Controller I/O; Relays And Digital Inputs; Analog Inputs And Outputs; Power And Communication - CRC -RPM User Manual

14.
RLY1
RLY1
RLY2
RLY2
RLY3
RLY3/4
RLY4
DIN1
DIN2
GND
GND
DIN3
DIN4
V+
GND
+10V
GND
+5V
AIN4
AIN3
GND
GND
AIN2
AIN1
AOUT4
AOUT3
AGND
AGND
AOUT2
AOUT1
24V IN
24V IN
Room Pressure Monitor and Controller - User Guide
:
Pressure Alarm Status 1
Pressure Alarm Status 2
Isolation/Non-Isolation Status
Door Contact 1
Door Contact 2
Audible Alarm Silence
:
Mode Change in
Exhaust/Supply PID 2 or mode out to RPM
RPC//MRM (PID RPC2 only)
Exhaust/Supply PID 1 0-10V
Pressure 2 to BAS 2-10V (RPC2 ONLY)
Pressure 1 to BAS 2-10V
:
24VAC
RS 485 Network connection
Differential Pressure 2
Differential Pressure 1
23
© 2014 CRITICAL ROOM CONTROL
(RPM2 &RPC2 )
