Total Phase Advanced Cable Tester User Manual page 20

VCONN: Presence of the VCONN pulldown in the cable plug.
VCONN Thru: Presence of the VCONN wire through the cable. A cable that
has this is not Type-C compliant. This test is recommended as Absent /
Required.
DP/DM1: Presence of the USB2 wire pair, also known as D+/D-. These
wires are required for all Type-C cables. This test is recommended as
Present / Required.
DP/DM2: Presence of a second USB2 wire pair, also known as D+/D-.
These wires are prohibited for Type-C cables. This test is recommended as
Absent / Required.
SS TX1 / SS TX2 / SS RX1 / SS RX2: Presence of each of the four
SuperSpeed wire pairs: SSTX1, SSTX2, SSRX1, SSRX2. These wire pairs
are required for Full-Featured Type-C cables.
E-Marker: This section defines E-Marker parameter validation. If an E-Marker is present
in the cable, then the identity VDOs are read, and compared to the parameters specified
here. If the checkbox for a given item is checked, then the associated parameter must
match.
Product: Product type as specified in the ID Header VDO. Can be either
Passive Cable or Active Cable.
Speed: USB SuperSpeed Signaling Support as specified in the Cable VDO.
Can be USB 2.0 only, USB 3.1 Gen 1, or USB 3.1 Gen 1 and Gen 2.
Current: VBUS Current Handling Capability as specified in the Cable VDO.
Can be either 3A or 5A.
Vendor ID: USB Vendor ID as specified in the ID Header VDO.
Vendor Name: Vendor Name as specified in the USB.org and the linux.org
vendor lists.
Product ID: USB Product ID as specified in the Product VDO.
Test ID: USB Test ID (XID) as specified in the Cert Stat VDO.
HW Ver: Hardware Version as specified in the Cable VDO.
FW Ver: Firmware Version as specified in the Cable VDO.
