Canon VB-S800VE Installation Manual

BIE-7156-000
ENGLISH
Network Camera
/

Installation Guide

Please be sure to read the "Safety Precautions" section for
correct use. After reading this Installation Guide, keep it in a
readily accessible location for future reference.
* Some cameras are not available in certain countries or regions.
Caution Request a professional installer for all installation
work. Never try to install the camera yourself.
Doing so may result in unforeseen accidents
such as dropping the camera or electric shock.
Check Included Items
Camera Template
Setup CD-ROM Installation Guide (This document)
Safety Wire, Screws (M4) x 1 Warranty Card
RJ45 Coupler Dedicated wrench
I/O Interface Cable (BK2-0078-000)
Waterproofi ng tape Waterproofi ng explanation sheet
Symbols Indicating Camera Model
: VB-S30VE : VB-S800VE
© CANON INC. 2017 Printed in Taiwan
Only for European Union and EEA (Norway, Iceland and
Liechtenstein)
These symbols indicate that this
product is not to be disposed of with
your household waste, according to the
WEEE Directive (2012/19/EU), the Battery
Directive (2006/66/EC) and/or national
legislation implementing those Directives.
If a chemical symbol is printed beneath the symbol shown
above, in accordance with the Battery Directive, this indicates
that a heavy metal (Hg = Mercury, Cd = Cadmium, Pb = Lead)
is present in this battery or accumulator at a concentration
above an applicable threshold specifi ed in the Battery
Directive.
This product should be handed over to a designated
collection point, e.g., on an authorized one-for-one basis
when you buy a new similar product or to an authorized
collection site for recycling waste electrical and electronic
equipment (EEE) and batteries and accumulators. Improper
handling of this type of waste could have a possible impact
on the environment and human health due to potentially
hazardous substances that are generally associated with EEE.
Your cooperation in the correct disposal of this product will
contribute to the effective usage of natural resources.
For more information about the recycling of this product,
please contact your local city offi ce, waste authority, approved
scheme or your household waste disposal service or visit
www.canon-europe.com/weee, or www.canon-europe.com/
battery.

Part Names

4
1 2 3
5 6 7
13
9 2
Front
Serial_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
MAC_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
10 11 12
1. Microphone / 2. Camera head / 3. Top cover /
4. Top cover lock screw / 5. Audio output terminal /
6. External device I/O terminal / 7. 100Base-TX LAN Connector /
8. Safety wire attachment / 9. Rotation dial /
10. Reset switch (please refer to the "Operation Guide") /
11. Memory card slot /
12. LED (Please refer to the "Operation Guide") / 13. Vent

Installing the Camera

1
Using the template, make holes for affi xing the camera unit.
a
Ceiling Installation
Upside
Wall Installation
a. Template
2
Dedicated wrench
If Using a Memory Card
8
To remove the memory card, push it in all the way until the card
slightly pops out and remove.
Important
Insert a memory card before installing the camera.
3
c
b
b. Anchor or Structure / c. Safety wire
4
Please refer to the reverse side of this guide
for details.
d
a e
d. RJ45 Coupler / e. I/O interface cable
Important
The camera head will move and make noise when the power is
turned on.
• Do not touch the camera head.
• After the head stops moving, mount the camera.
5
Please refer to the waterproofi ng explanation sheet for details on
how to wrap the waterproofi ng tape.
6
Weight:
M4
Screws
(included)
7
9
Perform camera settings by using the software found on the
Setup CD-ROM (please refer to the "Operation Guide").
Accessories
The following accessories can be purchased separately as necessary.
Some accessories are not available in certain countries or regions.
Pendant Mounting Kit PC30VE-VB
Dedicated accessory used to install the camera
to the end of pipe that extends from high
ceilings, such as in big-box stores.
Conduit Box CB30VE-VB
Dedicated accessory, when using composite
pipe for installation, to connect composite pipe
and the camera. Cables cannot be stored in the
conduit box.
Approx. 650 g (1.44 lb.)
Approx. 630 g (1.39 lb.)
8
