AT&T IR U-verse User Manual

to operate a VCR, Home Theater In A
Box (HTIB), Receiver or Amplifier.
A. Manually
Use the following steps to program
the TV, DVD or AUX mode keys:
1. Power on the device you want to
program
2. Locate the 4-digit set-up code
for the device you want to pro-
gram from the Manufacture
Code List in this manual. If your
device is not listed you will need
to use section B on "Using the
Automatic Search". If there are
multiple codes listed for your
device, you may need to repeat
steps 2 through 7 to find the cor-
rect one.
3. Press and hold the appropriate
mode key you want to assign to
this device (TV, DVD or AUX) on
AT&T IR U-verse
the remote control
4. While holding the mode key,
TV Remote Control
press the OK key
User Guide
5. Release both the mode key and
the OK key
– All the mode keys should flash
twice
Installing Batteries
– You'll now have 10 seconds to
The remote control requires two start step 6
AA size (1.5V) Alkaline batteries to
6. Enter the appropriate 4-digit set-
work.
up code for your device (from
the Manufacture Code List) by
Tips: replace the batteries every nine
months for optimum performance. pressing the number keys (0-9)
on the remote control
1. On the back of the remote con-
– If the mode key flashes three
trol, press the battery cover tab
times, then a correct code has
forward, lift and remove the bat-
been entered.
tery cover.
– If the mode key gives a long
2. Insert two (2) AA-size batteries,
flash, then an invalid code has
matching the + and – symbols
been entered. Start over at step
with the battery pictures.
3.
3. Put the battery cover back on
– If all the mode keys give a long
and test the remote control by
flash, then the remote control
pressing the AT&T key. The AT&T
has timed-out. Start over at step
key should light up to indicate
3
that batteries are inserted prop-
erly. 7. Point the remote control at the
programmed device and press
4. Re-pairing to TX Transmitter unit
the power key once
is required upon battery replace-
– The device should turn off
ment on the remote control and
vice visa. Battery placement is
– If it does not turn off, repeat
simple, remove the battery lid on
steps 2 through 6 trying each
the TX Transmitter unit and insert
code for your brand until you
the coin cell battery provided in
find the correct code
the battery slot. Next, replace
8. Repeat steps 1 through 7 to pro-
battery lid on the TX Transmitter
gram another device.
Unit.
Note: If you are interrupted while you
5. Refer to item 7 – RF Pairing with
are programming, the remote con-
Transmitter on this user manual
trol may time-out before you com-
for full instruction.
plete the code set-up and you will
need to start over. This is indicated
Controlling Other
by a red flash of the mode keys.
Devices
Now that your devices are pro-
grammed, you can press the appro-
In order to control other devices with
priate mode key on the remote con-
your U-Verse TV Remote Control, you
trol to work with the selected device.
need to tell the remote control what
To use the remote control for your
types of devices you have. Section 1
U-verse TV Receiver again, press the
guides you through the steps need-
AT&T mode key.
ed to do this. When you complete
Section 1, the volume and channels
Combination Devices Note: If you
will always work on the U-verse TV
have an integrated or combination
Receiver no matter what mode you
unit, such as a TV/DVD unit, each
are in. If you want to change this or
component of the unit needs to be
allow the POWER key to affect multi-
programmed separately. In the Man-
ple devices then you can also follow
ufacture Code List for these devices
the steps in Section 2. If you'd like
there will be codes for all compo-
to reset any of the settings then you
nents of the combination unit. They
can go to Sections 3 and 4.
can be distinguished as follows:
1. Programming the - TV codes start with a "1"
remote to control other
- DVD codes start with a "2"
devices
- AUX codes start with a "3"
To use the U-verse TV remote con-
For some combination devices, the
trol for your other devices, you will
original remote control may be re-
need to program one or more of the
quired to switch between the com-
TV, DVD or AUX buttons at the top of
ponents.
the remote control. There are two
ways to do this. If your device is list-
ed in the Manufacture Code List at B. Using the Automatic
the end of this Manual, you can use
Search
section A. If your device is not listed,
You can search the remote control
you will need to use section B.
memory for your 4 digit manufacture
Note: device code. You will need to use
The AUX button may be programmed this function if the code for your de-
AT&T RC1534819 (12 Jun 2008).ind1 1
I. Volume Always Controls the
same Device
vice is not listed in the Manufacture
1. Press and hold the AT&T key on
Code List.
the remote control
2. While holding the AT&T mode
1. Turn on the device you wish to
key, press the OK key
program
3. Release both the AT&T key and
2. Point the remote control at the
the OK key
device
– All the mode keys will flash
3. Press and hold the appropriate
twice indicating programming
mode key you want to assign to
mode
this device (TV, DVD or AUX) on
the remote control
4. Enter 955 by pressing the number
keys on the remote control
4. While holding the mode key,
press the OK key
– The AT&T key will flash twice
indicating correct entry
5. Release both the mode key and
the OK key 5. Press the mode key that you
want to always receive the vol-
– All the mode keys should flash
ume commands
twice
– The selected mode key will
– You'll now have 10 seconds to
flash three times indicating suc-
start step 6
cessful assignment and return to
6. Enter 922 by pressing the number
normal operations
keys on the remote control
The volume commands will now go
– The selected mode key will
to the selected device no matter
flash twice indicating correct en-
what mode you are in.
try
7. For TV or DVD modes press and II. Volume Control Depends on
release the PLAY key
Device Selected
– For AUX searching only, press
The volume setting can also be re-
and release the PLAY key then
configured to independently control
press
the volume associated with each de-
1 for VCR vice. (e.g. In AUX mode the receiver
controls the audio; In TV mode the
2 for Receiver/Tuner
TV controls the audio)
3 for Amplifier
1. Press and hold the AT&T key on
4 for Home Theater In A Box
the remote control
(HTIB)
2. While holding the AT&T mode
– The AUX mode keys will flash
key, press the OK key
twice indicating correct entry
3. Release both the AT&T key and
8. Now press the FF button multi-
the OK key
ple times until the device turns
– All the mode keys will flash
off
twice indicating programming
9. Press the ENTER key (bottom
mode
right) to save the code on the
4. Enter 955 by pressing the number
remote control
keys on the remote control
10. Check to make sure the code
– The AT&T key will flash twice
works by pressing the mode key,
indicating correct entry
then the power button, to turn
the device back on. If this does
5. Press the ENTER key
not work, start again at step 2.
– The AT&T key will flash three
11. Now that your devices are pro-
times indicating successful as-
grammed, you can press the signment and returns to normal
appropriate mode key on the
operations
remote control to work with
the selected device. To use the
B. Channel Selection Set-Up
remote control for your AT&T U-
Option
verse TV Receiver again, press
By default the remote control will
the AT&T mode key.
always send channel commands to
Note:
the U-verse TV receiver no matter
– If any other key is pressed except
what mode you are in. This will pre-
PLAY, ENTER, POWER, EXIT, REW, FF,
vent accidental TV channel changes
or number keys 1 to 4, the selected
while in TV, DVD or AUX modes.
mode key will give a long red flash
(error message) and the remote
There are two ways you can change
control will return to normal opera-
this: I) Have channel commands al-
tion and you will need to start over.
ways go to a single device other
than the U-verse TV receiver; II) Have
– If you are interrupted while you
channel commands go to different
are programming, the remote con-
devices when in different modes
trol may time-out before you com-
(e.g., When in TV mode the chan-
plete the code set-up and you will
nel commands go to the TV, when in
need to start over. This is indicated
DVD mode the channel commands
by a red flash of the mode keys.
go to the DVD player, etc.). See the
appropriate section for each.
2. Setting up your
Volume, Channel and
I. Channel Always Controls the
Same Device
Power Options
1. Press and hold the AT&T key on
The default for your power, vol-
the remote control
ume and channel controls send the
codes to the U-verse TV receiver no
2. While holding the AT&T mode key,
matter what mode you are in. Thus,
press the OK key
in DVD mode, the volume still con-
3. Release both the AT&T key and
trols the U-verse TV receiver, etc. If
the OK key
you would like to change this, follow
– All the mode keys will flash
these instructions:
twice indicating programming
mode
A. Volume Control Set-Up
4. Enter 966 by pressing the number
Options
keys on the remote control
The volume commands are always
– The AT&T key will flash twice
sent to the U-verse TV receiver un-
indicating correct entry
til the TV mode key is programmed.
Then the volume commands are
5. Press the mode key that you
sent to the TV from all mode keys.
wish the channel commands to
If you'd like the volume commands
always go to
to still be sent to just one device,
– The selected mode key will
but that it be a different device (for
flash three times indicating suc-
example a home theater setup) then
cess and return to normal opera-
follow the instructions in Section I.
tions.
If you'd like the volume commands
sent to different devices depending The channel commands will now
on which mode you are in then go go to the selected device no matter
to Section II. what mode you are in.
II. Channel Control Depends all back ON. It is important to point
the remote directly toward the de-
on Device Selected
vices for this to work properly.
1. Press and hold the AT&T key on
the remote control To change the number of devices
controlled by the POWER key, you
2. While holding the AT&T mode key,
must start at Step 1 and continue
press the OK key
until all desired devices have been
3. Release both the AT&T key and
programmed.
the OK key
– All the mode keys will flash
3. Changing and
twice indicating programming
Removing Codes
mode
4. Enter 966 by pressing the number
A. Mode Deactivation
keys on the remote control
To deactivate a mode key, follow
– The AT&T key will flash twice
these steps:
indicating correct entry
1. Press and hold the mode key
5. Press the Enter key
(TV, DVD or AUX) that you'd like
– The AT&T key will flash three
to deactivate on the remote con-
times indicating successful as-
trol
signment and return to normal
2. Without releasing the chosen
operations.
mode key, press and hold the OK
If you press any key other than the
key simultaneously
mode keys or ENTER, the AT&T key
3. Release both the mode key and
will give a long red flash and the
the OK key
remote control will return to normal
operation. Should the remote con-
– All the mode keys should flash
trol time-out before you complete
twice
the procedure you will need to start
4. Enter the appropriate 4-digit
over.
code from the list below de-
pending on the mode you are
C. Power Control Set-Up
deactivating:
Options
– TV: 1254
By default, the POWER key only
– DVD: 2254
powers on or places your U-verse TV
receiver in stand-by mode. Once you – AUX: 3254
have programmed the TV mode key,
– The mode key will flash three
the TV and U-verse TV receiver will
times indicating correct entry
both be powered on/off simultane-
and return to normal operation
ously. You also have the option to
– When an invalid code is en-
turn on/off TV, DVD and AUX mode
devices individually by pressing the tered, the selected mode key will
give a long flash to indicate that
applicable mode key then the POW-
you have not entered the code
ER key.
correctly
I. To Have Multiple Devices – Should the remote control
Power Off with the Power Key time-out before you complete
the set-up, you will need to start
If you would like other devices to be
over
powered on/off simultaneously with
the POWER key, then follow these
B. Reassigning Your Mode
instructions for the additional de-
vices (for a total of 4). Keys To Another Device
The TV, DVD and AUX keys are already
1. Press and hold the AT&T key on
set up to control specific devices:
the remote control
TV key: TV & HDTV
2. While holding the AT&T mode
key, press the OK key
DVD key: DVD
3. Release both the AT&T key and
AUX key: VCR, Home Theater
the OK key
In A Box (HTIB), Receivers and
– All the mode keys will flash Amplifiers
twice indicating programming
You may change these mode keys
mode
to operate another type of device.
4. Enter 977 by pressing the number To do this, you must copy an existing
mode key to the one you would like
keys on the remote control
to change. For example, you have
– The AT&T key will flash twice
two DVD players and you'd like to
indicating correct entry
use the AUX key for one of them. You
5. Press the AT&T key on the re-
would begin by programming one of
mote control the DVD players into the DVD mode
key and then copy that to the AUX
– The AT&T key will flash twice
mode key. Then you reprogram the
indicating correct entry
original DVD mode key to the other
6. Press the TV key on the remote
DVD player. Before beginning these
control
steps, program the device you'd like
– The TV key will flash twice indi- to copy by following the steps in
cating correct entry Section 1. Then use the steps below
to copy the codes.
7. Press each additional mode key
that you wish to include such as
1. Press and hold the AT&T key on
the DVD key or AUX key
the remote control
– Each selected mode key will
2. Without releasing the AT&T key,
flash twice indicating correct en-
press and hold the OK key simul-
try
taneously
8. Press the ENTER key to com-
3. Release both the AT&T key and
plete
the OK key
– The last mode key selected will
– All the mode keys will flash
flash three times indicating suc-
twice indicating programming
cessful assignment and return to
mode
normal operations
4. Enter 944 by pressing the number
Note:
keys on the remote control
If any key is pressed except the
– All the mode keys will flash
mode keys and ENTER, the AT&T key
will give a long red flash and the re- twice indicating correct entry
mote control will return to normal
5. Press the mode key (i.e., TV, DVD
operation. Should the remote con-
or AUX) you would like to copy
trol time-out before you complete
the codes FROM (See above)
the procedure you will need to start
– The selected mode key will
over.
flash once
If the devices that you have pro-
6. Press the mode key you would
grammed to turn ON/OFF at the
like to copy the codes TO
same time get out of sync so that
some turn ON and others turn OFF, – The selected mode key will
you will need to manually turn OFF flash three times indicating suc-
the out of sync devices and then cessful reassignment and return
press the POWER key to turn them to normal operations
Once you copy the mode key, you − All the mode keys will flash
will have both keys with the same twice indicating programming
program code. Now reprogram the mode
original mode key with a new code
5. Enter 988 by pressing the number
for a second device.
keys on the remote control
Note: − The selected mode key will
If any other key is pressed except
flash twice indicating correct en-
the mode keys the AT&T key will give try
a long red flash and the remote con-
6. Press the key on this U-verse re-
trol will return to normal operation.
mote control that you want the
Should the remote control time-out
codes to be learnt to (TV, DVD
before you complete the procedure
and AUX keys are mode keys and
you will need to start over.
so not available for learning)
− The selected mode key will
4. Resetting to Factory
flash twice indicating correct en-
Defaults
try
7. Point the original remote control
A. Resetting the Remote
directly opposite to this U-verse
Control to Factory Default
remote control.
Settings:
8. Press and hold the key on the
original remote control where
1. Press and hold the AT&T key on
the code is to be learnt
the remote control.
− The original remote control
2. Without releasing the AT&T key,
transmits code to this U-verse
press and hold the OK key.
remote control. Upon comple-
3. Release both the AT&T key and
tion this U-verse remote con-
the OK key
trol, selected mode key will flash
– All four mode keys will flash three times indicating successful
twice to indicate programming learning.
mode.
9. Release the key on the original
remote control
4. Enter programming code 900 by
pressing the number keys on the
10. Repeat steps 6-9 for learning
remote control.
more codes.
– The AT&T key will flash three
11.Press any of the mode key (i.e.
times indicating you have suc-
AT&T, TV, DVD or AUX) to return
cessfully entered the code and
to normal operations
the remote has been reset to the
− The selected mode key will flash
default settings
three times and return to normal op-
Note:
erations
If any other key is pressed except the
number keys, the AT&T key will give Note:
− If no code is received from original
a long red flash and the remote con-
trol will return to normal operation. remote within the 30 seconds, then
all the selected mode keys will give
Should the remote control time-out
before you complete the procedure a long red flash (error message) and
this U-verse remote control will re-
you will need to start over.
turn to normal operations. You will
need to start over.
B. Resetting the Volume,
Channel and Power − If codes from original remote are
poorly received, or battery is weak,
Programming:
or learns memory is full, then only
1. Press and hold the AT&T key on
the single selected mode key will
the remote control.
give a long red flash (error message)
and this U-verse remote control will
2. Without releasing the AT&T key,
return to normal operations. You will
press and hold the OK key.
need to start over after replacing
3. Release both the AT&T key and
batteries or erasing some existing
the OK key
learn codes.
– All four mode keys will flash
twice to indicate programming
6. Resetting of Learning
mode
Codes
4. Enter programming code 902 by
pressing the number keys on the
A. Resetting of Individual
remote control.
Learning Codes
– The AT&T key will flash three
To erase individual learn codes, fol-
times indicating you have suc-
low these steps:
cessfully entered the code to re-
set Volume, Channel and Power
1. Press and hold the mode key (i.e.
to the defaults and the remote
TV, DVD or AUX) which you want
will return to normal operation
to erase learn codes
Note:
2. Without releasing the selected
If any other key is pressed except the
mode key, press and hold the
number keys, the AT&T key will give
MENU key simultaneously
a long red flash and the remote con-
trol will return to normal operation. 3. Release both the mode key and
the MENU key
Should the remote control time-out
before you complete the procedure
− All the mode keys will flash
you will need to start over.
twice indicating programming
mode
5. Learning the remote
4. Enter 904 by pressing the number
to control other devices
keys on the remote control
In cases where devices are not listed − The selected mode key will
flash twice indicating correct en-
in the Manufacture Code List in this
manual or certain keys are not avail- try
able, but you have the original re-
5. Press the key that you want to
mote control on hand, you can learn
erase the learn codes
the codes from the original remote
− The selected mode key will
control into the desired keys of this
flash three times indicating suc-
U-verse remote control.
cessful resetting
To learn the desired IR codes from
6. Repeat step 5 for erasing other
the original remote, follow these
learning codes
steps:
7. Press any of the mode key (i.e.
AT&T, TV, DVD or AUX) to return
1. Get ready the original remote
control to be learnt to normal operations
2. Press and hold the mode key (i.e. − The selected mode key will
flash three times and return to
TV, DVD or AUX) where you want
the codes to be learned. normal operations
Note:
3. Without releasing the selected
− If the battery power is weak during
mode key, press and hold the
resetting mode, the selected mode
MENU key simultaneously.
key will give a long flash (error mes-
4. Release both the mode key and
the MENU key
sage), the learn codes will not be 7. Press and release the OK key on
erased and you will need to replace the remote control to start RF
new batteries and start over. pairing
8. Use the sharp object to press
B. Resetting of All Learning
and release the tiny Pairing key
on the RF transmitter
Codes within TV, DVD or AUX
mode − The AT&T mode key will flash
three times indicating successful
To erase all learn codes in selected
RF pairing
mode TV, DVD or AUX, follow these
Note:
steps:
− If the batteries are removed from
1. Press and hold the mode key (i.e. the remote control, the pairing with
the Transmitter will be lost, and the
TV, DVD or AUX) which you want
to erase learn codes remote will respond to RF signals
from all similar RF transmitters. You
2. Without releasing the selected
will need to pair them again.
mode key, press and hold the
MENU key simultaneously
− If the battery is removed from
the Transmitter, the pairing with
3. Release both the mode key and
the remote control will be lost, and
the MENU key
the remote will not respond to any
− All the mode keys will flash
transmitter. You will need to pair the
twice indicating programming
Transmitter with the remote again.
mode
4. Enter 905 by pressing the number
8. Backlight Control Set
keys on the remote control
Up Option
− The selected mode key will
By default the Backlight is set to Off.
flash three times indicating suc-
cessful erasing of all learn codes You can turn the Backlight on or off
by performing this function.
under the selected mode and
the remote control will return to
1. Press and hold the AT&T key on
normal operations
the remote control
Note:
2. Without releasing the AT&T mode
− If the battery power is weak during
key, press and hold the MENU
resetting mode, the selected mode
key simultaneously
key will give a long flash (error mes-
sage), the learn codes will not be
3. Release both the AT&T mode key
erased and you will need to replace
and the MENU key
new batteries and start over
− All the mode keys will flash
twice indicating programming
C. Resetting of All Learning
mode
Codes in All Modes
4. Enter 991 by pressing the number
To erase all learn codes, follow these keys on the remote control
steps:
− The AT&T mode key will flash
three times indicating successful
1. Press and hold the AT&T mode
toggling the Backlight enabling/
key on the remote control
disabling control.
2. Without releasing the AT&T mode
Note:
key, press and hold the MENU
− The Backlight is turned off upon
key simultaneously
factory default settings and you will
3. Release both the AT&T mode key need to perform this function to turn
and the MENU key
the Backlight on again.
− All the mode keys will flash
twice indicating programming
mode FCC ID:RCSTX100001
4. Enter 906 by pressing the number Federal Communication
keys on the remote control
Commission Interference
− The AT&T mode key will flash Statement
three times indicating success-
This equipment has been tested and
ful erasing of all learn codes and
found to comply with the limits for
the remote control will return to
a Class B digital device, pursuant to
normal operations Part 15 of the FCC Rules. These limits
are designed to provide reasonable
Note:
protection against harmful interference
− If the battery power is weak during in a residential installation. This
resetting mode, the selected mode equipment generates, uses and can
radiate radio frequency energy and, if
key will give a long flash (error mes-
not installed and used in accordance
sage), the learn codes will not be
with the instructions, may cause harmful
erased and you will need to replace
interference to radio communications.
new batteries and start over However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does
7. RF Pairing with cause harmful interference to radio
or television reception, which can be
Transmitter
determined by turning the equipment
off and on, the user is encouraged to
By default this remote recognises RF
try to correct the interference by one of
signal from all similar RF transmit- the following measures:
ters. However you can set this re-
- Reorient or relocate the receiving
mote control to recognize RF signal
antenna.
only from its dedicated transmitter
- Increase the separation between the
by performing this function: equipment and receiver.
- Connect the equipment into an
outlet on a circuit different from that
1. Remove the battery lid from
to which the receiver is connected.
the Transmitter and get ready a
- Consult the dealer or an experienced
sharp object (such as a pencil)
radio/TV technician for help.
2. Place the remote control near
FCC Caution: Any changes or
the RF transmitter
modifications not expressly approved
by the party responsible for compliance
3. Press and hold the AT&T key on
could void the user's authority to
the remote control operate this equipment.
4. Without releasing the AT&T mode This device complies with Part 15 of the
FCC Rules. Operation is subject to the
key, press and hold the MENU
following two conditions: (1) This device
key simultaneously
may not cause harmful interference,
5. Release both the AT&T mode key and (2) this device must accept
any interference received, including
and the MENU key
interference that may cause undesired
operation.
− All the mode keys will flash
twice indicating programming
This transmitter must not be co-located
mode or operating in conjunction with any
other antenna or transmitter.
6. Enter 990 by pressing the number
keys on the remote control
− The AT&T mode key will flash
twice indicating correct entry
6/12/2008 1:36:47 PM
