We hope you enjoy your Radio Alarm Clock with
Bluetooth ® Speaker from RadioShack. This
radio features a 1.2" blue LED display, dual alarm
clock, built-in USB charging port, and auxiliary
1201682
input jack. Bluetooth connectivity enables you
TM
to wirelessly stream music from your Bluetooth-
enabled device. Please read this user's guide
Radio Alarm Clock with
before using your new radio alarm clock.
Bluetooth ® Speaker

Package Contents

• Radio Alarm Clock
User's Guide
• AC Adapter
• User's Guide

Specifications

Power Supply .................................... DC 5V, 2A adapter
......................2 × AAA backup batteries (not included)
Output Power .......................................> 2W (10% THD)
USB Output ....................................................... DC 5V, 1A
Frequency Range ............................FM 87.5 – 108 MHz
Bluetooth Protocol .....................................................v4.0
Bluetooth Connection Range ......... > 33 ft. (10.05m)
Dimensions (WHD) ..............................5.6 × 3.4 × 3.2 in
.............................................................(14.2 × 8.6 × 8.1 cm)
Specifications are subject to change and improvement
without notice. Actual product may vary from the images
found in this document.
2

Power Your Radio

• Do not mix old and new batteries, different
types of batteries (alkaline or rechargeable), or

Install Backup Batteries

rechargeable batteries of different capacities.
• If you do not plan to use the radio for a long
Batteries provide backup power during power
time, remove the batteries. Batteries can leak
outages. Settings and data memory will be lost if
chemicals that can damage electronic parts.
both AC power and batteries are removed.
1. Open the Plug the AC Adapter
battery cover.
Connect the supplied AC adapter barrel plug
2. Install two
into the DC IN jack on the back of the radio, and
AAA batteries
plug the adapter into a standard AC outlet. The
(not included)
LED displays the time.
as indicated
by the polarity
symbols (+
and –) marked
inside. DC IN
3. Replace the
battery cover.
FM
Battery Notes:
Antenna
• Replace the batteries when the LED display
dims or the sound becomes weak or distorted.
• Dispose of batteries promptly and properly. Do

USB Charging Port

not burn or bury them.
Connect a portable device
• Use only fresh batteries of the required size and
for charging using an USB
type.
charging cable (not included).
3
+ / –
• Volume control.
• Set the time.
Microphone
PM Indicator (Green)
FM Indicator (Red)
Bluetooth
Indicator (Blue)
FM
• Press and hold to turn
the radio or Bluetooth
mode on/off.
• Press to switch between
radio and Bluetooth
mode.
4 5

Listen to Your Radio

AL1 / AL2
Turn the alarm on /off or
Set The Alarm.

Listen to FM Radio

1. Press and hold FM for 2 seconds to turn
 / 
on the radio. The red FM indicator lights.
• Tune radio stations.
2. Press  or  to tune a station, or press and
• Previous/next track
hold  or  to scan available stations.
(Bluetooth only).
TIME 3. Press + or – to increase or decrease the
volume.
Enter time-setting mode.

Listen to a Bluetooth Device

Alarm 1 Indicator
1. Press FM to switch to Bluetooth mode.
(Amber)
The blue Bluetooth indicator flashes.
2. Activate your device's Bluetooth function
Alarm 2 Indicator
(refer to your device's user's guide).
(Amber)
3. When your device locates RS1201682,
select it. When paired, the blue indicator
lights steadily.
§
4. Turn on the audio source. You can control
/snooze_dimmer/
your radio through your device or with the
• Answer/reject a call or play/pause playback
radio's  / , §/snooze_dimmer/
(Bluetooth only).
+ / – buttons.
• Turn the alarm snooze on.
• If you receive a call, you can answer the
• Toggle LED display brightness to high or
call by pressing §/snooze_dimmer/
low (selection disabled in Bluetooth or
and speaking into the microphone.
snooze mode, or when the alarm sounds).
6 7
