  • Page 1 Instructions & installation manual Manuel d’installation et d’utilisation Manual de instalação e uso Español • Mando a distancia opcional • Optional remote control • Télécommande en option • Comando à distância opcional English Français www.haverland.com www.haverland.com Português www.haverland.co.uk www.haverland.co.uk RCW_2020_V2.3_manual_ESPUKF_03August2020...
  • Page 2 ÍNDICE 1. ADVERTENCIAS GENERALES 2. INSTALACIÓN 3. FUNCIONAMIENTO 3.1 PANEL DE CONTROL 3.2 ¡EMPECEMOS! 3.3 CONFIGURACIÓN HORA Y DÍA 3.4 ELECCCIÓN MODO DE CALEFACCIÓN 3.5 AJUSTE TEMPERATURA CONFORT 3.6 AJUSTE TEMPERATURA ECONOMÍA 3.7 MODO ANTIHIELO 3.8 FUNCIÓN AHORRO “VENTANAS ABIERTAS” 3.9 MODO PROGRAMADO 3.10 BLOQUEO DE TECLADO 3.11 FUNCIONES AVANZADAS...
  • Page 3 1. CAUTION • Please read these instructions carefully. • To disconnect mains power from the radiator remove the plug from the wall socket, but never pull on the cable. • Do not leave the mains cable in contact with the radiator when it is switched •...
  • Page 4 1. CAUTION • WARNING: Certain parts of this product can become very hot and cause burns. Special attention shall be paid when children and other vulnerable persons are present. • Do not touch the external parts of the radiator when it is operating. •...
  • Page 5 2. INSTRUCTIONS FOR INSTALLATION IMPORTANT • It is important that the radiator IS FIXED FIRMLY TO A SOLID AND LEVELLED WALL. • Make sure that there is a socket near the area where you are going to place it. • Take out the wall pattern from the box to see the exact positions of the necessary drill holes.

  • Page 6: Instructions For Installation

    2. INSTRUCTIONS FOR INSTALLATION Cardboard template Place the screw but don’t screw it fully. (M. 6 x 40 mm) 4 Screws 5.5 x 50 mm Place Slide the the radiator radiator up, Place over top prong and lower gently into position...
  • Page 7 2. INSTRUCTIONS FOR INSTALLATION IMPORTANT: Screw down FULLY to lock the radiator BRACKET MOUNTING INFORMATION “A” (mm) “B” (mm) “C” (mm) 102,5 1100 1400 1700...

  • Page 8: Operation

    3. OPERATION 3.1 CONTROL PANEL 1. Increase 2. Reduce 3. Mode / OK 4. Anti-frost / Programming / Time 5. Selected temperature / Time 6. Comfort mode 7. Economy mode 8. Anti-frost mode 9. Open windows “on” 10. Radiator “on” 11.
  • Page 9 3. OPERATION 3.2 START - FIRST CONNECTION Press ON / OFF switch located at the right rear part of the unit. The screen will constantly flash. 3.3 SETTING THE CLOCK AND THE DAY OF THE WEEK 5 SEC.
  • Page 10 3. OPERATION With the buttons, set the current day of the week. Set the current hour by pressing the buttons. Set the current minutes by pressing the buttons.

  • Page 11: Comfort Mode

    3. OPERATION The radiator reads the internal memory in order to load the last mode selected. COMFORT MODE ECONOMY MODE PROGRAMMING MODE...

  • Page 12: Heating Modes

    3. OPERATION 3.4 HEATING MODES Choose the mode of operation (comfort, economy or programming mode) by pressing button. COMFORT MODE ECONOMY MODE PROGRAMMING MODE When the radiator is heating, this symbol will be displayed. The set temperature will be display, NOT ambient temperature. Remember that the economy mode is the temperature that you should set when you are not in the room or overnight, and the comfort mode is the temperature that you should set in a room when you are inside it.

  • Page 13: Setting The Comfort Temperature

    3. OPERATION 3.5 SETTING THE COMFORT TEMPERATURE Choose the comfort mode by pressing button repeatedly until the comfort symbol is displayed. COMFORT MODE This comfort temperature is adjusted by using the buttons 3.6 SETTING THE ECONOMY TEMPERATURE Choose the economy mode by pressing button repeatedly until the economy...

  • Page 14: Anti-Freeze Mode

    3. OPERATION 3.7 ANTI-FREEZE MODE Thanks to this “anti-freeze mode”, extreme temperatures will be avoided in your home, keeping the room temperature at 7ºC. 3.8 “OPEN WINDOWS” FUNCTION This function is activated when there is a sudden drop in temperature in the room. When this function activates, “OPEN”...
  • Page 15 3. OPERATION 3.9 PROGRAMMING MODE Choose the programming mode by pressing button repeatedly until the Pro symbol is displayed. Programming mode HOW DO I CREATE A HEATING PROGRAMME? Anti-freeze Flashing Flashing Monday 5 SEC. Flashing economy symbol PROGRAMMING MENU...
  • Page 16 3. OPERATION For “00:00 Monday”, choose the desired function (comfort, economy or anti-freeze) by successively pressing the key. To confirm the selection, press the key. Repeat the above step for each hour and each day of the week. key, it will copy the previous operating mode over to the next If you press the hour.
  • Page 17 3. OPERATION Once you have completed the entire week, the “set hour and day” menu will automatically appear. Follow the step on page 11 if you want to adjust the day and clock, but if not, press the to exit the programming menu. The word “Pro”...

  • Page 18: Keyboard Lock

    3. OPERATION 3.10 KEYBOARD LOCK Simultaneously press the buttons until is displayed. 2 SEC. The same operation must be followed to unlock the keyboard. 3.11 ADVANCED FUNCTIONS The “open window” function can be activated or deactivated. To access this “advanced” menu, follow these steps: Anti-freeze 3 SEC.
  • Page 19 3. OPERATION Choose ON or OFF press button or button. Example : OFF With this adjustment, you can unify the room temperature captured by the radiator with that captured by a thermometer in the room. The radiator captures the temperature around 15cm from the floor and will always be different to that captured at the opposite side of the room.

  • Page 20: Consumption Indicator Function

    3. OPERATION 3.12 CONSUMPTION INDICATOR FUNCTION The radiator incorporates a function that is unique on the market, which enables you to find out its electricity consumption. We ask that you carry out the following operation to indicate the power of your radiator (this operation should only be carried out once).
  • Page 21 3. OPERATION HOW DO I DISPLAY THE CONSUMPTION? Anti-freeze 3 SEC. The energy meter will tell you the sum of the accumulated KWh every 24 hours up to the latest restart. It can also be restarted at any time by pressing the button for 2 seconds.

  • Page 22: Maintenance

    3. OPERATION 3.13 “BABY CARE” FUNCTION This function reduces the surface temperature of the heater to protect the most vulnerable. The wattage of the heater is reduced approximately by 50% so you feel at ease when there are children in the house. Press simultaneously the keys until you see a picture on the screen.
  • Page 23 24 months as from the purchase date shown on the invoice. HAVERLAND guarantees against material, design or manufacturing faults at the moment of its original acquisition for 2 years. The electronic component for 3 years (exclude accidental damage, transport, and misuse).
  • Page 24 Modelos / Models / Modèles / Modelos RC3W RC5W RC7W RC9W RC11W Potencia calorífica / Heat output / Puissance thermique / Potência calorífica Potencia calorífica nominal (kW) Nominal heat output (kW) 0.45 Puissance thermique nominale (kW) Potência calorífica nominal (kW) Potencia calorífica máxima continuada (kW) Maximum continuous heat output (kW) 0.45...
