Forest 5201001460 Manual

Multi remote

Advertisement

Quick Links

● 3V battery CR2430
● battery life > 3 years
● frequency 433.92MHz
● transmit power 10mW

SET TIME:

PRESS MODE TO SET
PRESS TIME FOR ~7SEC.
MODE TO MANUAL
→ 2 DIGITS WILL BLINK
'man' ON DISPLAY
BEFORE SETTING THE TIMER, SET THE CLOCK!

SET TIMER (EACH CHANNEL SEPARATE):

PRESS MODE TO
SELECT CHANNEL
SET MODE TO
AUTO OR DYNAMIC
PRESS BUTTONS TO
PRESS TIME TO
CHANGE CLOSE▼ TIME
TOGGLE BETWEEN
HOURS/MINUTES
11/2013 WDOC MULTI REMOTE
FOREST MULTI REMOTE - 5201001460
● transmit range indoors max. 30mtr
● working temperature -10°C - +50°C
● modes: manual, timer and dynamic timer (15 minutes + and -)
● each channel can control up to 20 receivers / motors
selected channel
manual/auto/dynamic mode
open/up button
stop button
close/down button
channel +/-
PRESS BUTTONS TO
CHANGE TIME
PRESS TIME FOR
~7SEC. → HOUR
DIGITS WILL BLINK
PRESS TIME FOR ~7SEC.
UNTIL DIGITS STOP
BLINKING → FINISHED
866-823-3894 / www.forestdh.com
PRESS TIME TO
PRESS TIME ~7SEC.
TOGGLE BETWEEN
UNTIL ALL DIGITS
HOURS/MINUTES
STOP BLINKING
PRESS BUTTONS TO
PRESS TIME TO
CHANGE OPEN▲ TIME
TOGGLE BETWEEN
HOURS/MINUTES
SET MODE TO
AUTO OR DYNAMIC
mode button
time button
non applicable
battery slide (CR2430)
PRESS TIME ONCE
MORE TO FINISH
AND START CLOCK
PRESS MODE TO SWITCH
TO CLOSE▼TIME
1/4
