Quick
Start Guide
RT-AC68U
Wireless-AC1900
with AiMesh Wi-Fi System
BEFORE SETTING
01
Preparing to setup a standalone router
Go to ONE ROUTER SETUP STEPS.
1
ONE ROUTER SETUP
ONE ROUTER SETUP STEPS
01
Prepare your Modem
1
Unplug the power of cable / DSL modem.
If it has a battery backup, remove the battery.
1
02
Connect your Device
Power on the router.
1
Plug in and press the power button at the back of your router.
1
Check the WAN and 2.4GHz / 5GHz LED lights to ensure the
2
hardware connection is ready.
Hardware Explanations
1
Plug the adapter into the DCIN port, and press the power button.
2
The Power, 2.4GHz and 5GHz LEDs will light up when your hardware is ready.
Button Explanations
Wi-Fi
WPS
On/Off
Power
button
button
button
LED Explanations
LAN 1-4
02
Preparing to setup an AiMesh Wi-Fi system
1
2
3
WE SUGGEST...
2
Connect your modem
to the router with the
network cable provided.
3
Power on the modem.
Plug modem to the power
outlet and power on.
Connect your PC to the router using an additional
3
network cable.
WAN
LED On/Off
LAN
Reset
DCIN
USB 3.0
port
button
port 1-4
button
port
/2.0 ports
WAN
USB3.0
USB2.0
2.4GHz
5GHz
Power
Two (2) ASUS routers (models supporting AiMesh https://www.asus.com/AiMesh/).
Assign one as AiMesh router, and another one as AiMesh node.
** If you have multiple AiMesh routers, we recommend using the router with the highest specifications as your
AiMesh router and the others as AiMesh nodes.
Go to AiMesh SETUP STEPS.
AiMesh node
AiMesh SETUP STEPS
4
Check the modem LED lights
to ensure the connection is active.
(
If you are using DSL for internet, you will need your username / password from
your Internet service provider (ISP) to properly configure your router.
03
Login and Connect
Open a web browser.
1
You will be redirected to the ASUS Setup Wizard. If not, navigate
to http://router.asus.com.
RESET BUTTON
Reset the system to its factory default settings.
WAN PORT
Connect your modem to this port with a network cable.
LAN PORT 1-4
Connect your PC to a LAN port with a network cable.
AiMesh router
(
