Usage and connections

STRATO PI CAN CONNECTION DIAGRAM

The Strato Pi CAN board is supplied with all connectors pre-installed. No soldering is

required. You should connect Strato Pi to Raspberry Pi aligning the GPIO connector. Use

appropriate turrets/spacers to ﬁrmly bolt the two boards together, ensuring that no

conductive part of one board touches any part of the other board.

Be particularly careful to ensure there is enough clearance between the Ethernet and USB

connectors and the bottom of Strato Pi CAN circuit board.

NOTICE

The GPIO connector of the Strato Pi CAN board must be perfectly aligned to the

Raspberry Pi's GPIO pins. Turning on the Raspberry Pi and/or the Strato Pi CAN board

with the GPIO not correctly connected will damage both the Raspberry Pi and Strato Pi

CAN board.
