PREPARE
1
Using a 30mL syringe,
draw 3mL of ACD-A,
followed by 27mL of
blood.
2
Align and connect
Disposable Unit
to
Centrifuge
.
3
Transfer blood into
Disposable Unit using
cannula. Remove cannula.
PEAK
PLATELET RICH PLASMA SYSTEM
TM
USER QUICK GUIDE
SEPARATE
4
Press
to start 60 second
centrifugation.
5
to 1 for RBC
Rotate
removal.
6
When the bu y coat is
between the two
horizontal RBC Removal
Stop Lines, move
7
Rotate
to 2 for platelet
poor plasma removal for 15
seconds.
8
Rotate
to
centrifugation process.
9
to
.
10
to end
WITHDRAW PRP
Attach new sterile cannula
to 10mL syringe and
remove PRP.
Press release button on
rear of Centrifuge to
detach and dispose of
Disposable Unit.
Advertisement
Related Manuals for Synthes PEAK
Summary of Contents for Synthes PEAK
- Page 1 PEAK PLATELET RICH PLASMA SYSTEM USER QUICK GUIDE PREPARE SEPARATE WITHDRAW PRP Using a 30mL syringe, Press to start 60 second Attach new sterile cannula draw 3mL of ACD-A, centrifugation. to 10mL syringe and followed by 27mL of remove PRP.
- Page 2 DSM Biomedical 735 Pennsylvania Dr. Exton, PA 19341 USA www.dsm.com/medical The PEAK PRP System is intended to be used for the safe and rapid preparation Distributed by: of autologous platelet-rich-plasma (PRP) from a small sample of blood DePuy Mitek, Inc collected at the patient’s point of care.
