Caffitaly System S23 Instruction Manual

Capsule coffee maker machine
Hide thumbs
Table of Contents

Advertisement

Quick Links

S23
MODEL
ONLY USE WITH
Caffitaly System
Capsules
INSTRUCTION MANUAL
Imported by Roasting Australia Holdings Pty Limited
11 Hoyle Avenue, Castle Hill, NSW 2154
Phone: AU 02 9846 0307
NZ 0800 450 894
Email: caffitalysystem@rfg.com.au
caffitalysystem.com.au
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S23 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Caffitaly System S23

Summary of Contents for Caffitaly System S23

  • Page 1 MODEL ONLY USE WITH Caffitaly System Capsules INSTRUCTION MANUAL Imported by Roasting Australia Holdings Pty Limited 11 Hoyle Avenue, Castle Hill, NSW 2154 Phone: AU 02 9846 0307 NZ 0800 450 894 Email: caffitalysystem@rfg.com.au caffitalysystem.com.au...

  • Page 2: Table Of Contents

    • Detaching the Used Capsule Drawer & Drip Tray • Detaching the Water Tank • Descaling & Rinse Cycle Miscellaneous: • Restore Factory Settings • Energy Saving • Troubleshooting • Technical Data • Caffitaly System Care Contact • Warranty Details...

  • Page 3: Welcome

    CONGRATULATIONS on the purchase of your new Caffitaly System S23 Capsule Machine. In no time at all you will be producing barista quality coffee including Lattes, Cappuccinos, Hot Chocolate with the press of a button, all in the convenience of your home or office.

  • Page 4: Safety Warnings

    (unusual noise or odours), or if any other problem is detected inside the appliance, do not use it and contact the Caffitaly System Customer Service Line on AU 02 9846 0307 | NZ 0800 450 894.

  • Page 5: Symbols Guide

    SAFETY WARNINGS - Continued • This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

  • Page 6: Machine Components/Dispensing Head

    MACHINE COMPONENTS Diagram 1: Machine Components Lever Capsule Compartment Button Pad Water Tank Cover Dispensing Head Milk Jug Dial Cover Milk Jug Cover Dispensing Spout Used Capsule Water Tank Drawer Drip Tray Power Cord Milk Jug PLEASE NOTE: The machine Power On/Off and all the removable Switch at side of...

  • Page 7: Milk Jug Components/Milk Jug Dial Settings

    MILK JUG COMPONENTS Diagram 3: Milk Jug MILK JUG CONNECTOR Milk Jug Cover Always ensure the Milk Jug is placed back into position Milk Jug Dial gently but firmly onto your machine. There should be NO Milk Jug Connector GAP between the Milk Jug Connector and the Machine.

  • Page 8: Correct Use Of Buttons/Indicator Lights

    Caffitaly System Caffitaly System Capsules can be purchased from Woolworths, Capsules Countdown (NZ) and online. Check your favourite brand to see if they are Caffitaly System Capsules Diagram 5: Recommended Water & Milk Volumes Café Latte Button - 230ml (Lit in WHITE).

  • Page 9: First Time Use

    ON using the ON/OFF button for First Time Use and if the machine hasn’t been used for an extended period of time. ONLY USE WITH Ensure you only use Caffitaly System Capsules Caffitaly System which can be identified by the Caffitaly logo.
  • Page 10 FIRST TIME USE - continued If the Multifunction After Step 7 has Indicator continues successfully been to blink & no water completed, all the has been extracted, button lights will repeat Step 7. continue to blink, as the machine warms up.

  • Page 11: Dispensing Coffee Only

    Milk Jug in position. The Milk buttons will not be lit however the remaining beverage buttons will be lit and able to dispense beverages. ONLY USE WITH Ensure you only use Caffitaly System Capsules Caffitaly System which can be identified by the Caffitaly logo.

  • Page 12: Dispensing Tea Or Hot Water

    DISPENSING COFFEE ONLY - continued TIP: To ensure Raise the Lever optimum product to eject the used capsule into the delivery between uses, eject the used Used Capsule Drawer & then capsule from your lower the Lever. machine & rinse by pressing the Double Espresso button.

  • Page 13: Dispensing Milk Based Drinks

    DISPENSING TEA OR HOT WATER Raise the Lever TIP: To ensure to eject the used optimum product capsule into delivery between the Used Capsule uses, eject the used Drawer, and then capsule from your close the lever. machine & rinse by pressing the Double Espresso button.
  • Page 14 DISPENSING MILK BASED DRINKS - continued Replace the Milk Add fresh cold milk Milk Jug into position to the Milk Jug. by pushing gently onto your machine Note: Maximum is ensuring the Milk 500ml. Jug is flush on the right grid platform. Always ensure the Milk Jug is placed back into position...
  • Page 15 DISPENSING MILK BASED DRINKS - continued Press and release Always ensure the the Cappuccino, or Milk Jug is placed back into position Café Latte button gently but firmly onto depending on the your machine. There desired beverage. should be NO GAP The selected button between the Milk will flash.

  • Page 16: Programming The Quantity Of Beverage In A Cup

    PROGRAMMING THE QUANTITY OF BEVERAGE IN A CUP NOTE: The quantity of coffee dispensed may be programmed, from a minimum of 30ml to a maximum of 250ml. NOTE: Recommended Programming/Factory Programming: - 30ml: Single Espresso Shot - 60ml: Double Espresso Shot - 120ml: Tea &...

  • Page 17: General Operating Indications

    GENERAL OPERATING INDICATIONS DESCALING SIGNAL: HEATING: When the Descaling When all the button Indicator Light lights continuously blinks ORANGE it is blink, the machine is advisable to perform warming up. the Descaling Cycle (This will take on Page 25. approx.30 seconds.) WHEN THE WATER RUNS OUT DURING OPERATION: The Water Tank...
  • Page 18 GENERAL OPERATING INDICATIONS - continued IF THE LEVER IS RAISED: If the Lever is The Indicator light raised during blinks the delivery of a beeps. beverage, the The appliance will machine can emit immediately stop jets of hot water. dispensing. Risk of burns! Close the Press the Single or...

  • Page 19: Daily Maintenance/House Keeping

    DAILY MAINTENANCE - HOUSEKEEPING Always ensure the Water Tank is positioned correctly on your machine. Diagram 1. Tilt the Water Tank slightly and align the groves on the base of the Tank and your machine. Slide the Tank towards the back of the machine.

  • Page 20: Cleaning - Rinse Cycle

    DAILY MAINTENANCE Empty any used Remove the Drip capsules and water, Tray & Used then rinse the Drip Capsule Drawer Tray, Grid & Used from your machine. Capsule Drawer with water. Separate the Grid from the Drip Tray. Bottom Fill the Water Tank Remove the Water Tank.

  • Page 21: Cleaning - Milk System Rinse Cycle

    CLEANING - MILK SYSTEM RINSE CYCLE After dispensing any milk based drinks, you must complete a Milk System Rinse Cycle. If you have finished using the Milk Jug, ensure you perform the Milk System Rinse Cycle and have cleaned the Milk Jug Dispenser (instructions below). Full cleaning of the Milk Jug Dispenser must be completed at the end of each day.

  • Page 22: Detaching The Dispensing Head

    CLEANING – DETACHING THE COMPONENTS For best results, it is recommended that the Milk Jug is given a complete clean at the end of each day. Start by running a Milk System Rinse Cycle as described on the previous page. Please perform a full Cleaning Process at least twice a week.

  • Page 23: Detaching The Milk Jug

    CLEANING – DETACHING THE COMPONENTS - Continued To remove the Milk Connector Out Knob, turn the Dispensing Head to the back. On the left side you will see the knob in the ‘Locked Position (Image 1). Unlock the knob by rotating it to the right (anticlockwise).

  • Page 24: Detaching The Used Capsule Drawer & Drip Tray

    CLEANING – DETACHING THE COMPONENTS - Continued When assembling Always ensure the Milk Jug is placed the Milk Aspiration back into position Tubes, ensure the gently but firmly onto connections are flush your machine. There with each other. Also should be NO GAP check the connection between the Milk Jug when placed back...

  • Page 25: Descaling & Rinse Cycle

    DESCALING INSTUCTIONS Descaling Signal: When the Descaling Indicator Light blinks Orange, it is advisable to perform the Decaling Cycle with 48 hours or before next use. Failure to descale your machine will be detrimental to the taste of the coffee and may cause long term damage to your machine.
  • Page 26 DESCALING INSTUCTIONS - continued Add the 1 litre of Place at least a Descaling 1 Litre empty Solution jug under the to the Water Dispensing Spout. Tank. Descaling Solution Press and hold The Cleaning the Cleaning button will button in for blink during the TWO SECONDS Descaling Cycle.
  • Page 27 DESCALING INSTUCTIONS - continued Remove the Water Open the Water Tank, empty the Tank Cover and fill remaining descaling the tank with fresh solution & rinse the water to the Max. Water Tank with line indicated fresh clean water. Water Replace back onto your machine.

  • Page 28: Restore Factory Settings

    Primed If you have reset the machine and the problem as directed in ‘First still continues, please contact the Caffitaly System Time Use’ on Customer Care Line. Details on the front cover. Page 9.

  • Page 29: Energy Saving

    ENERGY SAVING After 10 minutes To start using your of disuse the machine again, 10 mins machine turns off press any button or automatically & lift the Lever. the button lights will slowly and sequentially blink. Your machine is All the button lights ready to use when will blink as the all the lights are...

  • Page 30: Troubleshooting

    TROUBLESHOOTING PROBLEM CAUSE SOLUTION FIRST USE - Machine heating up for the first - There may be a slight burning smell There is a burning smell when time. coming from the machine when first the machine first starts and a used.
  • Page 31 Tea button); buttons. -- For Milk based coffee only use the Cappuccino or Latte buttons. - Incorrect coffee capsule being -- Ensure you only use the Caffitaly System used. Capsules. Used the Cappuccino ot Latte - Milk Jug not positioned correctly.

  • Page 32: Technical Data

    Keep plastic bags, tags etc. out of reach of children and pets as they can be a source of danger. CAFFITALY SYSTEM CARE CONTACT For more information on the machine operation, available capsules and other useful www.caffitalysystem.com.au hints and tips go to the Caffitaly website: Phone: AU 02 9846 0307 | NZ 0800 450 894 E-Mail: caffitalysystem@rfg.com.au...

  • Page 33: Warranty Details

    1. Warranty Details: is at our sole discretion unless there is a (a) If your Caffitaly System Machine develops a ‘major failure’ as defined in the Australian fault or defect during the warranty period, Consumer Law or New Zealand Consumers and subject to the terms below, we will repair Guarantees Act.
  • Page 34 NOTES:...
  • Page 35 NOTES:...
  • Page 36 This unique design is why other capsules on the market do not work with the Caffitaly System Machine. Only use capsules displaying the Caffitaly System logo with this machine.
