Asko SVK67CS HCI643G Operating Instructions Manual

Ceramic cooking hob
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Operating instructions
SVK67CS HC1643G

Advertisement

Table of Contents
loading

Related Manuals for Asko SVK67CS HCI643G

Summary of Contents for Asko SVK67CS HCI643G

  • Page 1 Operating instructions SVK67CS HC1643G...
  • Page 2 Manual EN 3 - EN 27 Pictograms used Important information...

  • Page 3: Table Of Contents

    CONTENTS Your ceramic hob Introduction Control panel Description Safety instructions What you should pay attention to Connection and repair During use Cooking time limiter Using the touch controls Pans Operation Switching on Setting the power Switching off Residual heat indicator Zone function (Child) lock Kitchen / Egg timer...

  • Page 4: Your Ceramic Hob

    YOUR CERAMIC HOB Introduction This hob has been designed for the real lover of cooking. The hob is equipped with ‘Cooklight’ elements. These are very rapid- heating, radiant elements with a high efficiency, which is very favourable for heating-up times. What’s more, these elements also have very good heat distribution.

  • Page 5: Control Panel

    YOUR CERAMIC HOB Control panel Control sensor keys: Cooking hob on/off sensor Child lock sensor Child lock signal light Stop & Go sensor (temporary cooking progress suspension sensor key) Stop & Go signal light Alarm or timer setting sensor Cooking zone expansion indicator light Power level / residual heat displays Active function decimal point Increase value / setting sensor...

  • Page 6: Description

    YOUR CERAMIC HOB Description 1. Cooking zone rear left 1200 W / ø 145 2. Cooking zone front left 2200 W / ø 210, ø 120 3. Cooking hob control unit 4. Cooking zone front right 1200 W / ø 145 5.

  • Page 7: What You Should Pay Attention To

    SAFETY What you should pay attention to • Ceramic cooking is extremely safe. Various devices have been incorporated in the hob such as a residual heat indicator and a cooking time limiter. There are nevertheless a number of precautions you should take. Connection and repair •...
  • Page 8 SAFETY • This cooking appliance is designed for household use. It is to be used for food preparation only. • When you use the hob for the first time you will notice a “new smell”. This is normal. If the kitchen is well ventilated the smell will soon disappear.

  • Page 9: Cooking Time Limiter

    SAFETY Cooking time limiter • The cooking time limiter is a safety function of your cooking appliance. It will operate if you forget to switch off your hob. • Depending on the setting you have chosen, the cooking time will be limited as follows: Setting The cooking zone switches off automatically after:...

  • Page 10: Use

    Using the touch controls The touch controls may take some getting used to if you are used to other (rotary) controls. Place the tip of your finger flat on the control to achieve the best results. You do not have to apply any pressure.
  • Page 11 Attention • Grains of sand may cause scratches which cannot be removed. Only put pans with a clean base on the cooking surface and always pick pans up to move them. • Always keep the lid on the pan when cooking, in order to avoid energy loss.

  • Page 12: Operation

    OPERATION General • The cooking hob is fitted with electronic sensor keys which are activated, respectively, when the indicated surface of a particular sensor is touched with a finger for at least one second. • Activation of a sensor key is confirmed by a beep. •...
  • Page 13 OPERATION Changing the cooking zone power level • Select the cooking zone by pressing / touching the (H) sensor key. A decimal point (F1) will light up on the display of the selected cooking zone (F). • Press the “+” (G) or “–” (I) sensor key to change the power level.

  • Page 14: Residual Heat Indicator

    OPERATION Activating the child lock • Activate the child lock by holding the (B) sensor key for approximately three seconds; the (B1) signal light will light up. • Child lock can be activated when the cooking zone is operating. • Child lock prevents activation of any sensor key, except for the main switch (A) and the child lock sensor key (B).
  • Page 15 OPERATION Activating the autocook function • Set the power level to 9. • Press the “+” (G) sensor key. Indications “A” and “9” are shown on the display alternately. • Reduce the power level to the desired level at which the cooking is to continue.
  • Page 16 OPERATION Cooking zone expansion Activating the cooking zone expansion • For a selected cooking one (a decimal point is lit next to the display for the currently selected zone), an additional heating coil can be activated by pressing the (J) sensor key. The signal light (E) next to the display will light up.
  • Page 17 OPERATION Resuming the cooking progress • The cooking hob will continue to operate when the STOP & GO (C) sensor key is pressed again. • Signal light (C1) goes off. If the STOP & GO function is not deactivated in 10 minutes, the entire cooking hob will be switched off automatically.
  • Page 18 OPERATION B Switch-off function timer The switch-off timer facilitates the cooking process by allowing you to set the cooking time for a particular cooking zone. In order to set the switch-off timer, the power level must already have been set (see section “Turning on the cooking zones”).

  • Page 19: Cooking

    COOKING Switching off the timer After the set time has elapsed, an alarm will sound and the cooking zone will be turned off. The value “00” flashes on the timer display. Switch off the alarm by pressing any sensor key; if this is not done, the alarm will go off after a certain period of time.

  • Page 20: Maintenance

    MAINTENANCE Cleaning Set the (child) lock before you start cleaning the hob. Daily cleaning • Best for daily cleaning is a damp cloth with a mild cleaning agent. • Dry with kitchen paper or a dry teacloth. • Special cleaning agents for ceramic hobs have the advantage that a thin layer remains on the glass surface so that over- cooked food and lime scale are less likely to get burnt into the hob, making it easier to clean the next time.

  • Page 21: Faults

    FAULTS General If you notice a crack in the glass top (however small), switch the hob off immediately, unplug the hob, turn off the (automatic) fuse switch(es) in the meter cupboard or, in the event of a permanent connection, set the switch in the power supply lead to zero.) Contact the service department.

  • Page 22: Installation

    INSTALLATION Important warnings • Installation of the appliance into a kitchen worktop and its connection to the power mains may only be performed by an adequately qualified technician. • Veneer or other finish of the piece of kitchen furniture into which the hob is to be built in should be treated with heat resistant glue (100°C);...
  • Page 23 INSTALLATION Installation dimensions The dimensions and recesses are shown in the illustrations beneath. min.50 • Cooking hobs can be installed into worktops that are 30 to 50 mm thick. • The kitchen furniture element underneath the hob should not be fitted with a drawer. If the kitchen furniture element as a horizontal panel, it should be installed no less than 60 millimeters from the lower surface of the worktop.

  • Page 24: Electrical Connection

    INSTALLATION Attachment points for mounting brackets Electrical connection Connection diagram • Incorrect connection may destroy parts of the appliance, making the warranty void. • Before connecting the appliance, make sure the voltage indicated on the rating plate is consistent with the voltage in your home network.
  • Page 25 INSTALLATION Note: Connection bridges are already installed on their respective places on the clip. Screws of the connection terminals are open, which means they do not have to be unfastened or unscrewed any further. When fastening the screws, you may hear a slight ‘click’, which means that the screws should be fastened / screwed in completely.

  • Page 26: Building In

    INSTALLATION Technical details This appliance complies with all relevant CE directives. Hob type HC1643G Ceramic Connection 240V - 50Hz Max. capacity cooking zones (kW) Front left Rear left Rear right Front right Connected load (kW) Total connected load (Building in) dimensions (mm) Appliance width x depth 600 x 510 Build-in height from top of worktop...

  • Page 27: Environmental Aspects

    ENVIRONMENTAL ASPECTS Disposal of packaging and appliance In the manufacturing of this appliance durable materials were used. Make sure to dispose of this equipment responsibly at the end of its lifecycle. Ask the authorities for more information regarding this. The appliance packaging is recyclable. The following may have been used: •...
  • Page 28 EN 28...
  • Page 29 EN 29...
  • Page 30 EN 30...
  • Page 32 The appliance identification card is located on the bottom of the appliance. Stick the appliance identification card here When contacting the service department, have the complete type number to hand. You will find the addresses and phone numbers of the service organisation on the guarantee card. en (03-15)
