Backplane Connections — For switch fabric modules, displays a table
showing the current backplane connections (switch fabric module to
interface module) and the status of each connection.
Bridge Settings
The Bridge section contains the following settings:
General — Allows you to configure standard bridge parameters.
Spanning Tree — Allows you to view and configure spanning tree
parameters such as the bridge priority, hello time, maximum age, and
forward delay.
RAP Settings
The RAP (Roving Analysis Port) section contains the following settings:
Monitor Setup — Allows you to set up the port whose traffic you
want to analyze. The monitor port mirrors incoming and outgoing
traffic to the analyzer port for analysis.
Analyzer Setup — Allows you to set up the destination port that will
receive and process monitored traffic. The analyzer is the location
where RMON processing occurs.
Roving analysis enables you to monitor port traffic for network
management purposes. Device View allows you to choose any network
segment that is attached to a supported device and monitor its activity
using a network analyzer (also called a "probe").
You can monitor a port to:
Analyze traffic loads on each segment so that you can continually
optimize your network loads by moving network segments
Troubleshoot network problems (for example, to find out why a
particular segment has so much traffic.)
When you set up roving analysis, the system copies port data and
forwards it to the port on which the network analyzer is attached -
without disrupting the regular processing of the packets.
IP Configuration Settings
The IP Configuration section contains the following settings:
