- Page 1 Operating instructions Hg1654s/Hg1664s Hg1774s/Hg1774a Hg1984s/Hg1984a...
- Page 2 Manual EN 3 - EN 29 Pictograms used Important information...
-
Page 3: Table Of Contents
CONTENTS Your gas hob Introduction Description 5 - 6 Safety instructions 7 - 8 Controls Igniting, adjusting and flame failure device Comfortable cooking Optimal use of the hob Use of the auxiliary support Maintenance General Stubborn stains on enamel Stubborn stains on stainless steel Cleaning the pan support Brass wok burner parts Cleaning removable burner components... -
Page 4: Your Gas Hob
YOUR GAS HOB Introduction You have chosen to cook with gas. You have therefore also chosen a hob which offers optimum ease of use. The gas hob is easy to operate, heats up quickly and is reliable. Furthermore, the gas flame can be adjusted very accurately. -
Page 5: Description
YOUR GAS HOB Description Hob Hg1984s/Hg1984a Hob Hg1664s 1. Simmer burner 2. Normal burner 3. Rapid burner 4. Wok burner 5. Pan support 6. Drip tray EN 5... -
Page 6: Description
YOUR GAS HOB Description Hob Hg1774s / HG1774a Hob Hg1654s 1. Simmer burner 2. Normal burner 3. Rapid burner 4. 2-Wok burner 5. Pan support 6. Drip tray EN 6... -
Page 7: Safety Instructions
SAFETY What you should pay attention to • Ensure that there is adequate ventilation during use. • Keep natural ventilation openings open. • When using the hob for long periods, extra ventilation is necessary. Open a window for instance or install a mechanical fan. •... - Page 8 SAFETY • Do not use the device as a worktop. The device may be switched on by accident or still be hot, which means objects could melt, become hot or catch fire. • Never cover the device with a cloth or something similar. If the device is still hot or is switched on, there is a risk of fire.
-
Page 9: Controls
CONTROLS Igniting and adjusting Each burner can be adjusted continuously between the high and low positions. 1. 0-setting 2. Burner indication 3. Low setting 4. High setting Flame failure device Your gas hob has a flame failure device. This ensures that the gas supply is shut off if the flame goes out during cooking. -
Page 10: Comfortable Cooking
Use of the auxiliary support Hg1774s/HG1774a/Hg1984s/Hg1984a • The auxiliary support supplied for the wok burner or available as an accessory provides additional stability in case of a wok with a round base. -
Page 11: Maintenance
MAINTENANCE General Your appliance has been manufactured from high-grade materials, which are easy for you to clean. • Regular cleaning immediately after use prevents over-cooked food being able to become ingrained and cause stubborn stains that are difficult to remove. Use a mild cleaning agent. •... -
Page 12: Stubborn Stains On Enamel
MAINTENANCE Assemble the burner parts using the guide ridges. Wok burner 1. Burner cap outer ring 2. External torch head 3. Internal lid and torch head 4. Gas base 5. Burner base 6. Sparkplug 7. Thermocouple Simmer-, semi-rapid and rapid burner 1. -
Page 13: Stubborn Stains On Stainless Steel
MAINTENANCE Stubborn stains on stainless steel • If spilled, acid fluids and sugary foodstuffs like red cabbage, beetroot, soy sauce, applesauce and rhubarb may cause the surface to discolour. Stubborn stains on stainless steel are best removed with a cleaning agent for stainless steel. Always polish in the direction of the steel structure to avoid shine spots. -
Page 14: Cleaning Removable Knobs
MAINTENANCE Cleaning removable knobs • If the knobs are very dirty, you can remove them temporarily to clean them. The knobs are best cleaned with a mild cleaning product and a soft cloth. Wearing rubber gloves makes it easier to remove the knob! Attention! Avoid an excess of moisture around the knob holes when cleaning. -
Page 15: Troubleshooting
If the appliance does not work properly, this does not always mean that it is defective. Try to deal with the problem yourself first by checking the points mentioned below in the table or contact the Asko service department (see guarantee card). - Page 16 TROUBLESHOOTING FAULT CAUSE SOLUTION A burner does not ignite. Control knob not kept pressed Keep the control knob pressed in far enough. in far enough between full and low. At first use this can take some more time because of the gas supply.
-
Page 17: General
The type of gas and the country for which the appliance has been designed are indicated on the application identification card. Please contact the ASKO service department if installation or operational faults occur during installation. This is a category 3 appliance. -
Page 18: Electrical Connection
• the plug has been pulled out of the socket. Faulty parts may only be replaced by original Asko parts. Only those parts are guaranteed by Asko to meet the safety requirements. If the connecting cable is damaged, it may only be replaced by the manufacturer, the manufacturer’s service organisation or equivalently... -
Page 19: Building In
INSTALLATION Building in Preparing the hob Fit the elbow supplied on the appliance’s gas connection. 1/2” ISO 228 (straight) 1/2” EN 10226-1 (conical) Sealing ring Cut opening in worktop Cut the opening in the worktop. This should be done very accurately (see building in dimensions). - Page 20 INSTALLATION Placing the sealing tape Remove the protective foil from the sealing tape (A) and apply the tape around the cut-out in the worktop. EN 20...
-
Page 21: Building In Dimensions
INSTALLATION Building in dimensions Hg1654s G1/2’’ EN 21... - Page 22 INSTALLATION Building in dimensions Hg1774s G1/2’’ EN 22...
- Page 23 INSTALLATION Building in dimensions Hg1774a G1/2’’ EN 23...
- Page 24 INSTALLATION Building in dimensions Hg1664s min. 50 Front Back EN 24...
- Page 25 INSTALLATION Building in dimensions Hg1984s/a G1/2’’ EN 25...
-
Page 26: Space To Be Left Free Around The Appliance
INSTALLATION Space to be left free around the appliance A hob generates heat. Leave a sufficient distance between the appliance and non heat-resistant materials. Take care also with materials that may discolour (such as stainless steel). min. 600 mm (Hg16..) min. -
Page 27: Gas Information
INSTALLATION Gas information ASKO Hg1774s/ Hg1774a/Hg1984s/Hg1984a BURNER INJECTOR INJECTOR ADJ. BURN BURNER SCREW RATE PRESSURE IN MM IN MM MJ/h SIMMER 0.90 0.45 3.60 N.G. 2 x NORMAL 1.20 0.60 6.70 LARGE 1.35 0.65 8.50 1.80 3.00 1.16 14.90 SIMMER 0.48... - Page 28 INSTALLATION ASKO Hg1664s BURNER INJECTOR INJECTOR ADJ. BURN BURNER SCREW RATE PRESSURE IN MM IN MM MJ/h SIMMER 0.90 0.45 3.60 N.G. NORMAL 1.20 0.60 6.70 1.80 3.00 1.16 14.90 SIMMER 0.48 0.30 2.90 ULPG* NORMAL 0.66 0.36 5.10 2.75 0.93...
-
Page 29: Appendix
APPENDIX Disposal of packaging and appliance In the manufacturing of this appliance durable materials were used. Make sure to dispose of this equipment responsibly at the end of its lifecycle. Ask the authorities for more information regarding this. The appliance packaging is recyclable. The following may have been used: •... - Page 31 142099...
- Page 32 The appliance identi¿ cation card is located on the bottom of the appliance. Stick the appliance identi¿ cation card here. When contacting the service department, have the complete type number to hand. You will ¿ nd the addresses and phone numbers of the service organisation on the guarantee card. en (10-13)
