H E X M I X S Y S T E M
Now, let's focus our attention on the second half of the system, the Hexpander.
There are two connectors in Hexpander module, please read carefully before connecting the module in your
rack.
HEXPANDER
CONNECTOR
JUMPER
C O N N E C T I N G I N G
T H E M O D U L E
Disconnect your cabinet from the mains.
1 .
2. Connect expander cable to your Hexmix module. Please use only provided
cable.
3. If you have any questions about this product please send them to:
befacosynth@gmail.com
7
U S E R M A N U A L
H E X P A N D E R
S201
P R E V I O U S C O N S I D E R A T I O N S
1 .
Hexpander Connector
The Hexpander have only one big connector in the
backside. This connector power the module and
handles the communication with the Hexmix
2.
S201
Expansion port. Not used.... for now.
H E X P A N D E R
