TE-700I
Installation and Operating Instructions
Haverland TOWELS
THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE.
GENERAL RECOMMENDATIONS:
* Please read these installation and usage instructions for your HAVERLAND towel-drier radiator in order to get to know all its
advantages and to prevent any errors of use.
* After reading this manual, please keep it in a safe place for future reference and at the disposal of any user.
* The Haverland towel-drier radiator is a heating element and is designed solely for home use. Any other use is forbidden.
* If the mains power cable is damaged, it must be replaced by a new one from the manufacturer or an authorised HAVERLAND
technical service.
* The mains power cable must never be cut.
* When the towel-drier radiator is to be disposed of, the requirements established for waste processing and recycling
(thermal fluid) must be taken into account.
* This radiator must not be used in the presence of gas, explosives or other inflammable substances.
* The guarantee for this appliance shall not cover any damage caused by not following these instructions.
IP44
CLASS II

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TE-700I and is the answer not in the manual?

Questions and answers

Related Manuals for Haverland TE-700I

Summary of Contents for Haverland TE-700I

  • Page 1 * The Haverland towel-drier radiator is a heating element and is designed solely for home use. Any other use is forbidden. * If the mains power cable is damaged, it must be replaced by a new one from the manufacturer or an authorised HAVERLAND technical service.

  • Page 2: Installation Instructions

    * Verify that there is a mains connection close to where the appliance is to be installed. * This Haverland towel-drier radiator is designed to be fixed to a wall. * It must not be installed below or in front of a mains socket.
  • Page 3 1.1.- Verify that there is a mains connection close to where the appliance is to be installed. 1.2.- Remove the TEMPLATE THAT INDICATES THE EXACT POSITION OF THE HOLES TO BE DRILLED IN THE WALL from inside the packing box. 1.3.- Remove the box of accessories.
  • Page 4 6. Drill the four holes marked on the wall. 7. Insert the four wall plugs (part 1) into the drilled holes. 8. Position parts 2 and 3 in accordance with the included drawing. Remember that the two assemblies installed in the upper section fit upwards into the slot of part 2 and the other two parts downwards in the slot.
  • Page 5 11. LOOSELY screw the four short screws 5 in the four fixing supports. 12. Take the HAVERLAND towel-drier radiator and support it on the four supports fixed to the wall. Place the radiator so that the upper supports are between the second and third heater bars.

  • Page 6: Specifications

    5. Adjust the time and follow the instructions given in the section “Putting into Operation”, page 7. INFRARED REMOTE CONTROL INSTRUCTIONS The infrared remote control is capable of controlling and regulating your TE-700I HAVERLAND towel drier control. Its weekly programming function provides energy savings in accordance with your daily routine.

  • Page 7: Putting Into Operation

    Select this mode in order to switch off the control. The remote control switches off first automatically (the screen goes blank) and then the HAVERLAND towel drier is switched off and set in Standby mode. This Standby status is indicated by the towel drier pilot lamp being on RED.

  • Page 8: Important Note

    The user-configurable program U1 (that leaves the factory programmed, see Table 1) can be programmed with all the heating requirements for your bathroom. The remote control for the HAVERLAND towel drier can execute a program each day of the week programming it hour by hour, indicating whether comfort or economic temperature is desired for each hour.
  • Page 9 Allow the heater to cool, then wipe with a dry cloth to remove dust and a damp cloth (not wet) to clean off stains. Be careful not to allow moisture into the heater. MEASURES MODEL: TE-700I HOLES POWER: 700 W PLANTILLA...
