PRODUCT FEATURES

Temperature Control
Controls the temperature in the cabinet.
Turn the knob to change the temperature
set point. The display shows new set
point as the knob is turned.
Power Switch
Temperature Scale Indicators
Set to Fahrenheit in the factory.
These indicators will also blink
while the temperature and
humidity set points are
being displayed.
Air Temperature Display
Displays the current cabinet
temperature. Also displays low
temperature warning.
Control Panel
Field Reversible
Doors
Be careful when
opening the doors
as hot, humid air will
escape the cabinet.
Flush Pull Handles
Water Drain
Allow water to cool
before draining.
/
Drip Trough Bumper
Drip Pan
Humidity Control
Controls the relative humidity in the cabinet. Turn the
knob to change the humidity set point. The display
shows the new set point as the knob is turned.
Audio Disable (Sound Off)
Press "Recall" and "Low Temp
Alarm" buttons simultaneously and
hold for five seconds to toggle sound
off and on.
7
Tray Slides
Air Duct
Water Reservoir
Fill with water to
about one half
inch (12mm)
below the water
reservoir cover.
Water
Reservoir Cover
This must be
installed for
cabinet to
function properly.
Set Point Recall
Displays cabinet's temperature
and humidity set points.
Humidity Display
Displays the current
cabinet humidity. Also
displays low water warning.
Element Cycling
Indicator Lights
Indicates the active heat
element. One each for air
and water heat elements.
Low Temperature Alarm
Sets and recalls the low
temperature alarm set point.
