Section 4; Start U P; Section 5; Operation - Solid State Cooling Systems THERMOCUBE 200 Product Manual

T C 200/300/400 T
HERMO UBE
S 4
ECTION
S U ______________________________________________________
TART P
Note: In order to avoid injury or damage, operators must only use this product in the
manner specified below.
WARNING
Electrical Shock
Hazard: Never Plug
in a Line Cord with
Wet Hands
CAUTION
Running the
ThermoCube dry
(no fluid) may
damage the pump
S 5
ECTION
O _____________________________________________________
PERATION
Key Action
UP Pressing the UP key raises the parameter value displayed.
DOWN Pressing the DOWN key lowers the parameter value displayed
ENTER Pressing the ENTER key momentarily enters the parameter changed.
ENTER Pressing and holding the ENTER key for 3 seconds causes the chiller to change the
display menu (see menu structure)
START/STOP Pressing the START/STOP key turns on temperature control.
START/STOP Pressing the START/STOP key while the chiller is operating turns off temperature
control (Operating Mode = *).
S S C S , 167 M
OLID TATE OOLING YSTEMS
T : (845) 296-1300 F
ELEPHONE AX
C
HERMOELECTRIC HILLER
Start-up the ThermoCube 200/300/400 using the following steps:
1) Connect coolant tubing to fluid connections located on the left
side of the unit, labeled Process Out (supply) and Process In
(return).
2) Connect Alarm Signal connector (if option chosen).
3) Remove the reservoir cap on top and fill the reservoir to just
below the bottom of its neck with coolant. Replace cap.
4) Plug line cord into 115 - 230 VAC, 50/60 Hz.
5) Turn on switch located on the left side of the unit. The front
display should read the current coolant temperature. If the front
display reads "TANK LEVEL LOW", add more coolant to the
reservoir until the display changes to read the coolant
temperature.
Important Notes:
1) If the tank level low alarm persists, or if another alarm is
displayed, consult section 6.0 of this manual.
2) If using an alcohol/water mixture, do not exceed 25% alcohol or
the reservoir level float may not rise sufficiently when filled to
turn off the tank level low alarm.
The ThermoCube 200/300/400 is operated via the control panel
located on the front panel. The control panel has a 16-character
LCD display and four input keys: UP, DOWN, ENTER, and
START/STOP. These keys work as follows:
C R , W
YERS ORNERS OAD APPINGERS
: (845) 296-1303 : .
WEB WWW SSCOOLING
M
ANUAL
F , NY 12590
ALLS
.
COM
52-11300-1
11
V M28
ERSION
