CLEANING THE FILTER. The timer is protected by a wire mesh lter that ensures long-lasting and trouble-free operation. The
lter should be inspected periodically and washed at the start of each season. Simply remove the lter from the connector
and rinse clean under running water.
1
1
For Aqua-Radio 2-way RF Timer (code): 90832
FITTING THE BATTERIES.
Unscrew the transparent cover and remove the control unit.
Unscrew the cap of the battery housing.
Draw the battery holder out of the housing.
Remove at batteries, if in place, and t the new ones in the holder, observing the correct polarity.
1
1
b
b
a
a
For Aqua-Radio 2-way RF Timer (code): 90832
RF 2-way timer
RF 2-way timer
Pag. 1
2
2
Washing at the
each season
2
2
c
c
O K
LO
W
3
3
start of
3
3
O K
LO
W
d
d
User guide
User guide
e
e
NEW!
1,5V - AAA
Alkaline
Advertisement
Related Manuals for claber 90832
Summary of Contents for claber 90832
- Page 1 Washing at the start of each season For Aqua-Radio 2-way RF Timer (code): 90832 FITTING THE BATTERIES. Unscrew the transparent cover and remove the control unit. Unscrew the cap of the battery housing. Draw the battery holder out of the housing.
-
Page 2: Installation
IP68 tested For Aqua-Radio 2-way RF Timer (code): 90832 INSTALLATION Fit the timer to a cold water tap, following these simple instructions. The spout of the tap should have a 3/4" or 1” male thread (if not, use an adapter) Screw the ring nut of the 3/4"... - Page 3 For Aqua-Radio 2-way RF Timer (code): 90832 RADIO REMOTE CONTROL. FITTING THE BATTERIES. Remove the cover of the battery housing and t the 2 batteries in the holder, observing the correct polarity; use only 2 new AAA 1.5V alkaline batteries. Re t the cover of the battery housing.
- Page 4 PROG EXIT S M T W T F S For Aqua-Radio 2-way RF Timer (code): 90832 RADIO REMOTE CONTROL. SETTING THE DAY OF THE WEEK. Use the buttons to select the day of the week: S=Sunday – M=Monday – T=Tuesday – W=Wednesday – T=Thursday – F=Friday – S=Saturday. To con rm and quit, press ;...
- Page 5 S M T W T F S IP68 For Aqua-Radio 2-way RF Timer (code): 90832 While the timer display keeps blinking, press the hidden button on the radio remote control with the tip of a paper clip. The display will start to blink and the symbol will appear.
- Page 6 S M T W T F S EXIT S M T W T F S For Aqua-Radio 2-way RF Timer (code): 90832 PROGRAMMING. Set up to 4 START TIMES for the watering cycle programmed on RF Unit 1. Press to set start time 1 — the n° 1 symbol remains permanently alight. Use the buttons to set start time n°...
-
Page 7: Rain Sensor
S M T W T F S EXIT S M T W T F S for 4 For Aqua-Radio 2-way RF Timer (code): 90832 RAIN SENSOR. Press the button to access activation/deactivation of the Rain Sensor; the OK message will blink. Pressing the buttons, the option can be toggled between YES (sensor activated) and NO (sensor deactivated). - Page 8 EXIT S M T W T F S EXIT S M T W T F S For Aqua-Radio 2-way RF Timer (code): 90832 TRANSFER OF PROGRAMMING DATA TO TIMER. Press the button to access , then press the button. The RF icon PROG will appear blinking on the display of the remote control for few seconds, with the green reception signal blinking on the timer.
- Page 9 2 batteries in the holder, observing the correct polarity. Reposition the battery holder in the housing and re t its cover. 1,5 V AA Alkaline For Aqua-Radio 2-way RF Timer (code): 90832 For further information, please refer to the instruction manual supplied with the product.
