STEP 3
3.1
Attach Upper Support (F,G) and Bottom Support(C,D) with Connector(3).
3.2
Attach Stopper(4) and Wheel(5) on the bottom of Bottom Support(C,D)
and Back Support(H).
** 5 slope angle to be adjust on Support Frame(B),as shown.**
** Table height can be adjust with Connector(3).**
A
F
3
(1)x 2pcs
C
H
Recommended Maximum Weight
15Lbs
20Lbs
A
B
图1
Adjustable Slope
G
3
D
(5)x 2pcs
(4)x 2pcs
WARNING:
>This unit has been designed to support the
maximum loads shown. Exceeding these
load limits could cause sagging, instability,
product collapse, and/or serious injury.
>DO NOT allow children to climb on unit.
>Put heavier items on lower shelves.
its Space. its Budget
Approx. 30 minutes
Recomm. 1 Person
No Tools Required
Customer Support
NEED HELP? For help with assembly, or if you are missing a
part, please call Furinno Customer Service, 1-773-299-8111
from Mon-Fri, 9am-5pm (CST) or email: support@furinno.com
www.furinno.com
Assembly Instruction
Furinno Boyate Adjustable Rolling
Laptop Desk
FNBL-22090
MODEL
:
FNBL2209020171106
