SpotOn Pressure Tester
Product Manual
Features:
Measure nozzle supply pressure without shutting down
Easy handheld operation
Works with sprayer and irrigation nozzles
Model: PT-60
Item # 26970
Model: PT-100 Item # 26620
Model: PT-200 Item # 26630
Innoquest, Inc.
910 Hobe Road
Woodstock, IL 60098
Phone: 800-637-1623
www.SpotOnProducts.com
Specifications:
- Range:
PT-60
0-60 psi (0-4 Bar)
PT-100
0-100 psi (0-7 Bar)
PT-200
0-200 psi (0-14 Bar)
- Accuracy: +/- 2.5%
- Temp Range: 32 to 150*F (0 to 65*C)
- Size: 2.2" Dia.(5.6cm) x 5.0" Long(12.7cm)
- Weight: 0.4 lbs (180g)
- Made in USA
Taking a Measurement:
1.
Remove needle from storage compartment and install on
white fitting with gentle twisting motion.
2.
Insert needle into nozzle's orifice - usually done while nozzle
is running. (Shown dry here for clarity of picture)
Advertisement
Table of Contents
Related Manuals for SpotOn PT-100
Summary of Contents for SpotOn PT-100
- Page 1 PT-100 0-100 psi (0-7 Bar) PT-200 0-200 psi (0-14 Bar) Model: PT-100 Item # 26620 - Accuracy: +/- 2.5% Model: PT-200 Item # 26630 - Temp Range: 32 to 150*F (0 to 65*C) - Size: 2.2” Dia.(5.6cm) x 5.0” Long(12.7cm) - Weight: 0.4 lbs (180g)
- Page 2 Needle Selection: Fully insert needle inside nozzle to accurately measure pressure supply to nozzle. Note: Air Induction nozzles will Standard Needle Extra Long Needle require inserting the needle inside the primary orifice fully for accurate pressure readings. This may require use of the extra long needle.
