Input Terminal Module
FA-TH16XRA20S,FA-TH16X100A31,FA-TH16X200A31,
FA-TH16X24D31,FA-TH16X100A31L,FA-TH16X200A31L,
FA-TH16X24D31L,FA-TH16X48D31L,FA-TH16X100D31L
Thank you for purchasing the FA Goods products.
Before using the products, please read this manual and the relevant manuals carefully to
handle the products correctly.
Before using the products, please read this manual and the relevant manuals carefully, and pay full
attention to safety to handle the products correctly.
The precautions given in this manual are concerned with the FA Goods products only.
For the safety precautions of the programmable controller system, refer to the user's manual for the
programmable controller used.
In this manual, the safety precautions are classified into two levels: "
WARNING
CAUTION
Under some circumstances, failure to observe the precautions given under "
to serious consequences.
Observe the precautions of both levels because they are important for personal and system safety.
SAFETY PRECAUTIONS
(Read these precautions before using the FA Goods products.)
Indicates that incorrect handling may cause hazardous
conditions, resulting in death or severe injury.
Indicates that incorrect handling may cause hazardous
conditions, resulting in minor or moderate injury or
property damage.
User's Manual
WARNING" and "
1
CAUTION".
CAUTION" may lead
