- Page 1 IBW SERIES Revision B2, January 2010 © Inscale Ltd. 2010...
- Page 2 Easy Reference: Model name of the scale: Serial number of the unit: Software revision number (Displayed when power is first turned on): Date of Purchase: Name of the supplier and place: © Inscale Ltd. 2010...
-
Page 3: Table Of Contents
6.7 CHECK WEIGHING FUNCTION ..............12 6.8 USER CALIBRATION FUNCTION ..............13 6.9 SELECTION OF WEIGHING UNITS ..............13 7.0 CALIBRATION....................14 7.1 AUTOMATIC EXTERNAL CALIBRATION ............14 8.0 ERROR MESSAGE ..................15 © Inscale Ltd. 2010 p a g e... - Page 4 © Inscale Ltd. 2010 p a g e...
-
Page 5: Introduction
• Indicators for Stable, zero, net weight, and low battery functions • Stainless steel pan with ABS case and pan support • Sealed Membrane keypad • Overload Protection • Spirit level and leveling feet • Auto calibration, zero tracking and tare © Inscale Ltd. 2010 p a g e... -
Page 6: Specifications
0ºC to 40ºC temperature 32ºF to 104ºF 12VDC @ 800mA adapter Power supply 6V4.5Ah rechargeable battery Calibration External calibration Calibration 1kg,2kg,3kg 2kg,4kg,6kg 4kg,8kg,15Kg 10kg,20kg,30kg 2lb/4lb/6lb 4lb/8lb/12lb 10lb/20lb/25lb 20lb/40lb/60lb Weights Display 6 digits 24mm LCD © Inscale Ltd. 2010 p a g e... -
Page 7: Safety Precautions
• When the battery is lower than 5.7v, the battery symbol will show to indicate the low battery; when it is lower than 5.4v, the scale will turn off automatically. © Inscale Ltd. 2010 p a g e... -
Page 8: Set Up
The adapter provided with the scale is used to charge the battery. Make certain the adapter matches the voltage of the location you are using the scale in. © Inscale Ltd. 2010 p a g e... -
Page 9: Weighing
2% of the capacity, the NET symbol will be on. Load the container or remove material from the container, the scale will show the net weight of the material added or removed. © Inscale Ltd. 2010 p a g e... -
Page 10: User Functions
• Press the [Tare/↵ ↵ ↵ ↵ ] key to set the reference sample value, the display will show “SE ”. • Place the item to be set at 100% on the pan, and press the [Tare/↵ ↵ ↵ ↵ ] Key when the stability indicator comes on. © Inscale Ltd. 2010 p a g e... -
Page 11: Check Weighing
“xxxxx.x Lo”; if it is higher than high limits, the scale will show“xxxxx.x HI”. Otherwise the scale will show “xxxxx.x OK”。 • Press the [Tare/↵ ↵ ↵ ↵ ] key to exit and go back to weighing mode. © Inscale Ltd. 2010 p a g e... -
Page 12: Hold Function
• Press [Tare/↵ ↵ ↵ ↵ ] to confirm the value and start hold weighing function. 5.3.5 CALIBRATION • Refer to section 7 for details © Inscale Ltd. 2010 p a g e... -
Page 13: Function Setting
• “On bL”: backlight will be on all the time. Press [Tare/↵ ↵ ↵ ↵ ] to confirm and move to the next setting. When you • HOD " or "OFF HOD" . enter Hold function mode, it will show "On © Inscale Ltd. 2010 p a g e... -
Page 14: Hold Function Mode
• " ON CHE"：check weighing function is enabled. • Press the [Tare/↵ ↵ ↵ ↵ ] key to confirm and move to the next setting. It enters the calibration mode when is shows "On CAL" or "OFF CAL". © Inscale Ltd. 2010 p a g e... -
Page 15: User Calibration Function
• Press the [Tare/↵ ↵ ↵ ↵ ] key to confirm and move back to the first setting. Turn the scale off and on again to enter the normal weighing mode and save the changes make. © Inscale Ltd. 2010 p a g e... -
Page 16: Calibration
“（or ”CAL XX Lb “）.Press the [Hold/ ] key to change the calibration values if necessary. Each model has 3 different kg and lb calibration selection values. Calibration selectable values for all model: © Inscale Ltd. 2010 p a g e... -
Page 17: Error Message
L) or too high (FAIL H) in respect to the previous calibration value. 8.0 ERROR MESSAGE A/D counts are too high ---ADO A/D counts are too low ---ADL Wrong operation --ERR- ------ Overload 9d All the units are disabled Unit-E Low battery indication © Inscale Ltd. 2010 p a g e... - Page 18 © Inscale Ltd. 2010 p a g e...
- Page 19 Shielded interconnect cables must be employed with this equipment to insure compliance with the pertinent RF emission limits governing this device. Changes or modifications not expressly approved by Inscale Ltd could void the user's authority to operate the equipment. WEEE COMPLIANCE...
- Page 20 For a complete listing of all Inscale products visit our website at www.inscale.co.uk © Copyright by inscale Ltd. All rights reserved. No part of this publication may be reprinted or translated in any form or by any means without the prior permission of Inscale Ltd.
