Bosch DS306E Installation Instructions

Other Information
Perform maintenance annually. Check the
range and coverage according to the Setup
and Walk Testing instructions.
Ensure continual daily operation by instruct-
ing the end user to daily walk through the
outer edge of the coverage pattern. This as-
sures an alarm output before arming.
Mirror Information
The mirror is adjustable from +2° to -18°
vertically and from +10° to -10° horizontally.
Change the mirror by pulling it out from its
resting grooves.
© 2004 Bosch Security Systems
130 Perinton Parkway, Fairport, New York, USA 14450-9199
Customer Service: (800) 289-0096; Technical Support: (888) 886-6189
Coverage Patterns
This product is factory assembled with the
look down zones (O, P, and Q) masked out. If
you want to use these zones, remove the
masking tape from the lens.
Remove the mask by
peeling back the tab.
J K L M N
A B C D E F G H I
Broad Coverage
Top View
0 15
Meters
B Mirror Segment
25 7.5
to Pattern Reference
A
O P Q
D
J
+2
C
M
0
O K -8
e
F J K L M N
-16
t
e P
E 0
L
0 e
e
r
t Q
M
s
G
A B C D E F G H I
N
F
I
25 7.5
H
0 Feet 50 View of Front
Polished Surface
Side View
0 15
Meters M
10 3
F e
e t
5
e e
0
0
t r
0 50
Feet
s
O-Q J-N A-I
Mirror adjusted to -5°
Barrier Coverage (OMB77)
Top View
0 Meters
25
10
3
M Mirror Segment
I
F K
C A e
G E
to Pattern Reference
e
0 t
0
K L
e H F
D e
B
L J
t
r
+2
10 3
s
0 I J
-8
0 Feet 80
-16
G H
E
C D
0 Side View
Meters 25
M
e
10 3
F
A
t
e 5
e
e
0 0
r
t
View of Front
s
0 Feet
80
Polished Surface
A-B
K-L I-J G-H E-F C-D
Mirror adjusted to -2°
Long Range Coverage (OMLR77)
Top View
Meters
0
5
F
e
0
e
t 5
0
Feet
120
Side View
0 Meters
10
F
e
e
0
t
0
Feet
120
A
E D C B
Mirror adjusted to -1°
DS306E Installation Instructions
P/N: 28831F Page 4
Installation Instructions
for the
DS306E ASIC Based
Passive Infrared
Intrusion Detector
Specifications
• Input Power: 6 VDC to 15 VDC; 15 mA
at 12 VDC
• Standby Power: There is no internal
standby battery. Connect to DC power
sources that can supply standby power if
the primary power fails. For each hour of
standby time that is needed, 15 mAh is
required.
+2
0
• Coverage:
-8
-16
Broad (standard): 15 m by 15 m
(50 ft by 50 ft)
*
Barrier : 25 m by 5 m (80 ft by 16 ft)
*
Long Range : 40 m by 3 m
(120 ft by 10 ft)
*
Barrier and Long Range mirrors are
available as options.
• Sensitivity: Adjustable for Standard,
Intermediate, or High.
• Alarm Relay: Normally closed reed relay
with contacts that are rated at 28 VDC,
+2
0
-8
125 mA maximum for DC resistive loads.
-16
F
• Tamper Switch: Normally closed (with
B
cover in place) tamper switch. Contacts
area rated at 28 VDC, 125 mA maximum.
• Temperature: The storage and operating
range is -20°F to +120°F (-29°C to +49°C).
• Options: B328 Gimbal Mount Bracket,
40
1.5
M
e
B333 Swivel Bracket, TC6000 Test
0
t
e
1.5
r
Cord, OMB77-3 Barrier Mirror, and
s
OMLR77-3 Long Range Mirror.
40
3 M
e
• U.S. Patent Numbers: 4,764,755 and
t
0 e
r
5,083,106
s
03/04
Chassis
Screw
T-Strip
1 2 3
Configuration
Switches
OFF
Noise
Voltage
LED
Tamper
Switch
Circuit Board Components
Surface Mounting Hole
Corner Corner
Mounting Mounting
Bracket
Hole Hole
Mounting Hole
Surface Mounting Hole
Detector Enclosure
Avoid
Direct Hot and Cold Drafts, Windows,
Small Animals, Air Conditioner Outlets,
Heat Sources, Direct Sunlight
Remember
Does not detect through glass.
Best catch performance is across
the pattern.
When using two or more detectors,
cross patterns for best coverage.
