Caffitaly System S24 Quick Start Manual

S24 QUICK START GUIDE:
FIRST TIME USE
Indicator Light
(Orange = Descale,
Red = Check System)
Tea Button -
120ml (Blue)
Tea & Water ONLY.
Single Express Double Espresso
Button Button
30ml (White)
60ml (White)
Open the Water
WATER
Tank Cover & fill the
Water Tank with
fresh water to the
1.
Max. Line indicated.
Check there is no
capsule in the
Capsule
Compartment.
3.
CLOSE the Lever.
Place a cup or
mug (at least
250ml) under the
Dispensing Spout.
5.
Note: If the Red
Indicator Light
continues to blink
and no water has
been extracted,
repeat Step 6.
When all the button
lights remain steadily
lit, rinse by pressing
the Tea Button.
8.
Press again to
repeat the the rinse
cycle.
ONLY USE WITH
Caffitaly System
Capsules
For more information, tips and video
tutorials please visit our website:
www.caffitalysystems.com.au
Plug your machine
ON
in and switch it ON
using the
On/Off Switch.
2.
Along with the
button lights, the
Indicator Light will
blink.
4.
Press the Tea
Button. Water will
cycle through the
system (approx. 30
6.
sec.) When done,
the Red Indicator
Light will switch off.
After Step 6.
has successfully
completed, all the
button lights will
7.
continue to blink
while your machine
warms up. (Approx.
1 min.)
Once you have
completed the Rinse
Cycle. Remove the
Drip Tray and Used
Capsule Drawer,
9.
empty any residual
water, rinse with
fresh water and
replace onto your
machine
TIP: The quantities of beverage dispensed can be programmed. Please refer
to chapter "Programming the quantity of coffee in a cup" in your Manual.
Open the Water
WATER
Tank Cover & fill
the Water Tank
with fresh water
10.
to the Max. Line
indicated.
Your machine is
now ready to use.
Insert the capsule,
pressing it gently
into place.
12.
TIP: For tall
mugs/latte
glasses, the
Drip Tray can
be detached and
removed.
The selected
button will blink
and the machine
will stop dispensing
15.
on reaching the
programmed
amount.
Raise the Lever
to eject the used
capsule into the
Used Capsule
16.
Drawer and then
lower the Lever.
Caffitaly System Capsules from your favourite brand
Raise the Lever to
open the Capsule
Compartment.
11.
Place a cup or
mug under the
Dispensing Spout.
13.
Select the
Single or Double
Espresso button
depending on the
14.
desired coffee.
Warning!
Do not use the
TEA BUTTON (lit in
blue) for dispensing
coffee.
Doing so will damage
the machine and
void your warranty.
TIP: To ensure
optimum product
delivery between
uses, eject the
used capsule from
your machine &
rinse by pressing
the Double
Espresson button.
