c. Select the Promira device which was found, and click OK.
6. In order to start the Advanced Cable Tester application on the Promira platform
you must enable it as the "Auto Start App:" by clicking on the pulldown.
a. Choose "com.totalphase.promact_cab" in the list, and click Apply.
b. Note the IP address shown in the window. This is the address of the device
that you will need below in the process.
c. Power-cycle the Promira by unplugging the USB cable, and plugging it back
in.
d. Wait for the Promira platform's right LED to go from RED to BLUE and finally
to GREEN.
6.3 Testing USB Type-C™ Cables
1. Open a web browser, and navigate to http://<ip-address-from-above>/
For example, assuming the IP shown was 10.1.4.233, then the URL would be
http://10.1.4.233/
Advanced Cable Tester User Manual v1.13.001
If it doesn't appear yet, wait a little while for it to finish booting and
enumerating, then click the
button to refresh the list.
28
