Initial Setup

The Simple Logger
To connect the SLII to your computer:
1. Install the DataView
trol Panel as an option (it is selected by default). De-select any Control Panels
you do not need.
2. If prompted, restart the computer after installation is complete.
3. Insert the batteries into the SLII.
4. Connect the SLII to the computer using a USB cable for 1 and 2 channel instru-
ments or pair with Bluetooth (pairing code 1234) for 4 channel instruments.
5. Wait for the SLII drivers to install. The drivers are installed the first time the SLII
is connected to the computer. The Windows operating system will display mes-
sages indicating when the installation is complete.
6. Start the Simple Logger II Control Panel by double-clicking the Simple Logger II
shortcut icon in the DataView folder placed on the desktop during the installation.
7. Click Instrument in the menu bar, and select Add an Instrument.
8. The Add an Instrument Wizard dialog box opens. This is the first of a series
of screens that lead you through the instrument connection process. The first
screen prompts you to select the connection type (USB or Bluetooth). Choose
the connection type and click Next.
If the instrument is identified, click Finish. The SLII is now communicating with
9.
the Control Panel.
10. When you are finished, the instrument will appear in the Simple Logger II
Network branch in the Navigation frame, with a green check mark indicating a
successful connection.

Erasing the Memory

When batteries are inserted into the instrument, the memory will be marked as full. There-
fore, before starting a recording, the memory must be erased.
NOTE: If a recording is pending on the SLII, you must cancel it before erasing memory or
setting the clock (see below). When a recording is pending, these options are grayed
out and inactive. To cancel a recording via the Control Panel, select Instrument and
then click Cancel Recording.
1. Click Instrument in the menu bar, and select Erase Memory.
Select Yes when asked to verify erasing the memory.
2.
Setting the Instrument's Clock
To ensure an accurate time stamp of measurements recorded in the instrument, set the
instrument's clock as follows:
Select Set Clock from the Instrument menu. The Date/Time dialog box will be
1.
displayed.
2. Select the Synchronize with PC Clock button.
NOTE: The time can also be set by changing the values in the Date and Time fields and
clicking OK.
II (SLII) must be connected to DataView
®
software, making sure to select the Simple Logger II Con-
®
before it can be configured.
®
-6-
