Veris TE series Installation Manual

Installation Guide
Temperature
NOTICE
• This product is not intended for life or safety applications.
• Do not install this product in hazardous or classified locations.
• Read and understand the instructions before installing
this product.
• Turn off all power supplying equipment before working on it.
• The installer is responsible for conformance to all applicable codes.
No responsibility is assumed by Veris Industries for any consequences arising out of the
use of this material.
Z202233-0V Page 1 of 2
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris 'V' logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.

Product Overview

The TE wall mounted temperature sensor monitors the temperature of the air inside a room. It has standard
resistive outputs compatible with building control systems, and it is warranted for a period of five years.

Product Identification

Sensor Type
TE
B = 100R platinum, RTD
C = 1k platinum, RTD
D = 10k T2, Thermistor
E = 2.2k, Thermistor
F = 3k, Thermistor
G = 10k CPC, Thermistor
H = 10k T3, Thermistor
I = 1k Balco (Nickel-iron) RTD
J = 10k Dale, Thermistor
K = 10k w/11k shunt, Thermistor
M = 20k NTC, Thermistor
N = 1800 ohm, Thermistor
R = 10k US, Thermistor
S = 10k 3A221, Thermistor
T = 100k, Thermistor
U = 20k "D", Thermistor
W = 10k T2 high accuracy,
Thermistor
Y = 10k T3 high accuracy, Thermistor
Z = 10k E1, Thermistor
CC = 15k, Thermistor

Specifications

©2013 Veris Industries USA 800.354.8556 or +1.503.598.4564 / support@veris.com
Other companies' trademarks are hereby acknowledged to belong to their respective owners.
TE Series
Wall Temperature Sensor
Setpoint/Override Cal Certificate
0 = None
1 = Override
2 = 1k Setpoint
3 = 10k Setpoint
4 = 1k Setpoint w/override
5 = 10k Setpoint w/override
Wiring 22 AWG; 2-wire RTD/Thermistor
0 = None
1 = 1 point Cal validation
2 = 2 point Cal validation
