LEAD-ACID

CHARGING PROGRAMS

Settings are made by pressing the MODE-button. After about two seconds the charger
activates the selected program. The selected program will be restarted next time the
charger is connected.
The table explains the different Charging Programs:
Program
Normal battery program 14.4V/25A. Only for lead-acid
NORMAL
batteries.
Recond program 15.8V/1.5A
Use Recond to return energy to empty WET and Ca/Ca batteries.
RECOND
Recond your battery once per year and after deep dischare to maximise
lifetime and capacity. The Recond program adds the Recond step to the
normal battery program. Only for lead-acid batteries.
Supply program 13.6V/25A
Use as a 12V power supply or use for float maintenance charging when
SUPPLY
100% capacity of the battery is required. The Supply program activates
the Float step without time or voltage limitation.
on the battery charger is disabled during the SUPPLY program.
READY TO USE
The table shows the estimated time to charge a battery from empty to 80%
BATTERY SIZE (Ah)
40Ah
100Ah
200Ah
300Ah
6 • EN
Explanation
The spark protection
TIME TO 80% CHARGED
1.5h
3h
6h
16h

MODE

POWER LAMP
If the power lamp is lit with a:
1. STEADY LIGHT
The mains cable is connected to the wall socket.
2. FLASHING LIGHT:
NORMAL LITHIUM SUPPLY
The charger has entered the energy save mode. This happens if the
charger isn´t connected to the battery within 2 minutes or the battery
voltage is below 2V.
ERROR LAMP
If the error lamp is lit, check the following:
1. Is the chargers red clamp connected to the battery's
positive pole? Connect the charger according to the
vehicles manual.
2. Is the charger connected to a 12V battery?
3. Are the clamps short circuited?
4. Has charging been interrupted in
Restart the charger by pressing the MODE-button. If charging is still
being interrupted, the battery...
MODE
...is seriosly sulphated and may need to be replaced.
...can not accept charge and may need to be replaced.
...can not keep charge and may need to be replaced.
NORMAL LITHIUM SUPPLY
RECOND
or ?
RECOND
