  • Page 1 USB Mix 4 mixer user manual...
  • Page 2 Musikhaus Thomann Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 19.09.2018, ID: 441270...
  • Page 3: Table Of Contents

    1.1 Further information......................4 1.2 Notational conventions....................4 1.3 Symbols and signal words................... 4 Safety instructions......................... 6 Features............................8 Installation..........................9 Connections and controls....................10 Technical specifications....................13 Plug and connection assignment................. 14 Protecting the environment................... 16 USB Mix 4...
  • Page 4: General Information

    Our products are subject to a process of continuous development. Thus, they are subject to change. 1.1 Further information On our website (www.thomann.de) you will find lots of further information and details on the following points: Download This manual is also available as PDF file for you to download.
  • Page 5 This combination of symbol and signal word indicates a possible dangerous situation that can result in mate‐ rial and environmental damage if it is not avoided. Warning signs Type of danger Warning – high-voltage. Warning – danger zone. USB Mix 4...
  • Page 6: Safety Instructions

    Safety instructions Safety instructions Intended use This device is intended to be used for amplification, mixing and playback of signals from musical instruments and microphones. Use the device only as described in this user manual. Any other use or use under other operating conditions is considered to be improper and may result in personal injury or property damage.
  • Page 7 Failure to do so could result in damage to the device and possibly injure the user. Unplug the device before electrical storms occur and when it is unused for long periods of time to reduce the risk of electric shock or fire. USB Mix 4...
  • Page 8: Features

    Features Features 4-channel DJ mixer with USB player 4 stereo inputs (3 × phono / line, 1 × line / mic) 1 × microphone input (XLR) 1 × headphones output (stereo, as 1/4" phone jack) 1 × master output (RCA sockets) 1 ×...
  • Page 9: Installation

    Create all connections while the device is off. Use the shortest possible high-quality cables for all connections. Take care when running the cables to prevent tripping hazards. Connection options USB Mix 4...
  • Page 10: Connections And Controls

    Connections and controls Connections and controls Front panel 1 [MIC 1] Microphone input, designed as XLR / 1/4" phone combo socket 2 [TREBLE] Rotary treble control for the microphone input signal. 3 [BASS] Rotary bass control for the microphone input signal. 4 [TALKOVER] Enables the Talk over function.
  • Page 11 Slider for mixing the signals of the left and right channel If the controller is in middle position, both channels can be heard. 15 [MIC 1] Volume control for microphone 1. 16 [MASTER LEVEL] Level meter shows the volume of the output channel or the currently selected solo channel. USB Mix 4...
  • Page 12 Connections and controls Rear panel 17 IEC chassis plug for operating voltage supply with fuse holder. Should the fuse have blown, disconnect the unit from the power supply and replace the fuse with a new fuse of the same type. 18 [MASTER] Master output for connecting an amplifier or powered speaker box, designed as RCA sockets.
  • Page 13: Technical Specifications

    0.02 % Operating supply voltage 230 V 50 Hz Fuse 5 mm × 20 mm, 500 mA, 250 V, slow-blow Dimensions (W × H × D) 382 mm × 220 mm × 130 mm Weight 2.6 kg USB Mix 4...
  • Page 14: Plug And Connection Assignment

    Plug and connection assignment Plug and connection assignment Introduction This chapter will help you select the right cables and plugs to connect your valuable equipment in such a way that a perfect sound experience is ensured. Please note these advices, because especially in ‘Sound & Light’ caution is indicated: Even if a plug fits into the socket, an incorrect connection may result in a destroyed power amp, a short circuit or ‘just’...
  • Page 15 Plug and connection assignment XLR plug (balanced) Ground, shielding Signal (in phase, +) Signal (out of phase, –) Shielding on plug housing (option) RCA connection Drawing and table indicate the pin assignment of an RCA plug. Signal Ground, shielding USB Mix 4...
  • Page 16: Protecting The Environment

    Protecting the environment Protecting the environment Disposal of the packaging material For the transport and protective packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling.
  • Page 17 Notes USB Mix 4...
  • Page 18 Notes mixer...
  • Page 20 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
