ViewSonic NMP620-P10 Quick Manual

Quick Guide
Ultra Tiny PC
NMP620-P10
VS17044
Package Contents
The box contains the following items. If any of the items is
missing or damaged, please contact agency or dealer
immediately.
NMP620-P10 Power Adapter
Quick Guide
Ultra Tiny PC
NMP620-P10
VS17044
Quick Guide VESA Mount Screws
HDMI Cable
Interface
Front View Rear View
1
2 3 4
5
8
9
Left View Right View
Power Button LAN Port
1 6
Micro USB 2.0 Port for
2 Power Status LED 7
power adapter
3 Standard USB 3.0 Port 8 Anti-Theft Key Lock Hole
Standard USB 2.0 Port Micro SD Card Slot
4 9
HDMI Port
5
Getting Started
1. Connect the HDMI port of the mini PC to the HDMI port
of a TV or LCD monitor with the HDMI cable. Then set the
7
TV or LCD monitor by selecting the connected HDMI port
as "video input signal".
2. USB power supply: Insert the power adapter into a
standard AC power outlet and connect Micro USB end of
power adapter to this device.
3. It supports both USB mouse/keyboard and Bluetooth
mouse/keyboard.
6
4. Plug the RJ45 Ethernet cable to LAN port for WAN
connection.
5. Press the power button to start the system.
WiFi
Front View Rear View
USB mouse/keyboard
Bluetooth
mouse/keyboard
HDMI cable
Power Adapter
