Section 2; Specifications - Solid State Cooling Systems THERMOCUBE 200 Product Manual

T C 200/300/400 T
HERMO UBE
S 2
ECTION
S
PECIFICATIONS
Operating Range (Set Point):
Ambient Temperature Range:
Stability / Repeatability:
Cooling Capacity (typical
Heating Capacity (typical):
Noise Level (at 1 meter):
Coolant / Process Fluid:
Process Fluid Fittings:
Pumps:
Tank Volume:
Wetted Materials:
Dimensions (L x W x H):
Weight:
Power Input:
Controls:
Communications:
Alarms
Standards
Other Options
Warranty
Note 1: Cooling capacity will vary with configuration.
S S C S , 167 M
OLID TATE OOLING YSTEMS
T : (845) 296-1300 F
ELEPHONE
C
HERMOELECTRIC HILLER
_________________________________________________
5°C to 50°C standard
(down to -5°C with low temp option - LT)
(up to 65°C with high temp option – HT, 60°C for centrifugal pumps)
0°C to 40°C non-condensing
±0.05°C with constant load (even near ambient)
1
): 200, 300 or 400 Watts @ 20°C in 20°C ambient air
400, 600 or 800 Watts @ 20°C in 20°C ambient air
< 63 dBA (down to 49 dBA with "-VS" variable speed fan option)
Koolance (27% propylene glycol / water mix)
or 27-50% ethylene glycol / water mix
Options available for PAO, Fluorinert / Galden or HFE
(contact SSCS for advice on other fluids)
1/4" John Guest standard (see options section for other fitting types)
Diaphragm, Centrifugal or gear pumps available
(see options section for pump types and specifications)
300 ml with level sensor
Aluminum, stainless steel and polymers
or Copper, stainless steel and polymers ("-CU" option)
13" x 11" x 13" (32cm x 28cm x 32cm)
28 lbs (12.7 kg) – standard model
Universal: 115-230 VAC, 50/60 Hz, 7-5 amps max
Digital PID controller for heating and cooling
Keypad or optional RS232 interface
Temperature, fluid level, system or component failure
(display and RS232 option)
TUV listed to UL, CAN/CSA and EN 61010-1,
CE 61010-1
(see Section 7 for available options)
2 years (diaphragm pumps are 1 year)
C R , W
YERS ORNERS OAD APPINGERS
: (845) 296-1303 :
AX WEB WWW
M
ANUAL
F , NY 12590
ALLS
. .
SSCOOLING COM
52-11300-1
5
V M28
ERSION
