GV-Data Capture V2

8. Run POS Server Setup. (Look under GV-System/Configure/POS
Application Setting/POS Device Setup)
9. Click the New button in the POS Server Setup window.
10. In the POS Module drop-down list, select the POS module you created in
TranStopEdit.
Figure 3 Selecting the created POS module
11. Click Add, and test this setting.
12

Connecting more than 2 POS systems/cash registers

Normally, one PC comes with 2 COM ports so that only 2 POS systems/cash
registers may be supported without COM port extension. Now the extension
is possible by using GV-Hub.
One GV-Hub can connect up to 4 GV-Data Capture boxes, as illustrated below.
RS232 RS485
POS system 1 GV-Data Capture 1
RS232 RS232
POS system 4 GV-Data Capture 4
The displayed transaction item did not match that entered at
the POS system/cash register
1. Run POS Server Setup. (Look under GV-System/Configure/POS
Application Setting/POS Device Setup)
2. Click the New button in the POS Server Setup window.
GV-Data Capture V2
USB
GV-Hub
GV-System
13
