Clas Ohlson PP-iDual-IR iD RC Manual

Remote Control

for iDual mood
lighting
Art.no 36-6090
Model PP-iDual-IR iD RC
Please read the entire instruction manual
before using the product and then save it for
future reference. We reserve the right for any
errors in text or images and any necessary
changes made to technical data. In the event
of technical problems or other queries, please
contact our Customer Services.
Safety
• Never subject the product to high
temperature, dust, heavy vibration,
impacts, humidity or moisture.
• The product is intended for indoor use only.
• Never mix old and new batteries and
never mix rechargeable batteries with non-
rechargeable batteries.
• Never attempt to dismantle the product, it
contains no user-serviceable parts.

Care and maintenance

• Clean the remote control by wiping it with
a dry cloth.
• Remove the batteries from the remote
control if it is not to be used for a long time.

Buttons and functions

1. On
2. Off
3. Dimming: hold the button in or press it
repeatedly to dim. Note: Dimming is only
possible when one of the light modes 4–7
and 10–11 is used. It is also possible to dim
when one of the buttons for fixed colour
(20) has been pressed.
GREAT BRITAIN • customer service tel: 020 8247 9300 e-mail: customerservice@clasohlson.co.uk internet: www.clasohlson.co.uk
3
4
5
8
9
12
13
16
17
White lights
4. Candle light
5. Warm white
6. Neutral white
7. Cold white
White scenes
8. Night light
9. Sleeping: initiates sleep mode, the light
dims gradually until fully off after 21 minutes
10. Working
11. Relaxing
Colour scenes
12. Sunrise: initiates wake-up mode,
reproduces the light of a sunrise until full
1
intensity is reached after 8 minutes and
30 seconds
2
13. Pastel
14. Party
15. Sunset
7
16. Forest
6
17. Lapping water
18. Fireplace
11
19. Romantic
10
15
Fixed colours
14
20. Select fixed colour: press to select the main
colour of your choice, press and hold in one
19
of the other adjacent fixed colour buttons
18
to gradually change the colour. There are
4 main colours and 7 intermediate colours
between each 2 main colours.
20
21. Colour saturation: press to increase/
decrease in three stages.
Function selector
21
22. Function selector for selecting the
type of target zone.
- Wide-angle and long range
< 6 m, suitable for controlling
multiple lights simultaneously.
- Narrow-angle and short range
< 3 m, suitable for controlling
one light (or several close
together).
Note:
• When the connected light is switched
off using the remote control, the current
light settings will be saved until the light is
switched on again.
• If the power to the light is cut, the light will
start in warm white light mode when it is
switched on again.
Batteries
1. Remove the battery cover on the back
of the remote control by sliding it in
the direction of the arrow.
2. Insert 3 × AAA/LR03 batteries.
Note the polarity markings on the bottom of
the battery compartment to ensure correct
insertion.
3. Slide the battery cover back into place.
Responsible disposal
This symbol indicates that this
product should not be disposed
of with general household waste.
This applies throughout the entire
EU. In order to prevent any harm
to the environment or health
hazards caused by incorrect waste disposal,
the product must be handed in for recycling
so that the material can be disposed of in
a responsible manner. When recycling your
product, take it to your local collection facility
or contact the place of purchase. They will
ensure that the product is disposed of in an
environmentally sound manner.
Specifications
Batteries 3 × AAA/LR03
Range Selectable 6 m or 3 m
22
Operating temperature −5 to 40 °C
