The LED indicates that wireless data transfer activity is in progress. This LED is
not used in the current firmware.
General Purpose Header
Pin
number Pin name
1 SPI_READY
2 NC
3 RESET_N
4 NC
5 WAKEUP
6 PT_GPIO2
7 ADC2
8 PT_GPIO1
9 GND
10 VCC
11 ADC1
Redpine Signals, Inc.
R S - W C - 3 0 1
R S - W C - 3 0 1
a a t t i i o o n n B B o o a a r r d d U U s s e e r r G G u u
V e r s i o n 2 . 5 1
V e r s i o n 2 . 5 1
Direction
Output
-
Input
-
Input
Output
Input
Output
-
Power
Input
i i d d e e
Description
Handshake signal used in SPI
mode and connected to a GPIO
pin of the Host MCU. In other
modes, this signal can be left
open
No connect
Active low reset input. This can
be connected to the Host MCU to
reset the module from the Host.
If not used, should be left open
No connect
The module wakes up from sleep
if a logic high is driven into this
pin. Used only in SPI mode,
should be left open in UART
mode
Pass through output pin
controllable by Host software.
Not used in current firmware,
should be left open
Analog input to internal ADC. Not
used in current firmware, should
be left open
Pass through output pin
controllable by Host software.
Not used in current firmware,
should be left open
Ground
3.3V power supply. If the USB
port for power supply is not
used, this pin can be used to
drive power to the EVB from the
Host MCU platform. The direction
of the "Power Selection" switch is
ignored in this case. The
maximum current sourcing
capacity of the Host should be
500mA. If not used, this pin
should be left open
Analog input to internal ADC. Not
used in current firmware, should
