450W Electric
25cm Line Trimmer
Model: EQ748
SAFETY AND OPERATING MANUAL
ASSEMBLY REQUIRED
Please read & understand this manual, paying particular attention to the safety instructions before use.
We reserve the right to change the product specification & livery according to continued product improvements.
1938166001 03-08-17
Advertisement
Table of Contents
Related Manuals for JDW EQ748
Summary of Contents for JDW EQ748
- Page 1 450W Electric 25cm Line Trimmer Model: EQ748 SAFETY AND OPERATING MANUAL ASSEMBLY REQUIRED Please read & understand this manual, paying particular attention to the safety instructions before use. We reserve the right to change the product specification & livery according to continued product improvements.
-
Page 3: Table Of Contents
CONTENTS SAFETY INSTRUCTIONS SPECIFICATIONS COMPONENTS ASSEMBLY OPERATION CLEANING & MAINTENANCE STORAGE & TRANSPORTATION TROUBLE SHOOTING PARTS DIAGRAM & LIST GUARANTEE DECLARATION OF CONFORMITY... -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS Read and understand the owner’s manual and labels affixed to the machine. Learn its application and limitations as well as the specific potential hazards. Retain these instructions for future reference. The operator is responsible for following the warnings & instructions in this manual and on the product. - Page 5 SYMBOLS This graphic and when accompanied by WARNING or Read the instruction handbook DANGER, calls attention to before operating this machine. actions which could lead to SERIOUS INJURY We recommend eye and ear Wear foot protection or sensible protection shoes when using the machine Always wear gloves to protect Ensure suitable tight clothing your hands.
- Page 6 Risks caused by vibrations The vibration values specified in the technical data represent the main uses of the device. The actual existing vibrations during use may deviate from these as a result of the following factors: Incorrect use of the product; •...
-
Page 7: Specifications
• Personal protective clothing • Wear safety goggles Wear ear defenders Wear protective gloves Wear safety shoes • Wear close-fitting work clothes SPECIFICATIONS Model EQ748 Product Number 1938166001 Rated Voltage 230–240 V~, 50 Hz Capacity 450W Protection Class Idle Revolutions... -
Page 8: Components
COMPONENTS 1. On/Off Trigger 2. Main Handle 3. Cable Restraint 4. Safety Guard 5. Nylon Head 6. Plant Guard 7. Motor Head 8. Cutting Head Lock 9. Height Adjuster 10. Front Handle Lock 11. Front Handle... -
Page 9: Assembly
ASSEMBLY OPERATION Remove the machine and contents from the carton. Be sure the carton is empty DANGER before discarding. If you require any Risk of injury! The device may only be put assistance with regards to the contents of into operation if there are no defects. If a part the lawnmower contact us: is defective it must be replaced before the Customer Service Team:... - Page 10 CABLE RESTRAINT thrown up. Feed the extension cable through the strain Cut long grass from top to bottom to ensure relief mechanism (3) as shown. that the grass does not get tangled around the spool. Only use the tip of the nylon line. This way you use less nylon line and avoid grass getting caught up in the spool.
-
Page 11: Cleaning & Maintenance
CLEANING & MAINTENANCE DANGER Prior to conducting maintenance or cleaning: Unplug from the power source. Note: Clean unit immediately after every use. Remains of dried grass is very hard, and are very difficult to remove. BEFORE EACH USE What? How? Check the power cable and connector for Conduct a visual inspection and have the damage. - Page 12 PARTS DIAGRAM...
- Page 13 PARTS LIST Item No Description Right Handle Pressing Line Plate Positive Micro Switch Trigger Hand Spring Inner Wire BS Plug Cord Cable Sleeve Wiring Terminal Left Handle Self-Tapping Screw Spring Wire Assembly Left Auxiliary Handle Knob Spring Right Auxiliary Handle Knob Handle Telescopic Tube Assembly Self-Tapping Screws...
-
Page 14: Guarantee
GUARANTEE JDW guarantees this product against manufacturing defects. We will repair (or replace at our option), if a manufacturing defect occurs within the guarantee period as long as it has only been subjected to domestic use. For the purpose of this guarantee, domestic use means any use of the product on the property belonging to the purchaser and forming part of the garden area of his/her dwelling. - Page 15 CONFORMS TO EUROPEAN STANDARDS Machine type: 450W Electric 25cm Line Trimmer Machine model: EQ748 Product Number: 1938166001 Capacity: 450 Watt This machine conforms to EU Directives, to which this declaration relates & corresponds to the relevant basic safety and health requirements of Directive:...
- Page 16 Customer Service Team: 0871 231 2000...
