Alarms & Remote Start
OEM-FO(RS)-FO1B-[OL-RS-FO1]-EN
NOTICE
The manufacturer will accept no responsability for any electrical
damage resulting from improper installation of this product, be that either
damage to the vehicle itself or to the installed device. This device must be in-
stalled by a certified technician. Please review the Installation Guide carefully
before beginning any work.
U.S. Patent No. 8,856,780
Automotive Data Solutions Inc. © 2016
INSTALL GUIDE
DOCUMENT NUMBER
26841
REVISION DATE
20160224
FIRMWARE
OEM-FO(RS)-FO1B-[OL-RS-FO1]
HARDWARE
OL-RS-FO1
ACCESSORIES
OL-LOADER (REQUIRED)
BEFORE INSTALLATION
1- Connect module to computer
2- Login to Weblink account
3- Flash firmware to module (module is not preloaded with firmware)
4- Use accessories accordingly (accessories are sold separately)
Advertisement
Table of Contents
Related Manuals for Omega Omegalink OL-RS-FO1
Summary of Contents for Omega Omegalink OL-RS-FO1
- Page 1 Alarms & Remote Start INSTALL GUIDE OEM-FO(RS)-FO1B-[OL-RS-FO1]-EN DOCUMENT NUMBER 26841 REVISION DATE 20160224 FIRMWARE OEM-FO(RS)-FO1B-[OL-RS-FO1] HARDWARE OL-RS-FO1 ACCESSORIES OL-LOADER (REQUIRED) NOTICE BEFORE INSTALLATION The manufacturer will accept no responsability for any electrical damage resulting from improper installation of this product, be that either 1- Connect module to computer damage to the vehicle itself or to the installed device.
- Page 2 PAGE 2 OF 24 VEHICLE LIST - 1 OF 1 • 20160224 DOC.: #26841 FEATURES Edge STD key AT 11-14 1 • • • • • • • • • • • • • Explorer STD key AT 11-15 1 •...
- Page 3 PAGE 3 OF 24 BOX CONTENTS - 1 OF 1 • 20160224 DOC.: #26841 BOX CONTENTS MODULE T-HARNESS 1 10 PIN CONNECTOR LED 2 PROGRAMMING BUTTON LED 1 BLUE 12 PIN CONNECTOR BLACK RF PORT/ WEBLINK PORT BLUE BLACK TELEMATIC PORT AFTERMARKET HOOD SWITCH AND CABLE BLACK...
- Page 4 PAGE 4 OF 24 COMPONENT LOCATOR - 1 OF 1 • 20160224 DOC.: #26841 INTERIOR VIEW DRIVER SIDE VIEW PASSENGER SIDE VIEW U.S. Patent No. 8,856,780 Automotive Data Solutions Inc. © 2016 OEM-FO(RS)-FO1B-[OL-RS-FO1]-EN...
- Page 5 PAGE 5 OF 24 TYPE 1 - WIRE CHART - 1 OF 1 • 20160224 DOC.: #26841 CanH C251 Black 16 pin 03 Gray/Orange (DATA) OBDII connector CanL C251 Black 16 pin 11 Purple/Orange (DATA) OBDII connector Horn C2280B Black 52 pin 33 Purple/Green BCM, driver side dash...
- Page 6 PAGE 6 OF 24 TYPE 1 - WIRING DIAGRAM - 1 OF 2 • 20160224 DOC.: #26841 MODULE IGNITION SWITCH (UNDER STEERING COLUMN) IMMOBILIZER CONNECTOR RF PORT/WEBLINK PORT TELEMATIC PORT IMMOBILIZER HARNESS IGNITION CONNECTOR IGNITION HARNESS OBDII BROWN/RED CANH - 03 BROWN/YELLOW CANL - 11 BCM (DRIVER SIDE DASH)
- Page 7 PAGE 7 OF 24 TYPE 1 - WIRING DIAGRAM - 2 OF 2 • 20160224 DOC.: #26841 MODULE RF PORT/WEBLINK PORT TELEMATIC PORT LIFTGATE SWITCH LIFTGATE SWITCH C2114 - BLACK * SEE PREVIOUS PAGE FOR WIRE CONNECTION 01 BROWN/BLACK - PARKING LIGHT (-) OUTPUT 1 2 3 4 5 6 02 GRAY (NC) 03 EMPTY...
- Page 8 PAGE 8 OF 24 TYPE 2 - WIRE CHART - 1 OF 2 • 20160224 DOC.: #26841 CanH C251 Black 16 pin 03 Gray/Orange (DATA) OBDII connector CanL C251 Black 16 pin 11 Purple/Orange (DATA) OBDII connector Horn C2280B Black 52 pin 33 Purple/Green BCM, passenger side dash...
- Page 9 PAGE 9 OF 24 TYPE 2 - WIRE CHART - 2 OF 2 • 20160224 DOC.: #26841 CanH C251 Black 16 pin 03 Gray/Orange (DATA) OBDII connector CanL C251 Black 16 pin 11 Purple/Orange (DATA) OBDII connector Horn C2280B Black 52 pin 33 Purple/Green BCM, driver side dash...
- Page 10 PAGE 10 OF 24 TYPE 2 - WIRING DIAGRAM - 1 OF 2 • 20160224 DOC.: #26841 MODULE IGNITION SWITCH (UNDER STEERING COLUMN) IMMOBILIZER CONNECTOR RF PORT/WEBLINK PORT TELEMATIC PORT IMMOBILIZER HARNESS IGNITION CONNECTOR IGNITION HARNESS BCM (DRIVER SIDE DASH) BCM (DRIVER SIDE DASH) DRIVER DOOR PIN (OPEN) - 09 C2280C...
- Page 11 PAGE 11 OF 24 TYPE 2 - WIRING DIAGRAM - 2 OF 2 • 20160224 DOC.: #26841 MODULE RF PORT/WEBLINK PORT TELEMATIC PORT OBDII * SEE PREVIOUS PAGE FOR WIRE CONNECTION BROWN/RED CANH - 03 BROWN/YELLOW CANL - 11 * SEE PREVIOUS PAGE FOR WIRE CONNECTION 01 BROWN/BLACK - PARKING LIGHT (-) OUTPUT TRUNK/LIFTGATE SWITCH TRUNK/LIFTGATE SWITCH...
- Page 12 PAGE 12 OF 24 TYPE 3 - WIRE CHART - 1 OF 1 • 20160224 DOC.: #26841 CanH C251 Black 16 pin 03 Gray/Orange (DATA) OBDII connector CanL C251 Black 16 pin 11 Purple/Orange (DATA) OBDII connector Driver Door Pin C2280G Gray 24 pin...
- Page 13 PAGE 13 OF 24 TYPE 3 - WIRING DIAGRAM - 1 OF 2 • 20160224 DOC.: #26841 MODULE IGNITION SWITCH (UNDER STEERING COLUMN) IMMOBILIZER CONNECTOR RF PORT/WEBLINK PORT TELEMATIC PORT IMMOBILIZER HARNESS IGNITION CONNECTOR IGNITION HARNESS BCM (BEHIND GLOVE BOX) BCM (BEHIND GLOVE BOX) DRIVER DOOR PIN (OPEN) - 19 GREEN/WHITE...
- Page 14 PAGE 14 OF 24 TYPE 3 - WIRING DIAGRAM - 2 OF 2 • 20160224 DOC.: #26841 MODULE RF PORT/WEBLINK PORT TELEMATIC PORT OBDII * SEE PREVIOUS PAGE FOR WIRE CONNECTION BROWN/RED CANH - 03 BROWN/YELLOW CANL - 11 04 GRAY/WHITE - HOOD STATUS (-) INPUT WITHOUT OEM HOOD SWITCH: INSTALL AND CONNECT TO AFTERMARKET HOOD SWITCH...
- Page 15 PAGE 15 OF 24 MODULE PROGRAMMING PROCEDURE (2 KEYS) - 1 OF 2 • 20160224 DOC.: #26841 >> NOTE: To complete this procedure, both OEM Insert key 1 into ignition. Turn key 2 to ON position. keys are required. START START Insert key 1 into ignition.
- Page 16 PAGE 16 OF 24 MODULE PROGRAMMING PROCEDURE (2 KEYS) - 2 OF 2 • 20160224 DOC.: #26841 Wait, LED will turn solid RED then will turn solid GREEN. Module Programming Procedure completed. U.S. Patent No. 8,856,780 Automotive Data Solutions Inc. © 2016 OEM-FO(RS)-FO1B-[OL-RS-FO1]-EN...
- Page 17 PAGE 17 OF 24 VALET MODE PROGRAMMING PROCEDURE - 1 OF 1 • 20160224 DOC.: #26841 >> >> NOTE: In Valet Mode, the Remote starter is not To exit valet mode: repeat steps 1 to 5. functional. Keyless entry, Lock and Unlock will remain functional.
- Page 18 PAGE 18 OF 24 MODULE NAVIGATION PROCEDURE - 1 OF 1 • 20160224 DOC.: #26841 >> It is mandatory to exit the Module Navigation TO ACCESS THE OPTIONS: Press and hold To save and return to the OPTIONS: Press and at the end of this procedure.
- Page 19 PAGE 19 OF 24 MODULE NAVIGATION CHART - 1 OF 2 • 20160224 DOC.: #26841 MODULE NAVIGATION CHART: NOTES I Default settings are listed in bold. DISARM/UNLOCK BEFORE START II Make sure the option is covered on the vehicle before attempting to change the setting.
- Page 20 PAGE 20 OF 24 MODULE NAVIGATION CHART - 2 OF 2 • 20160224 DOC.: #26841 MODULE NAVIGATION CHART: NOTES DOUBLE LOCK LOCK + UNLOCK HORN EVENT TRIGGER LOCK + UNLOCK + START CONFIGURATION DOUBLE LOCK + START 30 mSEC HORN CHIRPS WIDTH 15 mSec 60 mSec 02-07 Technical Support only...
- Page 21 PAGE 21 OF 24 REMOTE STARTER ERROR CODES - 1 OF 1 • 20160224 DOC.: #26841 REMOTE STARTER ERROR CODES: NOTES Foot brake is ON. I WARNING: The following applies only when the parking lights are connected and supported by the system. Hood is open.
- Page 22 PAGE 22 OF 24 MODULE DIAGNOSTICS - 1 OF 1 • 20160224 DOC.: #26841 TEST MODULE Flashing RED Missing/wrong information from fi rmware or vehicle. Solid RED Module waiting for more vehicle information. Flashing GREEN Additional steps required to complete module programming. DURING PROGRAMMING Solid GREEN then OFF Module correctly programmed.
- Page 23 PAGE 23 OF 24 MODULE RESET PROCEDURE - 1 OF 1 • 20160224 DOC.: #26841 Disconnect all connectors from module except Reconnect all connectors. the BLACK 20-PIN connector. Disconnect the BLACK 20-PIN connector. Repeat programming procedure. >> PRESS AND HOLD the module’s programming Failure to follow procedure may result with a button while connecting the BLACK 20-PIN DTC or a CHECK ENGINE error message.
- Page 24 PAGE 24 OF 24 INSTALLATION CHECKLIST - 1 OF 1 • 20160224 DOC.: #26841 CHECKLIST WARNING: Vehicle engine will start many times. Test in a well ventilated area. Close all vehicle doors, hood and trunk. Press LOCK button three times [3x] rapidly on the OEM keyfob to remote start vehicle. Question 1: Does the vehicle remote start? YES: Go to next step.
