- Page 1 Instructions for use Wine cooler with a freezer compartment RWFN2684SL RWFN2684BL...
- Page 2 We thank you for the confidence you have shown by purchasing our appliance. We wish you find a lot of pleasure in it use. The appliance is intended solely for household use. The wine cooler with a freezer compartment /ZeroZone compartment (hereinafter referred to as the appliance) consists of two parts.
-
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION IMPORTANT NOTES AND WARNINGS ADVICE FOR SAVING POWER WITH REFRIGERATION APPLIANCES APPLIANCE APPLIANCE DESCRIPTION DESCRIPTION 10 INSTALLATION AND CONNECTION 12 CHANGING THE DIRECTION OF DOOR OPENING 14 OPERATING THE APPLIANCE 19 APPLIANCE INTERIOR EQUIPMENT STORING AND 22 STORING FOOD IN THE ZEROZONE COMPARTMENT FREEZING FOOD 24 FREEZING AND STORING FROZEN FOOD... -
Page 4: Important Notes And Warnings
IMPORTANT NOTES AND WARNINGS This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or metal capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. - Page 5 Before connecting the appliance to the power mains, let the appliance rest in a vertical position for approximately 2 hours. This will reduce the possibility of operation faults due to the effect of transport on the cooling system. The appliance must be connected to the power mains and grounded in compliance with the effective standards and regulations.
- Page 6 To protect the environment, take the obsolete appliance to an authorized home appliance collection center. Packaging is made of environmentally friendly materials that can be recycled, disposed of, or destroyed without any hazard to the environment. Rating plate can be found in the appliance interior. If the language on the rating plate is not the language of your choice or the language of your country, replace it with the one supplied.
- Page 7 The symbol on the product or its packaging indicates that the product should not be treated as normal household waste. The product should be taken to an authorized collection center for waste electric and electronic equipment processing. Correct disposal of the product will help prevent any negative effects on the environment and health of people which could occur in case of incorrect product removal.
-
Page 8: Advice For Saving Power With Refrigeration Appliances
ADVICE FOR SAVING POWER WITH REFRIGERATION APPLIANCES • Install the appliance as specifi ed in the instruction manual. • Do not open the door more often than necessary. • Occasionally make sure air circulation underneath the appliance is unobstructed. • Condenser unit on the rear wall should be kept clean (see chapter Cleaning the appliance). -
Page 9: Appliance Description
APPLIANCE DESCRIPTION A Wine cooler Control unit 2 Led lighting of refrigerator interior 3 Bottle shelves 4 Portable bottle case B Freezer/ZeroZone compartment** 5 Freezer drawers/ZeroZone compartment • The shelves are protected against pulling out. To remove a shelf, lift it at the back and then pull it out. -
Page 10: Installation And Connection
INSTALLATION AND CONNECTION SELECTING THE ROOM • Install the appliance in a dry and well ventilated room. The appliance will operate correctly if the environment temperature is in the interval specifi ed in the table. The appliance class is indicated on the rating plate / label with the basic information on the appliance. Class Temperature from +10°C to +32°C... - Page 11 • The appliance may stand alone or it may be placed ext to a cupboard or a wall. Consider the clearance required to fully open the door in order to allow pulling out the drawers and shelves (see installation diagram). min 1210 627 675 1194 1242...
-
Page 12: Changing The Direction Of Door Opening
CHANGING THE DIRECTION OF DOOR OPENING Tools required: socket wrench No. 8, Phillips screwdriver, torx 25, hex key No. 4, flat screwdriver. The procedure to change the direction of door opening should be carried out by at least two persons. 1. -
Page 14: Operating The Appliance
OPERATING THE APPLIANCE A Appliance on key and wine cooler off key B Acoustic alarm off key C Lighting on/off key D Wine cooler temperature setting keys E Wine cooler set temperature display F Freezer compartment on key and appliance off key G Freezer/ZeroZone switch key H Freezer boost on/off key (when the freezer compartment operates in the ZeroZone mode, the H key has no function) - Page 15 Switching off the appliance: To switch off the appliance, press and hold (for three seconds) the F key (caution: appliance will remain powered, i.e. there will still be electric current in the appliance). ADJUSTING THE TEMPERATURE IN THE APPLIANCE • To set the temperature in the freezer compartment, use the D keys.
- Page 16 • After one of the I keys is pressed, the most recent temperature setting will fl ash on the display J. Use the I keys to set the desired temperature. Three seconds after the last key was pressed, the most recent temperature setting is stored for the freezer compartment. •...
- Page 17 • With this setting, the compressor will operate continuously and the temperature in the freezer compartment will drop considerably. • If the setting is not deactivated manually (by pressing the H key), it will be deactivated automatically after approximately one day. Freezer compartment temperature will return to the most recent setting.
- Page 18 APPLIANCE LIGHTING • Lighting in the entire wine cooler compartment is switched on every time you open the door, and it is switched off every time you close the door, except in the special operating mode described below. • Press the C key to activate the continuous LED lighting for the entire wine cooler compartment.
-
Page 19: Appliance Interior Equipment
APPLIANCE INTERIOR EQUIPMENT (* Equipment depends on the model) BOTTLE SHELVES • The shelves are intended for storing bottles. • Maximum load on each shelf is 13 kg. Shelf removal: The shelves are secured in place with a rail. When removing the shelf, unscrew the two screws on the rail, which is installed on the right side in the back of the appliance, behind the shelves. - Page 20 Note: The shelf is not intended to be partially pulled out. Therefore, do not pull out a full shelf from the appliance. Note: Do not stack bottles on the shelf in several layers. BOTTLE CASE • There is a bottle case at the bottom of the wine cooler compartment.
- Page 21 ADAPTIVE INTELLIGENT TECHNOLOGY Innovative sensor technology allows adjusting appliance operation to the user's habits or behaviour. Adaptive intelligent system monitors, analyzes, and records on a daily and weekly basis the use of appliance and adapts appliance operation to the perceived patterns.
-
Page 22: Storing Food In The Zerozone Compartment
STORING FOOD IN THE ZEROZONE COMPARTMENT The ZeroZone compartment allows storing a wide variety of fresh food to keep up to three times longer than in a conventional refrigerator. The food stays fresh longer, retaining the flavour and nutrients. • When buying food, make sure it is fresh as this will determine the quality of the food, as well as how long it will keep in the fridge. - Page 23 APPROXIMATE STORAGE TIME IN THE ZEROZONE COMPARTMENT* Type of food Time sausages, cold cuts, beef, pork, venison, raw meat up to 7 days Poultry up to 5 days fish up to 4 days seafood up to 3 days Vegetables: cabbage, garlic, carrots up to 180 days celery, herbs up to 30 days...
-
Page 24: Freezing And Storing Frozen Food
FREEZING AND STORING FROZEN FOOD FREEZING PROCESS Maximum amount of fresh food that may be inserted at once is specified on the appliance rating plate. If the amount of food to be frozen exceeds the indicated amount, the quality of freezing will be inferior;... -
Page 25: Important Warnings On Freezing Fresh Food
IMPORTANT WARNINGS ON FREEZING FRESH FOOD Only freeze the food that is suitable for freezing in the freezer. Make sure the food you freeze is of high quality and fresh. Choose appropriate packaging and use the packaging correctly. Packaging should not be permeable to humidity; it should be airtight to prevent the food from drying out and loss of vitamins. -
Page 26: Frozen Food Storage Time
FROZEN FOOD STORAGE TIME RECOMMENDED STORAGE TIME IN THE FREEZER Type of food Time fruit, beef from 10 to 12 months vegetables, veal, poultry from 8 to 10 months Venison from 6 to 8 months Pork from 4 to 6 months minced meat 4 months bread, pastry, ready-to-eat meals, lean... -
Page 27: Defrosting The Appliance
DEFROSTING THE APPLIANCE AUTOMATIC REFRIGERATOR DEFROSTING Refrigerator does not need defrosting because the ice on the back interior wall is thawed automatically. Any accumulated ice will melt when the compressor unit is inactive. Drops will flow through an opening in the refrigerator rear wall into a tray fitted above the compressor, from where they will evaporate. -
Page 28: Cleaning The Appliance
CLEANING THE APPLIANCE Before cleaning, unplug the appliance from the power mains – switch off the appliance (see chapter Switching the Appliance On/Off) and unplug the power cord from the wall outlet. • Use a soft cloth to clean all surfaces. Cleaners that contain abrasive substances, acids, or solvents are not suitable for cleaning as they may damage the surface. -
Page 29: Troubleshooting
TROUBLESHOOTING Problem: Cause or remedy: Appliance is connected • Make sure there is voltage in the power outlet and that to the power mains but it the appliance is switched on. does not work. • Too high environment temperature. Cooling system operates •... - Page 30 Problem: Cause or remedy: LED lighting does not • If LED lighting does not work, call a service technician. work: • Do not attempt a repair of the LED lighting yourself, as there is danger of contact with high voltage! Indication of error code on •...
-
Page 31: Information About Appliance Noise
INFORMATION ABOUT APPLIANCE NOISE Cooling in refrigerator freezers is made possible by a cooling system that also includes a compressor (and a fan with some appliances), which generates some noise. The level of noise depends on installation, proper use, and age of the appliance. •... - Page 32 en (08-18)
