HWXW SERIES AND TWXWXX
Wireless Temperature and Humidity Sensors
NOTICE
• This product is not intended for life or safety applications.
• Do not install this product in hazardous or classified locations.
• Read and understand the instructions before installing
this product.
• Turn off all power supplying equipment before working on it.
• The installer is responsible for conformance to all applicable codes.
No responsibility is assumed by Veris Industries for any consequences arising out of the
use of this material.
FCC PART 15 INFORMATION
NOTE: This equipment has been tested by the manufacturer and found
to comply with the limits for a class A digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in
a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own expense.
Modifications to this product without the express authorization of
Veris Industries nullify this statement.
IMPORTANT NOTE: To comply with FCC & IC RF exposure requirements, the antenna used
for this transmitter must be installed to provide a separation distance of at least 20cm
from all persons and must not be co-located or operate in conjunction with any other
antenna or transmitter.
PRODUCT IDENTIFICATION
Local Display
Wireless
HW
X
W
= No Display
= Wireless
Local Display
Wireless
TW
X
W
= No Display
= Wireless
Accessories (sold separately)
Part Number
AWB01
Wi-Fi configuration cable
AWB04
JACE Driver
Z206323-0B
PAGE 1
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris 'V' logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
WIRELESS DEVICES
Temp. Option
RH Option
1 = RH 1% NIST
X = No temp.
2 = RH 2% NIST
T = Temp. transmitter
H = RH 2%
XX
Description
©2012 Veris Industries USA 800.354.8556 or +1.503.598.4564 / support@veris.com
SPECIFICATIONS
Inputs:
Input Voltage
Two 1.5 V AA lithium/iron disulfide batteries (3000 mAh min.)
Setup
Outputs:
Wireless
Battery Indicator
Temperature Output Range
EU
Accuracy:
Temperature
Humidity
Operating Environment:
Operating Temperature Range
Operating Humidity Range
Storage Temperature Range
Agency Approvals
PRODUCT OVERVIEW
The Aerospond HWXW Series and the TWXWXX wireless sensors monitor the
humidity and temperature, respectively, of the air inside a room. The HWXW series
has a temperature option to get both readings in one device. The sensors send
environmental readings over a standard building wireless (Wi-Fi) network. The
sensors can be integrated with the building controller using either a network wireless
gateway (Veris Aerospond NWGWA2), which converts data to either analog or digital
outputs, or with a JACE controller and driver (Veris AWB04) for direct integration.
QUICK INSTALL
1. Configure all devices in the wireless network using the Veris configuration
software, available at www.veris.com.
2. Affix the backplate on a vertical wall, about 4 ½ feet above the floor, away from
ventilation sources.
3. Insert two 1.5 V AA lithium/iron disulfide batteries (3000 mAh min.) into the
terminals on the back of the sensor.
4. Mount the sensor onto the backplate and attach the front cover.
DIMENSIONS
3.5"
(89 mm)
INSTALLATION GUIDE
Pushbutton setup
802.11 B/G 2.4 GHz radio
Indicates low battery power (read by Gateway or JACE)
Configurable in software: 0° to 50°C (32° to 122°F)
or 10° to 35°C (50° to 95°F)
±0.75°C (typical)
±2% of full scale @ 25°C
0° to 50°C (32° to 122°F)
0 to 95% RH noncondensing
-40°C to 50°C (-40°F to 122°F)
EN61010-1; ETL; CE
1.2"
(30 mm)
4.8"
(121 mm)
12121
