Summary of Contents for Supermicro SC829TQ-R920LPB

  • Page 1 SC829 C hASSiS ERiES SC829TQ-R920LPB SC829TQ-R920UB SC829BTQ-R920WB USER’S MANUAL Revision 1.0a...
  • Page 2 This product, including software and documentation, is the property of Supermicro and/or its licensors, and is supplied only under a license. Any use or reproduction of this product is not allowed, except as expressly permitted by the terms of said license.
  • Page 3 This document lists compatible parts available when this document was published. Refer to the Supermicro web site for updates on supported parts and configurations. This manual may be periodically updated without notice. Please check the Supermicro Web site for possible updates.

  • Page 4: Table Of Contents

    SC829 Chassis Manual Contents Contacting Supermicro ....................7 Chapter 1 Introduction Overview ......................1-1 Shipping List ....................1-1 Chassis Features .................... 1-2 CPU ......................... 1-2 Hard Drives ..................... 1-2 I/O Expansion slots ..................1-2 Peripheral Drives ..................... 1-2 Other Features ....................1-2 Returning Merchandise for Service..............
  • Page 5 Preface Chapter 4 System Interface ..............4-1 Overview ......................4-1 Control Panel Buttons ..................4-2 Control Panel LEDs ..................4-2 Drive Carrier LEDs ..................4-4 SAS/SATA Drives .................... 4-4 Chapter 5 Chassis Setup and Maintenance ........... 5-1 Overview ......................5-1 Installation and General Maintnenance ............5-1 Installation .......................
  • Page 6 SC829 Chassis Manual Installing the System into a Rack ..............6-4 Identifying the Sections of the Rack Rails ............6-4 Releasing the Inner Rail ................. 6-5 Installing the Inner Rails on the Chassis ............6-6 Installing the Outer Rails onto the Rack ............6-7 Sliding the Chassis onto the Rack Rails ............

  • Page 7: Contacting Supermicro

    Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML...
  • Page 8 SC829 Chassis Manual Notes...

  • Page 9: Chapter 1 Introduction

    Chapter 1 Introduction Overview Supermicro’s SC829 2U chassis features a unique and highly-optimized design. The chassis is equipped with high efficiency power supply. Shipping List Please visit the following link for the latest shipping lists and part numbers for your particular chassis model visit the Supermicro Web site at www.supermicro.com.

  • Page 10: Chassis Features

    SC829 Chassis Manual Chassis Features The SC829 2U, high-performance chassis includes the following features: The chassis supports a dual-core Xeon processor. Please refer to the motherboard specifications pages on our Web site for updates on supported processors. Hard Drives The chassis features eight drive bays for SAS/SATA hard drives which support SES2.

  • Page 11: Returning Merchandise For Service

    For faster service, RMA authorizations may be requested online (http://www. supermicro.com/support/rma/). Whenever possible, repack the chassis in the original Supermicro carton, using the original packaging material. If these are no longer available, be sure to pack the chassis securely, using packaging material to surround the chassis so that it does not shift within the carton and become damaged during shipping.
  • Page 12 SC829 Chassis Manual Notes...

  • Page 13: Chapter 2 Standardized Warning Statements For Ac Systems

    Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our web site at http://www.supermicro.com/ about/policies/safety_information.cfm. Warning Definition Warning! This warning symbol means danger.
  • Page 14 SC829 Chassis Manual Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut.
  • Page 15 Chapter 2: Warning Statements for AC Systems ‫جسذٌة‬ ‫اصابة‬ ً‫تتسبب ف‬ ‫حالة ٌوكي أى‬ ً‫اًك ف‬ ‫خطز‬ ًٌ‫ٌع‬ ‫هذا الزهز‬ !‫تحذٌز‬ ‫الذوائز‬ ‫بالوخاطز الٌاجوة عي‬ ‫ي على علن‬ ، ‫ك‬ ‫هعذات‬ ‫تعول على أي‬ ‫قبل أى‬ ‫الكهزبائٍة‬ ‫حىادث‬ ‫أي‬ ‫وقىع‬ ‫وٌع‬...

  • Page 16: Installation Instructions

    SC829 Chassis Manual Installation Instructions Warning! Read the installation instructions before connecting the system to the power source. 設置手順書 システムを電源に接続する前に、 設置手順書をお読み下さい。 警告 将此系统连接电源前,请先阅读安装说明。 警告 將系統與電源連接前，請先閱讀安裝說明。 Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación.

  • Page 17: Circuit Breaker

    Chapter 2: Warning Statements for AC Systems Circuit Breaker Warning! This product relies on the building's installation for short-circuit (overcurrent) protection. Ensure that the protective device is rated not greater than: 250 V, 20 A. サーキッ ト ・ ブレーカー この製品は、 短絡 （過電流） 保護装置がある建物での設置を前提としています。 保護装置の定格が250 V、...

  • Page 18: Power Disconnection Warning

    SC829 Chassis Manual 경고! 이 제품은 전원의 단락(과전류)방지에 대해서 전적으로 건물의 관련 설비에 의존합니다. 보호장치의 정격이 반드시 250V(볼트), 20A(암페어)를 초과하지 않도록 해야 합니다. Waarschuwing Dit product is afhankelijk van de kortsluitbeveiliging (overspanning) van uw electrische installatie. Controleer of het beveiligde aparaat niet groter gedimensioneerd is dan 220V, 20A.
  • Page 19 Chapter 2: Warning Statements for AC Systems auf den Chassisinnenraum zurückgreift, um Systemsbestandteile anzubringen oder zu entfernen. ¡Advertencia! El sistema debe ser disconnected de todas las fuentes de energía y del cable eléctrico quitado de los módulos de fuente de alimentación antes de tener acceso el interior del chasis para instalar o para quitar componentes de sistema.

  • Page 20: Equipment Installation

    SC829 Chassis Manual Equipment Installation Warning! Only trained and qualified personnel should be allowed to install, replace, or service this equipment. 機器の設置 トレーニングを受け認定された人だけがこの装置の設置、 交換、 またはサービスを許可 されています。 警告 只有经过培训且具有资格的人员才能进行此设备的安装、更换和维修。 警告 只有經過受訓且具資格人員才可安裝、更換與維修此設備。 Warnung Das Installieren, Ersetzen oder Bedienen dieser Ausrüstung sollte nur geschultem, qualifiziertem Personal gestattet werden.

  • Page 21: Restricted Area

    Chapter 2: Warning Statements for AC Systems Waarschuwing Deze apparatuur mag alleen worden geïnstalleerd, vervangen of hersteld door geschoold en gekwalificeerd personeel. Restricted Area Warning! This unit is intended for installation in restricted access areas. A restricted access area can be accessed only through the use of a special tool, lock and key, or other means of security.

  • Page 22: Battery Handling

    SC829 Chassis Manual ‫אזור עם גישה מוגבלת‬ !‫אזהרה‬ ‫יש להתקין את היחידה באזורים שיש בהם הגבלת גישה. הגישה ניתנת בעזרת‬ .)'‫כלי אבטחה בלבד (מפתח, מנעול וכד‬ ‫محظورة‬ ‫مناطق‬ ٍ‫نتركُبها ف‬ ‫هذه انىحذة‬ ‫تخصيص‬ ‫تم‬ ،‫أداة خاصت‬ ‫من خالل استخذاو‬ ‫فقط‬ ‫محظورة‬...
  • Page 23 Chapter 2: Warning Statements for AC Systems Warnung Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp. Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers. Attention Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer que par une pile de type semblable ou équivalent, recommandée par le fabricant.

  • Page 24: Redundant Power Supplies

    SC829 Chassis Manual Redundant Power Supplies Warning! This unit might have more than one power supply connection. All connections must be removed to de-energize the unit. 冗長電源装置 このユニッ トは複数の電源装置が接続されている場合があります。 ユニッ トの電源を切るためには、 すべての接続を取り外さなければなりません。 警告 此部件连接的电源可能不止一个，必须将所有电源断开才能停止给该部件供电。 警告 此裝置連接的電源可能不只一個，必須切斷所有電源才能停止對該裝置的供電。 Warnung Dieses Gerät kann mehr als eine Stromzufuhr haben. Um sicherzustellen, dass der Einheit kein trom zugeführt wird, müssen alle Verbindungen entfernt werden.

  • Page 25: Backplane Voltage

    Chapter 2: Warning Statements for AC Systems ‫امداد الطاقة‬ ‫بوحدات‬ ‫عدة اتصاالت‬ ‫جهاز‬ ‫ال‬ ‫يكون لهذا‬ ‫قد‬ ‫الكهرباء‬ ‫عن‬ ‫وحدة‬ ‫ال‬ ‫لعسل‬ ‫كافة االتصاالت‬ ‫يجب إزالة‬ 경고! 이 장치에는 한 개 이상의 전원 공급 단자가 연결되어 있을 수 있습니다. 이 장치에 전원을...

  • Page 26: Comply With Local And National Electrical Codes

    SC829 Chassis Manual ‫מתח בפנל האחורי‬ !‫הרה‬ ‫אז‬ ‫קיימת סכנת מתח בפנל האחורי בזמן תפעול המערכת. יש להיזהר במהלך‬ .‫העבודה‬ ‫اللىحة‬ ‫أوالطاقة المىجىدة على‬ ‫التيار الكهزبائي‬ ‫مه‬ ‫خطز‬ ‫هناك‬ ‫هذا الجهاس‬ ‫خدمة‬ ‫كه حذرا عند‬ ‫يعمل‬ ‫النظام‬ ‫عندما يكىن‬ 경고! 시스템이...

  • Page 27: Product Disposal

    Chapter 2: Warning Statements for AC Systems Attention L'équipement doit être installé conformément aux normes électriques nationales et locales. ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ ‫הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫התקנת‬ ‫المتعلقة‬ ‫المحلية والىطىية‬ ‫قىاويه‬ ‫يجب أن يمتثل لل‬ ‫الكهربائية‬...

  • Page 28: Hot Swap Fan Warning

    SC829 Chassis Manual ¡Advertencia! Al deshacerse por completo de este producto debe seguir todas las leyes y reglamentos nacionales. Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent.
  • Page 29 Chapter 2: Warning Statements for AC Systems 警告 危險的可移動性零件。請務必與轉動的風扇葉片保持距離。 當您從機架移除風扇裝 置，風扇可能仍在轉動。小心不要將手指、螺絲起子和其他物品太靠近風扇。 Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.

  • Page 30: Power Cable And Ac Adapter

    Verbindungskabeln, Stromkabeln und/oder Adapater, die Ihre örtlichen Sicherheitsstandards einhalten. Der Gebrauch von anderen Kabeln und Adapter können Fehlfunktionen oder Feuer verursachen. Die Richtlinien untersagen das Nutzen von UL oder CAS zertifizierten Kabeln (mit UL/CSA gekennzeichnet), an Geräten oder Produkten die nicht mit Supermicro gekennzeichnet sind. 2-18...
  • Page 31 ‫םילבכב שמתשהל רוסיא םייק ,תוחיטבה יקוחו למשחה ירישכמב שומישה יקוחל םאתהב‬ ‫ -ב םיכמסומה‬UL ‫-ב וא‬CSA (‫( לש דוק םהילע עיפומ רשאכ‬UL/CSA ‫ילמשח רצומ לכ רובע‬ ‫ י"ע םאתוה רשא רצומב קר אלא ,רחא‬Supermicro ‫.דבלב‬ ‫تالباكلا ءارشب مق وأ ةددحملا وأ ةرفوتملا تاليصوتلا مادختساب مق ،جتنملا بيكرت دنع‬...
  • Page 32 Het gebruik van niet geschikte Kabels en/of Adapters kan een storing of brand veroorzaken. Wetgeving voor Elektrische apparatuur en Materiaalveiligheid verbied het gebruik van UL of CSA -gecertificeerde Kabels (met UL/CSA in de code) voor elke andere toepassing dan de door Supermicro hiervoor beoogde Producten. 2-20...

  • Page 33: Chapter 3 Chassis Components

    DVD-ROM drive (optional) and a panel with one com port and two USB ports (optional). Hard drives must be purchased separately. For the latest shipping lists, visit our Web site at: http://www.supermicro.com. This chas- sis supports a 2U backplane, four fans and redundant power supplies.

  • Page 34: Power Supply

    Supermicro Authorized Distributors/ System Integrators/Resellers. A list of Supermicro Authorized Distributors/System Integrators/Reseller can be found at: http://www.supermicro.com. Click the Where to Buy link.

  • Page 35: Chapter 4 System Interface

    Chapter 4: System Interface Chapter 4 System Interface Overview There are several LEDs on the control panel and the drive carriers to keep you constantly informed of the over-all status of the system, as well as the activity and health of specific components. Most SC829 models have two buttons on the chas- sis control panel: a reset button and a power on/off button.

  • Page 36: Control Panel Buttons

    SC829 Chassis Manual Control Panel Buttons There are two push-buttons located on the front of the chassis. These are (in order from left to right) a reset button and a power on/off button. Reset: The reset button is used to reboot the system. Power: The main on/off button is used to apply or remove power from the power supply to the server.
  • Page 37 Chapter 4: System Interface Informational LED: Continuously on and blue: UID function has been activated. Flashing red: Fan failure. Continuously on and red: Overheat condition. This may be caused by cables obstructing the airflow in the system or the ambient room temperature being too warm.

  • Page 38: Drive Carrier Leds

    SC829 Chassis Manual Drive Carrier LEDs Your chassis uses SAS/SATA drives. SAS/SATA Drives Each SAS/SATA drive carrier has two LEDs. Green LED: Each SAS/SATA drive carrier has a green LED. When illuminated, this green LED (on the front of the SATA drive carrier) indicates drive activity. A connection to the SATA backplane enables this LED to blink on and off when that particular drive is being accessed.

  • Page 39: Chapter 5 Chassis Setup And Maintenance

    Chapter 5: Chassis Setup and Maintenance Chapter 5 Chassis Setup and Maintenance Overview This chapter covers the steps required to install components and perform mainte- nance on the chassis. The only tool you will need to install components and perform maintenance is a Phillips screwdriver.

  • Page 40: Removing The Chassis Cover

    SC829 Chassis Manual Removing the Chassis Cover Remove Screw Remove Screw Figure 5-1: Removing the Chassis Cover Removing the Chassis Cover 1. Power down the server and remove the power cord from the power supply. 2. Remove the two screws on each side of the cover, which secure the cover to the chassis.

  • Page 41: Installing Hard Drives

    Chapter 5: Chassis Setup and Maintenance Installing Hard Drives Figure 5-2: Removing Hard Drive Removing Hard Drive Carriers from the Chassis 1. Press the release button on the drive carrier. This extends the drive carrier handle. 2. Use the handle to pull the drive out of the chassis.
  • Page 42 SC829 Chassis Manual Dummy Drive Drive Carrier Figure 5-3: Chassis Drive Carrier The drives are mounted in drive carriers to simplify their installation and removal from the chassis. These carriers also help promote proper airflow for the drive bays. Caution: Except for short periods of time (swapping hard drives), do not operate the server with the hard drives removed from the bays.
  • Page 43 5. Replace the drive carrier into the chassis bay, making sure that the drive car- rier handle is completely closed. Figure 5-6: Installing the Hard Drive Note: Enterprise level hard disk drives are recommended for use in Supermicro chassis and servers. For information on recommended HDDs, visit the Supermicro Web site at http://www.supermicro.com.
  • Page 44 SC829 Chassis Manual Removing the Dummy Drive or Hard Disk Drive 1. Power down the server, remove the power cord from the power supply and remove the chassis cover. 2. Press the release tab. 3. Push against the back of the dummy drive, sliding the dummy drive and slot cover forward, out through the front of the chassis.

  • Page 45: Dvd-Rom Replacement Or Installation

    Chapter 5: Chassis Setup and Maintenance DVD-ROM Replacement or Installation Most SC829 chassis models include one DVD-ROM which is usually pre- installed. Installing or Replacing a DVD-ROM Drive 1. Power down the server, remove the power cord from the power supply and remove the chassis cover.

  • Page 46: Replacing The Dvd-Rom And Front Panel

    SC829 Chassis Manual Replacing the DVD-ROM and Front Panel SC829 chassis models include a slim DVD-ROM, and front port panel. Use the instructions in this section in the unlikely event that you must replace any of these components. Front Port Panel DVD-ROM Figure 5-9: Install the DVD-ROM and Front Panel Installing the Motherboard...

  • Page 47: Installing The I/O Shield

    Chapter 5: Chassis Setup and Maintenance Installing the I/O Shield Installing the I/O Shield 1. Review the documentation that came with your motherboard. Become familiar with component placement, requirements, and precautions. 2. Power down the server, remove the power cord from the power supply and remove the chassis cover..
  • Page 48 SC829 Chassis Manual Installing the Motherboard 1. Review the documentation that came with your motherboard. Become familiar with component placement, requirements, precautions, and cable connec- tions. 2. Power down the server, disconnect the power cord from the power supply and open the chassis cover.

  • Page 49: Pci Slot Setup

    SC829: chassis include PCI/PCIE slots for expansion cards. The number of cards you can use depends on your chassis model. SC829TQ-R920LPB: Provides seven low-profile PCI/PCIe card slots. SC829TQ-R920UB: Provides four full-height, full-length and two low-profile PCI/ PCIe card slots through a user-defined universal expansion card.

  • Page 50: Pci Slot Setup For Sc829Tq-R920Ub (Universal Output)

    This universal output card allows the system to accept SAS, SCSI, IB, Ethernet, and other types of connections. The SC829TQ-R920UB chassis setup is similar to the SC829TQ-R920LPB chassis with two differences: A. The SC829TQ-R920UB chassis accepts four full-length, full-height expansion cards and two low-profile expansion cards.

  • Page 51: Pci/Pcie Slot Setup For Sc829Btq-R920Wb (Wide I/O)

    This universal output card allows the system to accept SAS, IB, Ethernet, and other types of connections. The SC829BTQ-R920WB chassis setup is similar to the SC829TQ-R920LPB chas- sis with two differences: A. The SC829BTQ-R920WB chassis accepts four full-length, full-height expansion cards and two low-profile expansion cards.
  • Page 52 SC829 Chassis Manual Figure 5-13: Installing a Riser Card Installing a Riser Card in SC829TQ-R920UB and SC829BTQ-R920WB Models 1. Power down the server, disconnect the power cord from the power supply and open the chassis cover 2. Remove the chassis air shroud. 3.

  • Page 53: Installing The Air Shroud

    SC829 (part number MCP-310-29002-0N). 3. Place air shroud in the chassis. The air shroud fits behind the two fans clos- est to the power supply. For ordering information, visit the Supermicro website at www.supermicro.com and click on the Where to Buy link. 5-15...

  • Page 54: Checking The Server's Airflow

    SC829 Chassis Manual Checking the Server's Airflow Checking the Airflow 1. Make sure there are no objects to obstruct airflow in and out of the server. In addition, if you are using a front bezel, make sure the bezel's filter is replaced periodically.

  • Page 55: System Fans

    Chapter 5: Chassis Setup and Maintenance System Fans Three heavy-duty fans provide cooling for the chassis. These fans circulate air through the chassis as a means of lowering the internal temperature of the chassis. Release Tab Figure 5-15: System Fan Replacing a System Fan 1.
  • Page 56 SC829 Chassis Manual Figure 5-16: Placing the System Fan 5-18...

  • Page 57: 5-10 Power Supply

    SC829 chassis models have two (redundant) power supplies. In the unlikely event that the power supply unit fails, the power supply can be replaced without powering- down the system. Replacement units may be ordered directly from Supermicro (see contact information in the Preface).
  • Page 58 SC829 Chassis Manual Release Tab Figure 5-17: Removing the Power Supply Replacing the Power Supply 1. Your chassis includes a redundant power supply with two power modules. You can leave the server running and remove only one power supply. If your server has only one power supply, you must power-down the server and unplug the power cord before replacing the power supply.

  • Page 59: 5-11 Replacing The Power Distributor

    Chapter 5: Chassis Setup and Maintenance Figure 5-18: Replacing the Power Distributor 5-11 Replacing the Power Distributor Redundant server chassis that are 2U or greater require a power distributor. The power distributor provides failover and power supply redundancy. In the unlikely event you must replace the power distributor, see the following instructions Replacing the Power Distributor 1.

  • Page 60: 5-12 Replacing Or Installing The Front Port Panel

    SC829 Chassis Manual 5-12 Replacing or Installing the Front Port Panel Replace or Install the Front Port Panel 1. Power down the system, unplug the power cord from the power supply and remove the chassis cover. 2. Disconnect the power and data cables from the front port panel to other chas- sis components including the motherboard and backplane.

  • Page 61: 5-13 Optional Front Bezel

    The SC829 chassis supports an optional full-face locking front bezel for added se- curity. The front bezel is not included with the SC829 chassis, but can be ordered seperately by visiting the Supermicro Web site at www.supermicro.com, clicking on the Where to Buy link and referencing part number MCP-210-82601-0B.
  • Page 62 SC829 Chassis Manual Notes 5-24...

  • Page 63: Chapter 6 Chassis Installation

    Chapter 6: Chassis Installation Chapter 6 Chassis Installation This chapter provides instructions for preparing and mounting your chassis in a rack. Unpacking the System You should inspect the box the chassis was shipped in and note if it was damaged in any way.

  • Page 64: Warnings And Precautions

    SC829 Chassis Manual Warnings and Precautions Rack Precautions • Ensure that the leveling jacks on the bottom of the rack are fully extended to the floor with the full weight of the rack resting on them. • In single rack installation, stabilizers should be attached to the rack. In multiple rack installations, the racks should be coupled together.

  • Page 65: Rack Mounting Considerations

    Chapter 6: Chassis Installation Rack Mounting Considerations Ambient Operating Temperature If installed in a closed or multi-unit rack assembly, the ambient operating temperature of the rack environment may be greater than the ambient temperature of the room. Therefore, consideration should be given to installing the equipment in an environment compatible with the manufacturer’s maximum rated ambient temperature (Tmra).

  • Page 66: Installing The System Into A Rack

    SC829 Chassis Manual Installing the System into a Rack This section provides information on installing the server into a rack unit with the rack rails provided. There are a variety of rack units on the market, so the assembly procedure may differ slightly. Refer to the installation instructions that came with your rack.

  • Page 67: Releasing The Inner Rail

    Chapter 6: Chassis Installation Releasing the Inner Rail Each inner rail has a locking latch. This latch prevents the server from coming completely out of the rack when when the chassis is pulled out for servicing. To mount the rail onto the chassis, first release the inner rail from the outer rails. Releasing Inner Rail from the Outer Rails 1.

  • Page 68: Installing The Inner Rails On The Chassis

    SC829 Chassis Manual Installing the Inner Rails on the Chassis Installing the Inner Rails 1. Identify the left and right inner rails. They are labeled. 2. Place the inner rail firmly against the side of the chassis, aligning the hooks on the side of the chassis with the holes in the inner rail.

  • Page 69: Installing The Outer Rails Onto The Rack

    Chapter 6: Chassis Installation Installing the Outer Rails onto the Rack Installing the Outer Rails 1. Press upward on the locking tab at the rear end of the middle rail. 2. Push the middle rail back into the outer rail. 3.

  • Page 70: Sliding The Chassis Onto The Rack Rails

    SC829 Chassis Manual Sliding the Chassis onto the Rack Rails Warning: Mounting the system into the rack requires at least two people to support the chassis during installation. Please follow safety recommendations printed on the rails. Installing the Chassis into a Rack 1.

  • Page 71: Appendix A Sc829 Chassis Cables

    For more compatible cables, refer to the manufacturer of the motherboard you are using and our Web site at: www.supermicro.com. A-2 Cables Included with SC829TQ Chassis SC829TQ-R920LPB, SC829TQ-R920UB, SC829TQ-R920WB Part # Type Length Description...
  • Page 72 SC829 Chassis Manual A-3 Compatible Cables These cables are compatible with the SC829 chassis. Alternate SAS/SATA Cables Some compatible motherboards have different connectors. If your motherboard has only one SAS connector that the SAS/SATA cables must share, use one of the following cables.
  • Page 73 Appendix A: Chassis Cables Extending Power Cables Although Supermicro chassis are designed to be efficient and cost-effective, some compatible motherboards have power connectors located in different areas. To use these motherboards you may have to extend the power cables to the mother boards.
  • Page 74 SC829 Chassis Manual Notes...

  • Page 75: Appendix B Sc829 Power Supply Specifications

    Appendix B: Power Supply Specifications Appendix B SC829 Power Supply Specifications This appendix lists power supply specifications for your chassis system. SC829 Series 920W (Redundant) MFR Part # PWS-920P-1R AC Input 100-240 V, 50-60 Hz, 11-4.5 Amp DC Output 4 Amp @ +5V standby, 75 Amp @ +12V +5V: 50 Amps With Power +3.3V: 30 Amps...
  • Page 76 SC829 Chassis Manual Notes...

  • Page 77: Appendix C Sas-825Tq Backplane Specifications

    Appendix C: SAS-825TQ Backplane Specifications Appendix C SAS-825TQ Backplane Specifications To avoid personal injury and property damage, carefully follow all the safety steps listed below when accessing your system or handling the components. C-1 ESD Safety Guidelines Electrostatic Discharge (ESD) can damage electronic com ponents. To prevent dam- age to your system, it is important to handle it very carefully.
  • Page 78 This manual reflects SAS-825TQ Revision 2.0, the most current release available at the time of publication. Always refer to the Supermicro Web site at www.supermicro. com for the latest updates, compatible parts and supported configurations.
  • Page 79 Appendix C: SAS-825TQ Backplane Specifications C-5 Front Connectors and SAS Ports Figure C-1: Front Connectors Front Connectors SAS Ports 1. 4-pin power connector: JP13 11. Upgrade Header: JP46 2. 4-pin power connector: JP10 12. SAS Port #0 3. CD-ROM/floppy connector: JP18 13.
  • Page 80 SC829 Chassis Manual C-6 Front Connector and Pin Definitions #1 and #2 Backplane Main Power Connec- Backplane tors Main Power 4-Pin Connector The 4-pin connectors, designated JP10, and Pin# Definition JP13 provide power to the backplane. See +12V the table on the right for pin definitions. 2 and 3 Ground #3 and #4 CD-ROM Pin Connectors...
  • Page 81 Appendix C: SAS-825TQ Backplane Specifications #8 and #9 Sideband Headers Sideband Headers The sideband headers are designated JP51 Pin # Definition Pin # Definition and JP52. For SES-2 to work properly, you SGPIO: Controller must connect an 8-pin sideband cable. See SDIN;...
  • Page 82 SC829 Chassis Manual C-7 Front Jumper Locations and Pin Definitions JP43 JP36 JP29 JP18 JP50 JP38 JP37 JP33 JP34 JP41 JP42 JP40 Figure C-3: Front Jumpers Explanation of Jumpers Connector Pins To modify the operation of the backplane, Open, jumper off the pins jumpers can be used to choose between optional settings.
  • Page 83 Appendix C: SAS-825TQ Backplane Specifications SGPIO and I C Modes and Jumper Settings This backplane can utilize SGPIO or I C. SGPIO is the default mode and can be used without making changes to your jumpers. The following information describes which jumper must be configured to use SGPIO mode.
  • Page 84 SC829 Chassis Manual C Settings Jumper Jumper Setting Notes JP33 Controller ID #1 Backplane ID #1 JP34 1-2: ID#0 2-3: ID#1 JP36 Controller ID #2 Backplane ID #2 JP37 1-2: ID#0 2-3: ID#1 JP38 Closed (Jumper on the pins) C Reset #2 JP40 Open (Jumper off the pins) C Reset_SDOUT#1...
  • Page 85 Appendix C: SAS-825TQ Backplane Specifications SAS Port Connections in I C and SGPIO Settings Use the following chart when connecting this backplane. If the SAS ports are con- nected out of order, it is not easy to identify drives using the LED function. SAS Port Connections in I C and SGPIO Settings Port #...
  • Page 86 SC829 Chassis Manual C-8 Rear Connectors and LED Indicators SAS #5 SAS #4 SAS #6 SAS #7 SAS #1 SAS #3 SAS #2 SAS #0 Figure C-5: Rear Connectors and LEDs Rear SAS/SATA Connectors Rear SAS Drive Rear SAS Drive Connector Number Connector...
  • Page 87 Appendix C: SAS-825TQ Backplane Specifications Notes C-11...
  • Page 88 SC829 Chassis Manual Disclaimer (cont.) The products sold by Supermicro are not intended for and will not be used in life sup- port systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical systems whose failure to per- form be reasonably expected to result in significant injury or loss of life or catastrophic property damage.
