- Page 1 IBC SERIES Pn. 700660168, RevisionC, August 2011 © Inscale Ltd. 2011...
- Page 2 Easy Reference: Model name of the scale: Serial number of the unit: Software revision number (Displayed when power is first turned on): Date of Purchase: Name of the supplier and place: © Inscale Ltd. 2011...
-
Page 3: Table Of Contents
7.6 ACCUMULATION WHEN IN PARTS COUNTING .......... 12 7.7 BACKLIGHT FOR LCD .................. 12 8.0 FUNCTION SETTING ..................12 8.1 ENTERING THE FUNCTION SETTING MODE ..........12 9.0 CALIBRATION....................14 10.0 ERROR MESSAGE................... 15 © Inscale Ltd. 2011 p a g e... - Page 4 © Inscale Ltd. 2011 p a g e...
-
Page 5: Introduction
• Indicators for Stable, zero, net weight, and low battery functions • Stainless steel pan with ABS case and pan support • Sealed Membrane keypad • Overload Protection • Spirit level and leveling feet • Auto calibration, zero tracking and tare © Inscale Ltd. 2011 p a g e... - Page 6 © Inscale Ltd. 2011 p a g e...
-
Page 7: Specifications
/ g / lb Stabilization time Operating 0ºC to 40ºC temperature 32ºF to 104ºF 12VDC @ 800mA adapter Power supply 6V4.5Ah rechargeable battery Calibration External calibration Calibration User Selectable Weights Display 6 digits 24mm LCD © Inscale Ltd. 2011 p a g e... -
Page 8: Safety Precautions
• When the battery is lower than 5.7v, the low battery will show to indicate the low battery; when it is lower than 5.4v, the scale will turn off automatically. © Inscale Ltd. 2011 p a g e... -
Page 9: Installation Of The Ibc Series
• The scale will show the battery voltage “vol-X.X” in the “Unit Weight” display . • Next a self-test is followed. At the end of the self-test, it will display “0” in all three displays, if the zero condition has been achieved. © Inscale Ltd. 2011 p a g e... -
Page 10: Display
TOTAL DISPLAY This display will show the number of items on the scale or the value of the accumulated count. Indicator: • Low battery, LO-BAT © Inscale Ltd. 2011 p a g e... -
Page 11: Key Descriptions
You can press the [Zero] key at any time to set the zero point from which all other weighing and counting is measured. This will usually be necessary only when the platform is empty. When the zero point is obtained the “Weight” display will show the indicator for zero. © Inscale Ltd. 2011 p a g e... -
Page 12: Taring
• The scale will then divide the total weight by the number of items and display the average unit weight. © Inscale Ltd. 2011 p a g e... - Page 13 [U W/Units] key. The “Unit Weight” display will show the value as it was entered. • The sample is then added to the scale and the weight will be displayed as well as the quantity, based on the unit weight. © Inscale Ltd. 2011 p a g e...
-
Page 14: Accumulation When In Parts Counting
• The default password is "0000" but other numbers can be set using the parameter menus. Press the [0] key four times. The display will jump to the first parameter. "FILt ?" with the Unit weight window showing the current filter setting. © Inscale Ltd. 2011 p a g e... - Page 15 To set the default unit. The option is g,kg,lb. ZErO To get the zero AD count. CALI See detail in section 10.0 To return to weighing after setting any parameter press the [Total] key to return to normal weighing. © Inscale Ltd. 2011 p a g e...
-
Page 16: Calibration
• If the calibration is outside of the previous calibration value by more than 5% ,it will show “FAIL L” or “FAIL H” indicating the new calibration weight was too low(FAIL L) or too high (FAIL H) in respect to the previous calibration value. © Inscale Ltd. 2011 p a g e... -
Page 17: Error Message
10.0 ERROR MESSAGE A/D counts are too high or low Z-ERR- EEEEE Overload 9d Arrow above Lo-Bat Low battery indication © Inscale Ltd. 2011 p a g e... - Page 18 © Inscale Ltd. 2011 p a g e...
- Page 19 Shielded interconnect cables must be employed with this equipment to insure compliance with the pertinent RF emission limits governing this device. Changes or modifications not expressly approved by Inscale Ltd could void the user's authority to operate the equipment. WEEE COMPLIANCE...
- Page 20 For a complete listing of all Inscale products visit our website at www.inscale.co.uk © Copyright by inscale Ltd. All rights reserved. No part of this publication may be reprinted or translated in any form or by any means without the prior permission of Inscale Ltd.
