Installation with Optional Rough-In Box
6b
6a
7
Rough-In box used as
a guide to cut out the
opening.

Installation without Rough-In Box

STEP 1
⁄ ⁄
9 1
Make a 3 " x 5 " cut-out in the desired location using the
1 6 4
template provided on page 2 of this manual.
STEP 2
Route the control cable from the wall cutout to the steam
generator. Connect one end of the cable to the steam generator
connector. The two ends of the control cable are the same.
STEP 2
When used, route the AudioWizard
cut-out to the AudioWizard. The two ends of the AudioWizard cable
are the same. See the AudioWizard Installation Operation & Mainte-
nance Manual (PUR 100478) for complete AudioWizard Installation
instructions.
IMPORTANT NOTE: Be careful not to strain, staple, pinch or
otherwise damage the control cable. Route cable as required to
permit replacement. Do not route cable inside conduit together
with power lines or close to hot water or steam piping.
Finish the iSteam 2.0 installation using the instructions on page 7.
IMPORTANT NOTE: Be careful not to strain, staple, pinch or
otherwise damage the cables. Route cables as required to permit
replacement. Do not route cables inside conduit together with power
lines or close to hot water or steam piping.
STEP 6
When used, route the AudioWizard
second knockout in the rough-in box and clip (6b). The two ends
of the AudioWizard cable are the same. See the AudioWizard
Installation Operation & Maintenance Manual (
complete AudioWizard Installation instructions.
STEP 7
Use the rough-in box as a guide to cut out the
⁄ ⁄
9 1
(3 " x 5 ") opening in the wall.
1 6 4
Finish the iSteam 2.0 installation using the instructions on page 7.
™ Cable from the wall
6
(cont.)
Cable (6a) through a
™
PUR 100478
Controls
) for
1
5 "
⁄
4
"
3 9
⁄
16
