Bakers Pride XX-4BG Specifications

COUNTERTOP GAS
GRIDDLE AND
RADIANT
BAKERS
PRIDE
CHAR BROILER
( Griddle tilts up 90° for Char Broiling
SPECIFICATIONS
Countertop gas radiant char broiler with spring balanced, feather-
touch, heavy duty tilting breakfast griddle designed for broiling or
grilling in one unit.
Exterior is all stainless steel. Front grease trough, slide out
stainless steel water pan/grease drawer and 4" (102mm) chrome
plated adjustable legs are standard. The tilting breakfast griddle is
1/4" (7mm) cold rolled steel. Interior combustion chamber is
fabricated of 11 gauge and 16 gauge HRS and hand welded to
form a single unit.
The XX-4BG features four 24" long, 18,000 BTU/HR, independently
controlled, clog-proof, high efficiency burners.
14 Gauge, 300-series stainless steel radiant heat deflectors are
placed directly above each burner for even heat transfer to the
broiling surface and breakfast griddle. Cast iron radiants are
optional.
Flame guards are attached to the underside of each burner to
prevent direct contact of grease and flames.
Top grates are cast iron with channels to direct grease to front
trough. Grates are 6" (152mm) wide by 23 3/4" (603mm) long
with 3/4" (19mm) rib spacing, while several grate types are
optional and may be mixed and matched.
BAKERS PRIDE OVEN COMPANY, INC.
30 Pine Street, New Rochelle, NY 10801
BAKERS
914/576-0200 • 1-800-431-2745 • fax 914/576-0605
PRIDE
Model XX-4BG
( Grilling Position )
Model XX-4BG
)
GAS CHAR BROILERS
Model XX-4BG
q
STANDARD FEATURES
Spring balanced, feather-touch, heavy duty tilting breakfast
q
griddle
Cast iron top grates for broiling
q
18,000 BTU/HR per burner with independently operated
q
control valves
72,000 BTU/HR natural or propane gas — model XX-4BG
q
All stainless exterior finish
q
Low profile, countertop design — only 13 1/4" to
q
broiling/grilling surface
Stainless steel slide-out grease drawer/water pans and 4"
q
legs
Stainless steel radiant heat deflectors with flame guards
q
3/4" (19mm) NPT rear gas connection and pressure regulator
q
Limited one year parts and labor warranty
q
OPTIONS & ACCESSORIES
Stainless steel front-mounted work deck with or without
q
sauce pan cut-outs
Richlite front mounted work deck with or without sauce pan
q
cut-outs
Cast iron radiants
q
Cast iron burners
q
Stainless steel equipment stand with or without casters
q
Meat grates, fish grates and/or floating rod grates
q
Char broiler and grilling utensils
q
Gas connector hoses
q
Removable splash guards
q
CERTIFICATIONS
Continuous product improvement is a policy of Bakers Pride Oven Company.
Therefore, specifications and design are subject to change without notification
G
®
CERTIFIED
