar Medical’s Ventilator Interface Kit (hereafter called VIK). It is an add-on to the RespiSim® System which includes the ASL 5000™ Breathing Simulator. The guide includes details for physical setup as well as installing the software. It is recommended that you read this carefully before using the equipment. V.V Conventions Used in This Manual Indicates points of particular interest or emphasis for more efficient or convenient operation. ARNING Indicates a potentially harmful condition that can lead to personal injury. CAUTION Indicates a condition that may lead to equipment damage or malfunction AFETY ONSIDERATIONS Z.V Operator Safety For correct and effective use of the product it is mandatory to read and to observe all instructions, WARNINGS, and CAUTION statements in this guide. If the product is not used as instructed, the safety protection provided may be impaired. ARNING Electromagnetic Interference: Do not use the VIK in patient rooms or other areas where life supporting equipment is in use. -
Page 7: Summary Of General Precautions
Z.Z Summary of General Precautions CAUTION Electrical Supply: Connect ASL 5000™ only to a properly grounded wall outlet providing 100 – 240 V AC, 50 – 60 Hz. -
Page 8: Nintroduction To The Vik
VIK NTRODUCTION TO THE ^.V System Overview The VIK is an accessory intended to be used when connecting ventilators to the ASL 5000™. The VIK provides a one-way communications link from a variety of ventilators to the RespiSim® system. The information from the ventilator can populate the RespiSim software via control module and the appropriate dongle for the ventilator. The VIK connects to the RespiSim system via the internal network router. Figure 3-1: VIK Installed in the RespiSim Cart... -
Page 9: Vik Setup
4 VIK ETUP The VIK add-on is controlled by the RespiSim® software by calling an array of available parameters to be populated in the RespiSim user interface. `.V VIK Components The VIK includes the following components • Main module with three (3) connection ports • USB power adapter (5.25V 2.4A max) • Ethernet cable • USB to Serial adapter • Ventilator dongle kit including USB drive with software Figure 4-1: VIK Components... -
Page 10: Vik Connection To The Respisim System
`.Z VIK Connection to the RespiSim System These instructions assume the VIK is being installed in an existing RespiSim® System. Figure 4-2: SBLVM / ASL 5000 Connection 1. Apply a strip of Velcro to the back side of the VIK module and place in the cart next to the router 2. Connect the black 1’ ethernet cable from the VIK Ethernet port to a numbered port on the router 3. Connect the USB end of the blue/yellow adapter into the VIK bottom USB port 4. Connect the 15’ Ethernet cable to the other end of the blue/yellow adapter. Route the other end of this cable through the back of the tray and loop with Velcro to the side of the cart (for connection to the ventilators) 5. Plug the USB-micro power adapter into the power strip on the cart and route the power cable into the drawer and into the VIK controller... -
Page 11: Vik Software Setup 1
`.^ VIK Software Setup The VIK includes a USB drive which holds the following required software packages: • Chrome browser (check online for latest version of the Google Chrome browser) • RTServerSetup.exe 1. Plug the VIK USB drive into the RespiSim® System computer 2. If Google Chrome is not already installed, install the Chrome Browser from the USB drive (Chrome is the recommended browser to use with the VIK installation) 3. Open the VIK folder in the USB drive 4. Double-click the RTServerSetup to install the RT-Server 5. Open the Chrome browser 6. Navigate to http://localhost (type this in the browser address bar) Figure 4-3: VIK Sign In Screen 7. Type manager in the User name field and type ingmar in the Password field 8. On the next screen, click the Admin dropdown in the top right corner of the screen, then click Bridges Figure 4-4: VIK Bridge Setup Page... - Page 12 9. On the Bridges page, click the “Create” button Figure 4-5: VIK Create Bridge 10. Find the serial number of the VIK by looking at the orange barcode sticker either on the side or bottom of the VIK controller Figure 4-6: VIK Serial Number 11. In the Add new bridge popup, enter the serial number of the VIK (including all hyphens), then click “Create” Figure 4-7: Add Serial Number...
- Page 13 12. The new Bridge will appear on the next screen Figure 4-8: Populated Bridge 13. Restart the RespiSim® System computer 14. From the RespiSim VIK case, find the appropriate dongle for the ventilator to be used and plug it into the appropriate port on the ventilator Figure 4-9: Example Dongle for Ventilator 15. Power on the ventilator 16. Connect the Ethernet cable from the VIK controller to the dongle 17. Open the Chrome browser 18. Navigate to http://localhost 19. Enter manager as the User name and ingmar as the Password and then click the “Sign In” button. 20. On the following screen, click on the Admin dropdown, then click bridges 21. Wait approximately one (1) minute for the ventilator and VIK to communicate 22. Click the Refresh on the BridgeTech display in Chrome and the information will be visible...
- Page 14 Figure 4-10: Ventilator Data Populated 23. Open the cart drawer and observe the LCD display on the VIK controller. It should look similar to the figure below Figure 4-11: VIK LCD Display 24. From the browser window on the RespiSim® computer, click BridgeTech WebClinical Figure 4-12: BridgeTech WebClinical Link 25. This will open a window showing a new patient with the name RespiSim followed by a set of numbers Figure 4-13: VIK Simulated Patient...
- Page 15 26. Click on the RespiSim® name and then click Patient Readings 27. Verify that data is being received from the vent as it will populate the Patient Readings screen Figure 4-14: VIK Patient Readings 28. Once data is confirmed, Chrome can be closed (data updates every 30 seconds) 29. Open Windows Explorer and navigate to the C:\Program Files (x86)\ASL Software 3.6\ folder 30. Open the ASL_SW3.6.ini file using Notepad or similar text editor 31. Change the following line: BridgetechV2=”False” to BridgetechV2=”True” Figure 4-15: ASL Configuration File...
- Page 16 Figure 4-16: Change Config from False to True 32. Save the file and close Windows Explorer 33. For setting up ventilator parameters as part of the RespiSim® System simulation, please refer to the ASL 5000 User’s Manual.
