A UV/blue light filter is
F . 6
IG
provided to prevent
premature curing of
dental composites
(comes pre-installed).
To use, slide the filter
over the front of the headlight until completely seated (Fig.
6). Using the supplied tool, tighten the set screw on the
bottom of the filter to properly secure to the headlight. You
can now rotate the UV/blue light filter into and out of the
path of light, as required.
NOTE: Be careful to not overtighten set screw when
installing.
U S I
NDERSTANDING THE TATUS NDICATOR
The LED DayLite® Micro incorporates an advanced status
monitoring system. The following table describes what each
indication signifies:
10
®
LED D L M U G
AY ITE ICRO SER UIDE
