Tektronix TDS5000B Series Service Manual page 175

Drives
Fig. &
Tektronix Serial no.
index
part number effective
number
4- - 1 119- - 6873- - 01
- - 2 174- - 0747- - 00
- - 3 407- - 4951- - 00
- - 4 174- - 4671- - 00
- - 5 119- - 6833- - 00
- - 6 407- - 4706- - 00
- - 7 211- - 1079- - 00
- - 8 174- - 4808- - 00
- - 9 174- - 4881- - 00
- - 10 211- - 1050- - 00
- - 11 211- - 1081- - 00
- - 12 407- - 4964- - 00
- - 13 119- - 6839- - 00
- - 14 103- - 0443- - 00
- - 15 174- - 7671- - 00
- - 16 441- - 2350- - 00
- - 17 679- - 5705- - 00
- - 18 065- - 0692- - 00
- - 19 211- - 1081- - 00
- - 20 407- - 4944- - 00
- - 21 119- - 6832- - 00
- - 22 211- - 1177- - 00
- - 23 200- - 4848- - 00
- - 24 407- - 4945- - 00
- - 25 679- - 5654- - 00
TDS5000B Series Service Manual
Serial no.
discont'd
Qty Name & description
1 DISK DRIVE; WINCHESTER,3.5 IN,80GB,180GXP
FAMILY,IDE,SINGLE PLATTER
UDMA100,7200RPM;07N9685,SAFETY CONTROLLED
4 SCREW,MACHINE; 6- - 32 X 0.188,PNH,STL,CDPL,T- - 15 TORX
DR
1 BRKT,MOUNTING; HARD DISK DRIVE,.050 ALUM
2 CA ASSY,SP; ULTRA DMA/ATA HARD DISK DRIVE,IDE,18.0 L
1 DISK DRIVE; USB FLOPPY,3.5 INCH;1.44MB,0.5 INCH,TWO
SIDED,DOUBLE DENSITY
1 BRACKET:FLOPPY DRIVE,6.064 X 5.075,ALUMINUM
2 SCREW,MACHINE:2.6 X 0.45 MM,3.0L,PNH,STL,PHILLIPS
1 CA ASSY; USB 2.0,DUAL HEAD,16.0 L
1 CABLE ASSY; 4 PIN P4 POWER,7.5 L,MOTHER BOARD TO
INTERFACE
2 SCREW,MACHINE:6- - 32 X 0.312 L,PNH,STL CAD,T15
1 SCREW,MACHINE; M3 X 0.5 X 3.5MM,FLAT WAFER HD
W/SERRATIONS STRESS RELIEVED,PHL,0.0002 STL ZI PLT
1 BRACKET ASSY; CD- - RW DISK DRIVE,0.050 AL
1 DISK DRIVE; OPTICAL,CD- - RW,5.25
SLIM,IDE,24X,24X,10X,650/700MB,110MS;CD- - W224E- - A93
1 ADAPTER; FOR CD- - ROM DRIVE,SLIMLINE,IDE INTERFACE
CONNECTOR,FOX CONN HL149207 OR EQUILIADAPTER;
FOR CD- - ROM DRIVE,SLIMLINE,IDE INTERFACE
CONNECTOR,FOX CONN HL149207 OR
1 CA ASSY,SP; ULTRA DMA/ATA HARD DISK DRIVE,IDE,18.0 L
1 BRACKET; REMOVABLE HD BOTTOM; GAL- - XC; STEEL
1 IDE1 ADAPTER BOARD
1 DRIVE ASSEMBLY; REMOVEABLE HARD DISK
DRIVE,TDS5000B SERIES, MIN REPLACEABLE HARD
DRIVE,W/O SOFTWARE INSTALLE
1 SCREW,MACHINE; M3 X 0.5 X 3.5MM,FLAT WAFER HD
W/SERRATIONS STRESS RELIEVED,PHL,0.0002 STL ZI PLT
1 BRACKET; REMOVABLE HD BOTTOM; GAL- - XC; STEEL
1 DISK DRIVE; WINCHESTER,2.5 IN,40 GB, IDE/ATAPI- - 6,4200
RPM,9.5MM,SINGLE PLATER
2 SCREW, THUMB, CAPTIVE; 6- - 32X.750 STAINLESS STEEL
COVER; FHD,REMOVEABLE
1 BRKT SUPPORT,REMOVABLE HD: TOP,GAL- - XC;STEEL
HDD ADAPTER; PTTHON
Mechanical Parts List
Mfr.
code
Mfr. part number
174- - 0747- - 00
1WNW6 407-4951-00
68167 F2N1107- - 18INCH
TK1943 407-4706-00
0KB01 10310188- - 0
060D9 174-4808-00
060D9 174-4881-00
0KB01 OBD
0KB01 211-1081-00
1WNW6 407- - 4964- - 00
50356 CD- - W224E- - A93
50356 E951073-10A
68167 F2N1107- - 18INCH
1WNW6 441- - 2350- - 00
80009 065-0692-00
0KB01 211- - 1081- - 00
1WNW6 407- - 4944- - 00
62786 08K0633
0KB01 211- - 1177- - 00
0KB05 200-4848-00
1WNW6 407-4945-00
80009 679- - 5654- - 00
10- 11
