H E X M I X S Y S T E M
M O D U L E
R E F E R E N C E
1 .
Aux Returns
Stereo return inputs with switched Line or
Modular level signal.
2.
PFL Switch
Activates pre-fader "cue" listening.
3.
Aux Sends Controls
Level controls for each Auxiliar Send.
4.
Aux Master Outs
Pre and Post Fader auxiliar send outs, with
master volume control.
5.
Headphones Control
Manual control for Headphones Output volume.
8
U S E R M A N U A L
F R O N T P A N E L C O N T R O L S
6.
PFL Out Control
Manual control to crossfade between PFL and
Master, at headphones out.
7.
Level Peak Meter
LED level meter. Shows the level of master or PFL
signal.
8.
Main Outputs
Master Out and Headphones outputs in 6,5'' Jack
format.
9.
Direct Outputs
Direct outputs (post Fader/EQ) for each channel.
H E X P A N D E R
