Data I/O FlashPAK Getting Started Manual page 3

5. Close the Device
Footnote box if it displays.
6. Load Job is complete.
Click OK.
CAUTION: Before pushing the eject
button on your card reader, be sure
to use the proper procedure for clos-
ing files on your system. This may
mean right-clicking the drive letter in
Windows Explorer and selecting
Eject. Some systems display an icon
in the Windows taskbar to stop pro-
grams.
7. Eject your PC Card from
the computer and insert it into
FlashPAK and switch the power on.
Fast Device Support Online
Searches:
In TaskLink click Help > Data I/O on the Web > Search for Device Support.
Select your programmer model.
If no device is found, you can click on Submit a Device Support Request on the
same Web page.
Requests:
In TaskLink click Help > Data I/O on the Web > Request Device Support.
For information on FlashPAK see:
–FlashPAK Operator's Guide (hardcopy included).
–in TaskLink click Help > Documentation > FlashPAK Operator's
Guide to see the PDF.
For information on TaskLink see:
–the TaskLink on-screen Help menu.
–the Data I/O Web site.
CAUTION: Never remove the PC
Card from FlashPAK while the yellow
lamp is blinking.
8. Your Job is ready to run
(after the Self-test passes). Press
the green Start button and follow the
instructions in the Control Panel
window.
• A vacuum tweezer is supplied for
handling devices.
• Lift the yellow Actuating Bar to pro-
gram devices.
PC Cards
FlashPAKs read type I and type II ATA 68-pin PC cards. PC Cards (originally
called PCMCIA Cards) use 68 pin dual row connecting interface.
CompactFlash (CF) cards can be used directly in a PC Card slot as an ATA (IDE)
or PCMCIA storage device with a passive adapter. A passive adapter is supplied
with FlashPAK. CF is a mass storage Flash memory card format.
New PC Cards must be formatted using FAT16.
Computer Requirements
• Operating System: Windows 2000, NT, XP, Vista
• Hard disk space: 90 MB minimum for TaskLink files
• CD ROM drive capable of reading CDR discs
• Mouse
• VGA monitor
• A PC Card reader/writer or a port (USB or parallel) to install an external
reader/writer
FlashPAK Electrical Requirements
• Operating voltage: 110 to 240 VAC
• Power Consumption: 100 watts maximum
• Frequency Range: 50 to 60 Hz
Data I/O has endeavores to ensure that this document is accurate. Data I/O assumes no liability for
error, or for any incidental, consequential, indirect, or special damages, including but without limita-
tion, loss of use, loss or alteration of data, delays, or lost profits or savings, arising from the use of this
document or the product that it accompanies.
©2004-2009 Data I/O Corporation. All rights reserved.
(for TaskLink)
