Large Display
Salinity &
Conductivity Pens
850036 & 850037

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Large Display Salinity Pen - 850036 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sper scientific Large Display Salinity Pen - 850036

Summary of Contents for Sper scientific Large Display Salinity Pen - 850036

  • Page 1 Large Display Salinity & Conductivity Pens 850036 & 850037...
  • Page 2 Sper Scientific. Sper Scientific 8281 E. Evans Rd., Suite #103 Scottsdale, AZ 85260 (480) 948-4448...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION ... . . 4 FEATURES....5 MATERIALS SUPPLIED ..5 POWER SUPPLY .

  • Page 4: Introduction

    INTRODUCTION The Sper Scientific Large Display Salinity (Model 850036) and Conductivity (Model 850037) Pens provide highly stable and accurate readings with a large LCD that simultaneously displays the parameter being measured and temperature in °C or °F. The pens are designed for simple one-hand operation.

  • Page 5: Features

    FEATURES • IP65 waterproof housing • Dual display with ATC • Data hold • Pen size for portability • Built-in probe with protective cap • One touch, multi-point calibration • Auto-power-off • Low battery indicator MATERIALS SUPPLIED • 4 LR44 button cell batteries •...

  • Page 6: Power Supply

    POWER SUPPLY The pen is powered by 4 LR44 batteries. Check the batteries when: • Using the unit for the first time • The low battery indicator appears on the LCD • The pen will not turn on LCD DISPLAY LCD DISPLAY Hold data on the LCD Calibration Mode...

  • Page 7: 850036 Salinity Pen

    Large Display Salinity Pen 850036...

  • Page 8: Set Up

    SETUP MODE The advanced Setup Mode allows you to customize the pen’s preferences and defaults: 1. Press SET to turn the pen on. 2. From Measurement Mode, press SET for more than 2 seconds to enter Setup Mode and change parameters. Temperature Units (tUt) To select the Celsius or Fahrenheit temperature scale:...
  • Page 9 5. When in P1.0, press ▲ to advance to the next setup function or press SET for more than 2 seconds to return to Measurement Mode. SETUP MODE Press Press and hold Resetting the Pen (rSt) When the pen is reset, all parameters for less will be reset to factory default values.
  • Page 10 5. Press SET for less than one second to confirm the selection or press SET for more than 2 seconds to return to P3.0 without saving. 6. When in P3.0, press ▲ to advance to the next setup function or press SET for more than 2 seconds to return to Measurement Mode.
  • Page 11 Range 2 Calibration Information: 4. When in P4.1, press ▲ to enter P4.2 to review the last calibration concentration. If range 2 is not yet calibrated, “---” will appear on the LCD. 5. When in P4.1 or P4.2, press SET for less than one second to confirm and return to P4.0.

  • Page 12: Calibration

    To manually select the measurement range: 1. Press SET to turn the pen on. 2. Press ▲ for more than 2 seconds to select range 1. Press ▲ for more than 2 seconds to select range 2. CALIBRATION Selecting the Calibration Standard Solution For best results, select a NaCl standard near the sample value that you are...
  • Page 13 the pen will retain the calibration data for other ranges that have not yet been re-calibrated. Selecting the Calibration Schedule Calibration is necessary and should be performed regularly. Soak the probe for 15 minutes before calibration or measurement to minimize drift. If the pen is used in the mid ranges, calibrate the unit monthly.
  • Page 14 Salinity Calibration 1. Place the probe into deionized or distilled water for about 30 minutes to rinse the probe. 2. Select the NaCl standard for calibration. 3. Pour 3 cm (deep) of solution into two separate containers (A & B). 4.
  • Page 15 9. When “CAL” stops flashing on the LCD, press SET for less than 1 second to confirm the value. The pen will return to Measurement Mode for salt measurement. To exit Calibration Mode without saving, press SET for more than 2 seconds.

  • Page 16: Measurement Procedures

    MEASUREMENT PROCEDURES 1. Remove the probe cover from the pen. 2. Press SET to turn the pen on. 3. The pen defaults to auto-ranging mode. The auto-ranging function determines and selects a range that will provide the greatest resolution and accuracy. 4.
  • Page 17 5. Rinse the probe tip with de-ionized or distilled water before use to remove any impurities adhering to the probe. If the probe tip is dehydrated, soak it for 30 minutes to prevent contaminants from slowing down the measurement and accuracy. 6.
  • Page 18 2. Press HLD again to release the hold function. Turning the Pen Off 1. Press SET to turn the pen off from Measurement Mode. 2. To turn the pen off from Setup Mode, press SET for more than 2 seconds to return to Measurement Mode, then press SET again.

  • Page 19: Specifications

    SPECIFICATIONS ±1% Full Scale ± 1 digit (0.0-10.0 ppt) Accuracy or ±2% Full Scale ±1 digit (10.1-70.0 ppt) 0.00-10.00 ppt (NaCl) Range or 10.1-70.0 ppt (NaCl) Resolution 0.01 ppt or 0.1 ppt Calibration One point per range Built-in NaCl conductivity TDS Factor to TDS factor Temperature...

  • Page 20: Error Codes

    Put the pen in standard buffer solution (the buffer concentration must be lower than the range limit). If E03 still appears, send the pen to Sper Scientific for repair. E04 Error in measuring original data (damaged temperature sensor, temperature out of specifications or salinity error).
  • Page 21 Sper Scientific for repair. The temperature value is above the range limit (50°C) or the temperature circuit is damaged; Place the pen in room temperature for 5 minutes, if E03 still appears, send the pen to Sper Scientific for repair.

  • Page 23: 850037 Conductivity Pen

    Large Display Conductivity Pen 850037...

  • Page 24: Set Up

    SETUP MODE The advanced Setup Mode allows you to customize the pen’s preferences and defaults: 1. Press SET to turn the pen on. 2. From Measurement Mode, press SET for more than 2 seconds to enter Setup Mode and change parameters.
  • Page 25 Temperature Units (tUt) To select the Celsius or Fahrenheit temperature scale: 1. Press SET for 2 seconds to enter setup. 2. “t” will appear on the primary display of the LCD and “P1.0” will appear on the secondary display. 3. Press SET again for less than one second to enter the unit setting.
  • Page 26 Reference (Normalization) Temperature (tnr) After saving the temperature unit setting, the pen will automatically enter the reference temperature setup. 1. Press ▲ to select 20°C or 25°C. 2. Press SET for less than one second to confirm the value or press SET for more than 2 seconds to return to P1.0 without saving.
  • Page 27 Temperature Coefficient (tCo) 1. Press ▲ or ▼ to change the temperature coefficient from 0.0 to 4.0. 2. Press SET for less than one second to confirm the value or press SET for more than 2 seconds to return to P1.0 without confirming the temperature coefficient value.
  • Page 28 Resetting the Pen (rSt) When the pen is reset, all parameters (including calibration information) will be reset to factory default values. 1. Press SET for 2 seconds to enter setup. 2. Press ▲ to select the reset pen setting. “rst” will appear on the main display of the LCD and “P3.0”...
  • Page 29 Calibration Review (CAL) 1. Press SET for 2 seconds to enter setup. 2. Press ▲ to select the calibration review setting. “CAL” will appear on the primary display of the LCD and “P4.0” will appear on the secondary display. Range 1 Calibration Information: 3.
  • Page 30 P4.1 and P4.2 Modes allow review of the calibration information but are not used during the calibration procedure. When in Temperature Parameter (P1.0), Resetting the Pen (P3.0) or Calibration Review (P4.0) Setup Modes, press SET for more than 2 seconds to return to Measurement Mode.
  • Page 31 Selecting the Measurement Range (rAn) There are two measurement ranges. The pen defaults to auto-ranging Conductivity 0 to 1999 µS Range 1 0 to 19.99 mS Range 2 To manually select the measurement range: 1. Press SET to turn the pen on. 2.

  • Page 32: Calibration

    CALIBRATION Selecting the Calibration Standard Solution For best results, select a conductivity standard near the sample value that you are measuring. Alternatively, use a calibration solution value that is approximately 2/3 of the full scale of the measurement range that you plan to utilize.
  • Page 33 Conductivity Recommended Cal. Measuring Range Solution Range µ µ 0 to 1999 600 to 1700 0 to 19.99 mS 6.0 to 17.00 mS The previous calibration data will be replaced after re-calibrating. For example, if you previously calibrated the conductivity pen at 1413 µS in the 0 to 1999 µS range, when you re-calibrate at 1500 µS again (also in the 0 to 1999 range), the previous...
  • Page 34 The default value of the reference temperature is set at 25°C. To normalize to a different value, see page 33. Determine the calibration standard value for your reference temperature before resetting the reference temperature. Contact the solution distributor for the calibration standard value of the solution.
  • Page 35 Conductivity Calibration CALIBRATION 1. Place the probe into deionized or 3. Pour 3 cm (deep) of buffer solution distilled water for about 30 minutes to into two separate containers (A & B). rinse the probe. 2. Select the conductivity standard for 4.
  • Page 36 7. Press CAL for more than 2 seconds to begin calibration. The conductivity value of the solution will flash on the LCD. 8. Press ▲ or ▼ to adjust the value on the primary display to match the value of the standard buffer. You can adjust the conductivity reading ±...
  • Page 37 Although the values differ less than 30%, the 22 µS is still over the range limit. The maximum input value is 19.99 µS. Example 2: Standard: 1.6 mS; Detected value: 2.1 mS Adjustable range: ± 0.63 mS (2.1*30%) Although the measured value differs less than 30%, the 1.6 mS is still less than the 10% range limit (1.99).

  • Page 38: Measurement Procedures

    Note… When the pen is switched from Measurement Mode to Calibration Mode, it will display the factory default value. Therefore, if the pen was previously calibrated, the display may appear to jump to the factory default value when entering Calibration Mode MEASUREMENT PROCEDURES 1.
  • Page 39 2. Press SET to turn the pen on. 3. The pen defaults to auto-ranging mode. The auto-ranging function determines and selects a range that will provide the greatest resolution and accuracy. 4. The pen also provides a manual range option. For example, to view a reading of 0.50 mS rather than 500 µS: From Measurement Mode, press ▲...
  • Page 40 5. Set the temperature coefficient to the correct value. The pen defaults to 2.1% per °C, which will typically provide good results. See page 27 to reset the temperature coefficient. 6. Select the reference temperature. The pen defaults to 25°C. To more than 2 seconds to select the 19.99 mS range.
  • Page 41 9. Stir the probe gently to create a uniform sample. Wait about 15 minutes for the reading to stabilize. 10. The unit of measure will flash on the LCD to indicate that the pen is in Measurement Mode. When the reading is stable, the unit of measure will stop flashing.

  • Page 42: Specifications

    SPECIFICATIONS ± 1% Full Scale Accuracy ± 1 digit 0 to 1999 µS or Range 0 to 19.99 mS Resolution 1 µS or 0.01 mS Temperature ± 2°F Accuracy ± 1°C Temperature 0.1°C/°F Resolution Calibration One point per range Temperature 0 to 4.0%/°C Coefficient Reference...

  • Page 43: Error Codes

    Put the pen in standard buffer solution (the buffer concentration must be lower than the range limit). If E03 still appears, send the pen to Sper Scientific for repair. Error in measuring original data (damaged temperature sensor or...
  • Page 44 Sper Scientific for repair. The temperature value is above the range limit (50°C) or the temperature circuit is damaged; Place the pen in room temperature for 5 minutes, if E03 still appears, send the pen to Sper Scientific for repair.

  • Page 45: Appendices

    Appendices...
  • Page 46 APPENDIX A: Program Function Default Note P1.1 Select °C/°F °C Temp unit P1.2 Reference 25°C Selectable Temperature 25°C or 20°C P1.3 Temperature 2.1% Adjustable Coefficient /°C 0.4 to 10% P3.1 Factory Retain Default your current settings P4.1 Viewing ---- No cal previous data for calibration...
  • Page 47 APPENDIX B: Temperature Effect Conductivity measurements are temperature dependent; if the temperature increases, conductivity increases. For example, the conductivity measured in a 0.01 M KCl solution at 20°C is 1.273 mS/ cm, whereas at 25°C, it is 1.409 mS/cm. The concept of reference temperature (normalization temperature) was introduced to allow the comparison of conductivity results obtained at...
  • Page 48 is the value taken at the measurement temperature. The Large Display Salinity (Model 850036) and Conductivity (Model 850037) Pens automatically use linear temperature correction. Linear Temperature Correction In moderately and highly conductive solutions, temperature correction can be based on a linear equation involving a temperature coefficient (θ).
  • Page 49 Note… The correction is accurate only within a limited temperature range around T1 and T2. The greater the difference between T and Tref, the higher the risk of error. Calculating Temperature Coefficients (θ) By measuring the conductivity of a sample at temperature T1 close to Tref and another temperature T2, you can calculate the temperature coefficient by APPENDICES...
  • Page 50 Acids: 1.0 - 1.6%/°C Bases: 1.8 - 2.2%/°C Salts: 2.2 - 3.0%/°C Drinking water: 2.0%/°C Ultra-pure water: 5.2%/°C...
  • Page 51 Battery Replacement, Maintenance, & Troubleshooting...

  • Page 52: Battery Replacement

    BATTERY REPLACEMENT 1. Press SET to turn the pen off. 2. Remove the battery cover located on the top of the unit by rotating counterclockwise. Do NOT discard the black washer. 3. Remove the old batteries and replace with 4 new LR44 batteries, ensuring correct polarity.

  • Page 53: Maintenance

    MAINTENANCE Ensure that the probe is clean before use and storage. To clean: 1. Remove the probe cap. 2. Rinse the probe carefully in deionized water, replace the cap, and store dry in an environment of 0 to 50°C. Note… If the probe has been exposed to a solvent that is immiscible with water, clean the probe with a solvent that is miscible with...

  • Page 54: Troubleshooting

    TROUBLESHOOTING Pen does not turn on: 1. Press SET for more than 1 second. 2. Check that the batteries are in place, making good contact, and placed with correct polarity. 3. Replace with new batteries and try again. 4. Remove the batteries for one minute and then replace the batteries.
  • Page 55 To remove the air bubbles: 1. Stir the probe. 2. Dip the probe into the solution at an oblique angle (at a slant, not perpendicular to solution). Dipping the probe perpendicularly will cause air bubbles to form. 3. Soak the probe in solution for 15-30 minutes.

  • Page 56: Warranty

    WARRANTY Sper Scientific warrants this product against defects in materials and workmanship for a period of one (1) year from the date of purchase, and agrees to repair or replace any defective unit without charge. If your model has since been discontinued, an equivalent Sper Scientific product will be substituted if available.
