RX-77
07-25-2001
Page 1 of 6
Introduction
Possible Set-ups
The RF Extender can be used in several situations:
• Your devices can be remotely controlled while the
RF Extender is placed in line of sight (situation A).
• The RF Extender controls devices placed in
an adjacent room (situation B).
• The RF Extender is placed inside a closet
or a rack together with your devices
(situation C ).
• The set-ups in situation A, B and C can
be combined. If you want to control
devices in different locations,
you have to place
a RF Extender in
each location.
You can operate all
RF Extenders with
one remote control.
User Guide
Model RX-77 User Guide
RF Extender
Situation A
1
Situation B
Situation C
See Multiple RF Extenders on p. 6 to
apply the necessary settings.
Advertisement
Related Manuals for Marantz RX-77
Summary of Contents for Marantz RX-77
- Page 1 RX-77 07-25-2001 Page 1 of 6 Model RX-77 User Guide RF Extender Introduction Possible Set-ups The RF Extender can be used in several situations: • Your devices can be remotely controlled while the RF Extender is placed in line of sight (situation A).
- Page 2 RX-77 07-25-2001 Page 2 of 6 Installation Before you install the RF Extender, you should decide which of the set-up described on p. 1 apply to your needs. Working Angle and Range of the IR blaster Warning The IR signals sent out by the RF Extender always have to be able to reach the receiving eyes of your devices.
-
Page 3: Connecting The Power Adapter
RX-77 07-25-2001 Page 3 of 6 Installation Using the Dual IR Emitters You can use the dual IR emitters as an alternative for the IR blaster. The IR emitters can control devices the IR blaster cannot reach, for instance when there is limited space in a small closet, it can be placed in a location as to where the infrared receiver, can receive the signal. - Page 4 RX-77 07-25-2001 Page 4 of 6 Installation Settings As the RF Extender ‘communicates’ with RC5200/RC9200, you have to set the same Extender ID (identity) on both appliances. The settings depend on whether you have a single RF Extender or multiple RF Extenders.
-
Page 5: Troubleshooting
RX-77 07-25-2001 Page 5 of 6 Troubleshooting Troubleshooting Devices do not respond properly • Check if the power adapter is connected and the red LED is on. • Check if the ID and channel numbers on the RF Extender match with the ID and channel numbers on the ProntoPro Remote Control (see p. -
Page 6: Specifications
RX-77 07-25-2001 Page 6 of 6 Specifications Hardware Red LED (continuously on when powered, blinking during RF reception) 16 IDs and 4 CHs , 4 outputs for IR emitters Dimensions 4.5 x 3.2 x 1.2 inch (113 x 81 x 30 mm) Operating 32°F to 122°F (0°C to 50°C)
